Dalxo Gas Cooktop

Model: GHS705IV-PCI

User Manual

Please read the instruction carefully before usage.If you have any problems,

support@dalxo.com

please do not hesitate to contact our service team:

Table of Contents

Need help?

Do you have a question about the GHS705IV-PCI and is the answer not in the manual?

Questions and answers

Summary of Contents for Dalxo GHS705IV-PCI

Page 1 Dalxo Gas Cooktop Model: GHS705IV-PCI User Manual Please read the instruction carefully before usage.If you have any problems, support@dalxo.com please do not hesitate to contact our service team:...
Page 2: Table Of Contents
Table of Contents Introduction..........................1 Important Safety Tips......................2 Machine Diagram/Parts List....................4 Installation Gas Cooktop.....................5 Using the Gas Cooktop.......................12 Cleaning & Maintenance....................14 Troubleshooting........................16 Warranty..........................17...
Page 3: Introduction
Easy to install and convert from NG to LPG by providing the kit. Perfect for your indoor or outdoor kitchen area, cabin and mobile home. Hope that you will enjoy the use of Dalxo's gas cooktop for many years to come. We take great pride in providing you with the highest quality products and superior service and support.
Page 4: Important Safety Tips
Important Safety Tips Please read and understand the following safety tips prior to using your product. Recommend asking a professional electrician to install the gas cooktop. Never use this device to heat a room. It may lead to carbon monoxide poisoning or overheating of the oven.
Page 5 To reduce the risk of fire, electric shock, personal injury, or damage when using the stove top, please follow basic precautions as followings:  Note: Do not put items of interest to children in the cabinet above the cooktop to prevent them from climbing up and causing serious injury.
Page 6: Machine Diagram/Parts List
Machine Diagram/Parts List 1. Defendi Auxiliary burner 2. Defendi Semi-rapid burner 3. Defendi Rapid burner 4. Defendi Triple burner 5. Metal knob 6. Ignition 7. Thermocouple Parts Number Diagram Elbow 1pcs Gas Regulator 1pcs Washer 2pcs 4pcs LPG Nozzle Fixing Plate 4pcs Screws 5pcs...
Page 7: Installation Gas Cooktop
Installation Gas Cooktop  Be sure to disconnect the power to the device before installation and maintenance.  These cooktops are designed to be placed in a countertop depth >2.36 inches (60 mm).  Please use the included "cutting template" to outline and cut holes on the countertop.
Page 8 Installation in Kitchen Cabinet with Door NOTE: Adjacent furniture and all materials must be able to withstand at least 185°F (85°C) above ambient when installed. However, certain types of vinyl or laminate kitchen furniture are particularly prone to heat damage or discoloration at temperatures below 185℉(85℃).
Page 9 Settling the Cooktop for Installation  Remove burners and grates.  Turn the cooktop upside down and place the top on a cloth.  Seal "G" with self-adhesive, as shown in Figure 5.  Place the cooktop in the recess and secure the 4 corners with the brackets for a worktop thickness of 1.18 - 1.57”...
Page 10 Connect the Cooktop to Gas Close the main gas supply valve before disconnecting the old cooktop and keep it closed until the new connection is made. When turning the gas back on, don't forget to relight the pilot on the appliance. Never use the old connectors when installing a new cooktop. Convert to LPG or NG This cooktop is factory settings to use natural gas or LPG.
Page 11 If the gas pressure is different from the regulations, a pressure regulator that meets national and government standards must be installed at the source. To complete the conversion, please follow the steps below, A) Replace the burner nozzle B) Adjust the level of the burner flame C) Leak test A) Replace the Burner Nozzle 5 LPG nozzles in the package and 5 installed NG nozzles on the gas stove...
Page 12 C) Leak Test To prevent gas leaks, coat all external thread with compound or wrap teflon tape around the pipe thread.  Install a manual globe valve in the gas line at an easily accessible location within safe limits. Make sure all operators know where the gas supply is and how to turn off the gas supply to the cooktop.
Page 13 For personal safety, this equipment must be properly grounded, please read the following carefully. The power cord for this equipment is equipped with a three-prong grounded plug for use with a standard three-prong grounded wall outlet to minimize the potential for electric shock hazard. If you encounter a standard two-prong wall outlet, please contact us or replace it with a properly grounded three-prong wall outlet.
Page 14: Using The Gas Cooktop
Using the Electric Fireplace How to choose burners and pans? To improve efficiency and reduce gas consumption, choose the appropriate pots and pans based on the diameter of the burner. Avoid flames sticking out of the bottom of the pan (Refer the table below).
Page 15 Gas Burners Gas flow to the burners is adjusted by turning the knobs which control the valves. Turning the knob so that the indicator line points to the symbols printed on the panel achieves the following functions: It will permit the rapid boiling of liquids when knob is rotated to the max position, but the ...
Page 16: Cleaning & Maintenance
Cleaning & Maintenance IMPORTANT: Disconnect the device from the power source before cleaning and 、 maintenance. It is recommended to clean the appliance after it has cooled down, especially the interior of the enamel.  Avoid leaving alkaline or acidic substances on the surfaces, such as lemon juice and vinegar.
Page 17 Triple Ring Burner  The triple ring burner must be correctly positioned (Refer Fig.11); the burner rib must be entered into ligament as shown by the arrow.  The burner correctly positioned must not be able to rotate (Refer Fig.12), then position the cap "A"...
Page 18: Troubleshooting
Troubleshooting Before calling service team for support, please check the following troubleshooting tips: Cause Solution Check that the gas and electricity supply is not It may occur that the cooktop does interrupted, especially that the mains gas valve is not work normally. open.
Page 19: Warranty
Warranty This warranty applies to products sold by Dalxo in the U.S. It expressly applies to a single product only. Dalxo products are warranted for one year after purchase against defects in material and workmanship. Please save your receipt as proof of purchase is required to make a warranty claim.
Page 20 If you have a claim under this warranty, please contact : support@dalxo.com. For faster service, please provide the model number, serial number, and receipt ready for the...
