Page 1: Table Of Contents
29. Compliance standards 30. Technical support and troubleshooting 1. WELCOME Thank you for choosing this quality Ektor product. This manual is intended to help you install this product in a way that ensures the safety of yourself and others. Whilst this Ektor product is designed...
Page 2: Overview
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 2. OVERVIEW Ektor Generation III platform introduces you to a new era of emergency lighting control. With years in the making, the third generation platform builds on the Ektor product ranges’ increasing quality, reliability and performance.
Page 3: Installation
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 4. INSTALLATION Ektor Ledfire recessed emergency luminaires can be installed in either accessible or inaccessible ceiling cavities. To install the Ledfire please follow the steps listed below: Remove the product from the box and inspect it for any damage. If you believe the product to be damaged or otherwise unsound, DO NOT install the product.
Page 4: Maintaining Your Ledfire Luminaire
DRAFT WARNING The Ektor Ledfire Emergency Luminaire is connected to an unswitched active during normal operating conditions. When disconnected from the mains supply, the Ledfire is powered by a LiFePO4 battery operated inverter. Due to this, care should be taken when replacing either the battery or dish.
Page 5: Battery Life
AS/NZS 2293 or an equivalent standard can have a positive effect on the battery performance as long as 12 discharge cycles per year is not exceeded. 9. POWER AND BATTERY CHARGE The Ektor Generation III platform uses smart battery charging technology which reduces power consumption and increases battery life. Max charge voltage...
Page 6: Wireless Daughterboard
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 10. WIRELESS DAUGHTERBOARD The Ledfire inverter supports an optional wireless daughterboard. The driver must be disconnected from mains and battery must be removed, before installing or changing any expansion module. More information and a list of other accessories can be found in the Wireless design and installation guide.
Page 7: Self-Test Wiring/ Central Battery System
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 11. SELF-TEST WIRING/ CENTRAL BATTERY SYSTEM Installer wired Prewired Figure 6: Inverter standard wiring diagram The inverter can be used in an automatic self-test mode which reduces the need for a test switch timer. The self-test ability automatically disables if the unit is wired to DALI or the wireless daughterboard is attached.
Page 8: Using The Inverter With A Sensor
Battery 3000mAH 2 Cell LiFePO4 to suit Ledfire Pro & Ult EV-3000mAh-6.4V-LiFePO4 01303 Ledfire inverter antenna EV-LEDFIRE-ANT 02111 Ledfire strain relief cover EV-LEDFIRE-EXTENSION-LOOM 02112 Wireless daughterboard EV-WIFI-DAUG 06118 Antenna extension EV-ANTENNA-EXTE 06125 Easy commissioning module - DALI EV-ECM-DALI 05304 Easy commissioning module - Ektor EV-ECM-EKTOR 05305...
Page 9: Lead And Cable Accessories
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 16. LEAD AND CABLE ACCESSORIES The following cord-sets can be ordered and attached to the inverter depending on the site requirements. CORD-SET LENGTH PRODUCT CODE DESCRIPTION 2.4M 00709 Wire By Click 5-Pin Lead L1025/5 2.4M 00707 Wieland Plug GST18I5S B1 ZR1 S PB02...
Page 10: Non Maintained / Maintained Jumper
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 18. NON MAINTAINED / MAINTAINED JUMPER A user can select the mode of operation for the Ledfire inverter. If the inverter is using a switch input this is disregarded and not used. INDICATOR STATUS DESCRIPTION...
Page 11: Self-Test Indicator Leds
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 20. SELF-TEST INDICATOR LEDS The table below shows the operation of the Ledfire status indicators: INDICATOR DESCRIPTION YELLOW Device is performing a duration test 2sec ON / 2sec OFF YELLOW Last duration test passed. The duration was met when last run. 4sec ON / 1sec OFF Test ran less than five days ago YELLOW...
Page 12: Product Specifications
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 22. PRODUCT SPECIFICATIONS LEDFIRE DISH LEDFIRE DISH (02101) 16mm LEDFIRE PRO DISH (02102 & 02104) 26mm 140mm LEDFIRE ULTIMATE DISH (02103) DRAFT 76mm 84mm 140mm LEDFIRE / INVERTER Ledfire inverter with wireless daughterboard and antenna attached. LEDFIRE INVERTER (01201) LEDFIRE PRO INVERTER (01202) AND LEDFIRE ULTIMATE INVERTER (01203) 27mm...
Page 13 Maximum power <7W LEDFIRE ULTIMATE Maximum power <10W NOTE: Power ratings stated are the maximum power drawn whilst in maintained mode operation and charging a battery. For power ratings in other configurations and operating modes please refer to the Ektor website.
Page 14: Australian Emergency Classification
If you choose to expose the Ektor emergency products to such harsh operating conditions, Evolt may not honour any warranty on the life of the batteries or the dish. This Ektor emergency product is designed to undergo regular discharge tests but it is recommended that the intervals between consecutive tests are not less than two weeks.
Page 15: Testing Precautions
26. TESTING PRECAUTIONS When the Ektor emergency product is permanently connected to the mains supply you will need to allow 24 hours to charge its battery. Once the battery is fully charged you will need to conduct a manual discharge test as per the requirements of AS/NZS 2293 or other relevant standards.
Page 16: Warranty Information
Australian Competition and Consumer Act and other Australian laws. Ektor products are warranted in Australia for a period of 12 months from the date of delivery of the product, provided that the products are properly stored, installed, used and maintained in accordance with the DRAFT instructions contained within their manual.
Page 17: Compliance Standards
LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS 29. COMPLIANCE STANDARDS STANDARD TITLE Australian/ New Zealand AS/NZS 2293-3:2005+A1:2010 Emergency escape lighting and exit signs for buildings. Part 3: Emergency escape luminaires and exit signs. Standards AS/NZS 60598-2-22:2005 Luminaires Part 2.22: Particular requirements - Luminaires for emergency lighting (IEC 60598-2-22, Ed.
Page 18 LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS DRAFT...
Page 19 LEDFIRE / PRO / ULTIMATE EMERGENCY INSTALLATION INSTRUCTIONS DRAFT...
