How to install your Small Digbeth Latch
We recommend fitting is carried out by a suitably qualified tradesman.
Please note, this product is rear-fixed so please ensure this is suitable for your application.
Latch - x1
Snap off screws - x4
-
Appropriate safety equipment i.e. safety glasses
-
Spirit level
-
Drill
-
Screwdriver
-
Tape measure
-
Pencil
0121 359 2111 | armacmartin.co.uk | sales@armacmartin.co.uk
Contents
Advertisement
Table of Contents
Summary of Contents for ARMAC MARTIN Small Digbeth Latch
- Page 1 How to install your Small Digbeth Latch We recommend fitting is carried out by a suitably qualified tradesman. Please note, this product is rear-fixed so please ensure this is suitable for your application. Contents Latch - x1 Snap off screws - x4 Tools Required Appropriate safety equipment i.e.
- Page 2 Step One Mark Holes Mark out the fixing holes using the hole pattern shown below. Step Two Drill Holes Drill holes with a 4mm drill. Step Three Insert Screws Cut the rear fix M4 screws to the appropriate size for the cabinet. Place M4 snap off screws into holes from the inside of the cabinet.
- Page 3 Step Four Fix Latch Offer up the cabinet latch to the M4 snap off screws and fix to the cabinet securely. Finish Care & Cleaning Thank you for purchasing your Brass Latch from Armac Martin. Our products are of the finest quality and hand finished. Please follow the below care guide to maintain the condition of the product.
- Page 4 How to install your Large Digbeth Latch We recommend fitting is carried out by a suitably qualified tradesman. Please note, this product is rear-fixed so please ensure this is suitable for your application. Contents Latch - x1 Snap off screws - x4 Tools Required Appropriate safety equipment i.e.
- Page 5 Step One Mark Holes Mark out the fixing holes using the hole pattern shown below. Step Two Drill Holes Drill holes with a 4mm drill. Step Three Insert Screws Cut the rear fix M4 screws to the appropriate size for the cabinet. Place M4 snap off screws into holes from the inside of the cabinet.
- Page 6 Step Four Fix Latch Offer up the cabinet latch to the M4 snap off screws and fix to the cabinet securely. Finish Care & Cleaning Thank you for purchasing your Brass Latch from Armac Martin. Our products are of the finest quality and hand finished. Please follow the below care guide to maintain the condition of the product.
