Limente DELTA Assembling Instructions

LIMENTE DELTA | MINI | MINI-2 USB | MINI-3 POP | MIRO
assembling instructions, asennusohje, monteringsanvisning, monteringsvejledning, monteringsanvisning, paigaldusjuhend, istruzioni di montaggio
Technical data is printed on package
Tekniset tiedot ovat paketin päällä
Teknisk data er trykket på emballasjen
Teknisk information är tryckt på paketet
Teknisk informasjon är trykt på emballagen
Tehnilised andmed on pakendil
I dati tecnici sono stampati sulla confezione
Mini-1, S/S
PNC: 630481 PNC: 630581
max. max.
16 A 16 A
Snro: 2407101
PNC: 630584
max.
16 A
Delta
PNC: 630381
max.
16 A
Snro: 2407100
EN - NOTE!
Before installation assure online at www.limente.com that you are using the latest assembling instruction.
The socket must be installed against two closed surfaces (e.g. wall and cabinet) see picture 1. The open back part of socket must be closed after
installation. Power feed cable must be installed from back part, either from wall or cabinet.
Mini-2 USB includes two USB connectors.
Mini-3 POP includes two sockets, two USB connectors and a loudspeeker. To be able to listen for example music you can connect your mobile phone by
bluetooth to the the device.
To connect a phone to Mini-3 POP keep the button C (pic. 7) pressed for 3 seconds until you hear a voice. The Bluetooth connection of Mini-3 POP is now
activated. Activate bluetooth from your phone, choose Mini-3 POP from the list of devices and activate it. If you want to change the connected device
just press the button C for 3 seconds to reset and activate the Bluetooth connection of Mini-3 POP.
Installation must always be done by an authorized person following valid local regulations.
Mini-2, S/S Mini-2 USB, S/S
PNC: 630981
max.
16 A
Snro: 2407102 Snro: 2407116
Mini-2, white Mini-2 USB, white
PNC: 630984
max.
16 A
Snro: 2407108 Snro: 2407117
Kankiraudantie 1, 00700 Helsinki | info@limente.com | www.limente.com
Mini-3, S/S Miro-3 POP, S/S
PNC: 630681 PNC: 631181
max. max.
16 A 16 A
Snro: 2407103 Snro: 2407118
Mini-3, white Miro-3 POP, white
PNC: 630684 PNC: 631184
max. max.
16 A 16 A
Snro: 2407109 Snro: 2407119
2016
Miro-2, S/S
PNC: 630781
max.
16 A
Snro: 2407114
Miro-2, white
PNC: 630784
max.
16 A
Snro: 2407115
