Summary of Contents for Tomahawk eJXPC50
- Page 1 ELECTRIC PLATE COMPACTOR Operations Manual YEAR...
-
Page 2: Table Of Contents
Table of Contents 1. SAFETY INFORMATION - Fire Safety - Operating Safety - Service Safety - Electric Motors 2. EQUIPMENT DATA - Product Diagram - Compactor Specifications 3. COMPACTION - Reasons for Compaction - Compaction Specification - Applications 4. OPERATION - Pre Start Checks - Operating Instructions - Starting the Motor... - Page 3 Register Your Equipment Thank you for purchasing TOMAHAWK equipment! Your product is covered by the TOMAHAWK Warranty policy, but in order to activate your warranty, we need you to register your product. In addition to activating your equipment warranty, product registration will grant you access to important product updates, streamlined customer service and more.
-
Page 4: Safety Information
Tomahawk Power. The information contained in this manual is based on machines in production at the time of publication. Tomahawk Power reserves the right to change any portion of this informa- tion without notice. -
Page 5: Fire Safety
1.2.2 NEVER use accessories or attachments for this equipment, which are not recommended by TOMAHAWK POWER. Damage to the rammer and/or injury to user may occur. -
Page 6: Service Safety
WARNING responsibility of the operator to ensure that he/she fully understands how to operate this equipment safely. If you are unsure about the safe and correct use of the eJXPC50 Plate Compactor, consult your supervisor. 1.3.1 DO NOT attempt to clean or service machine while it is running. Rotating parts can cause severe injury. -
Page 7: Electric Motors
1.5 Plugs The eJXPC50 Plate Compactor is intended for DIY or site usage, the following plug types are supplied/fitted to the product: 15 amp rated 120 volt plug type. THIS PRODUCT MUST BE GROUNDED... -
Page 8: Equipment Data
1.8 Health and Safety 1.8.1 Vibration Some vibration from the compacting operation is transmitted through the handle to the operator's hands. Refer to specifications & technical data for vibration levels and usage times (recommended maximum daily exposure time). DO NOT exceed the maximum usage times. -
Page 9: Compactor Specifications
2.2 Product Dimensions 2.3 Compactor Specifications Model eJXPC50H Power (HP / kW) 2.0 / 1.5 Motor RPM 2800 Nominal Voltage (v) Full Load Current (A) 14.2 Motor Protection Rating IP44 Vibrator Force (kN) Frequency (Hz) Maximum Travel Speed (m/min) Usage Time (Mins) Noise (dBA) Weight (lbs / kg) 110 / 50... -
Page 10: Compaction
The following pre start-up inspection must be performed before the start of each work session or after every four hours of use, whichever is first. Please refer to the service section for detailed guidance. If any fault is discovered, the eJXPC50 plate compactor must not be used until the fault is rectified. -
Page 11: Operating Instructions
If necessary, use a suitable rope attached to the eJXPC50 at a low point on the chassis, to allow a helper to take part of the eJXPC50's weight. Work up and down a slope not across. -
Page 12: Service & Maintenance
The Electric Plate Compactor is designed to give many years of trouble free operation. It is recommended that an approved TOMAHAWK POWER dealer or service center carries out all major maintenance and repairs. Always use genuine TOMAHAWK POWER replacement parts, the use of spurious parts may void your warranty. -
Page 13: Maintenance Record
For your convenience we have provided this space to record relevant data about your plate compactor. 5.5 Replacement Parts For replacement parts and technical questions visit www.tomahawk-power.com or scan the QR code on the front of this manual. • Not all equipment components are available for replacement. The illustrations within this manual are a convenient reference to the location and position of parts in the assembly sequence. -
Page 14: Troubleshooting
Contact Tomahawk Power. down Verify the load has not changed. Verify equipment Load increased hasn't got tighter. If fan application verify the air low hasn't changed or Contact Tomahawk Power Defective capacitor Contact Tomahawk Power Faulty stationary switch Contact Tomahawk Power... -
Page 15: Warranty
Your new Electric Single Direction Plate Compactor is warranted to the original purchaser for a period of one-year. (12 months) from the original date of purchase. The Tomahawk Power warranty is against defects in design, materials and workmanship. The following are not covered under the warranty: 1. -
Page 16: More Compaction Tips
8. MORE COMPACTION TIPS 8.1 Soil Drop Test: Soil preparedness refers to the “wetness” of the dirt or soil. Soil needs to be 50% dry and 50% wet, before starting compaction. A simple “hand test” can deter- mine this. Pick up a handful of soil with your hand and squeeze the dirt. Observe whether the soil is powdery or if it breaks apart when dropped. - Page 17 8.3 Compaction Terms 8.3.1 Cohesive soils: Clays and mixes have a particular particle size of less than .003” or .002” and are typically classified as cohesive soils. This type of soil is primarily used for retaining pond beds and mound fills. These soils are dense due to the strongly bound mo- lecular attraction.
- Page 18 8.3.4 Static force: Found in the deadweight of machines, static force applies pressure downward on soil surfaces. As a result, soil particles compress in the topsoil layer. 8.3.5 Vibratory force: This force is engine-driven, creating a downward force, in addition to the machine's static weight.
- Page 19 Offering adjustable pressure from 20 to 70 PSI, Tomahawk Battery Sprayers are perfect for spraying residential and commercial areas! Powered by a superior 7Ah lithium battery with up to 11 hours of life, spray 6000 ft² in 10 minutes or less! Item #: eTPS18 4.75 GALLON BATTERY...
- Page 20 Item #: JXPT46K 24” - 36” - 46” POWER TROWELS www.tomahawk-power.com...
- Page 21 Lose the manual pump and gain the power to spray 15,000 ft² in 10 minutes or less while maintaining constant, adjustable pressure from 50-435 PSI with your ideal concrete sealant, cure, top cast, form release, and more! Item #: TCS6.5 6.5 GAL MOTORIZED CONCRETE SPRAYER www.tomahawk-power.com...
-
Page 22: Catalog And Coupon
3 Year Engine Warranty & 1 Year Product Warranty 3 Year Engine Warranty & 1 Year Product Warranty HAVE QUESTIONS? HAVE QUESTIONS? Contact us. We’re here to help! Contact us. We’re here to help! Email us at sales@tomahawk-power.com Email us at sales@tomahawk-power.com... - Page 23 1 Year Product Warranty 3 Year Engine Warranty & 1 Year Product Warranty 1 Year Product Warranty * All coupons in this manual are valid only for orders placed on www.tomahawk-power.com, unless otherwise noted. Coupon codes ASSEMBLED IN THE ASSEMBLED IN THE may only be used once per customer and may not be combined with any other offer.
- Page 24 With same day shipping and faster delivery times, count on Tomahawk to keep you powered throughout the day! With long lasting parts and engines, Tomahawk equipment will be the star of your fleet for years to come. Visit www.tomahawk-power.com to get started today!
