Summary of Contents for iRex IR BOX-IN
- Page 1 drawer systems Solutions...
- Page 2 IREX BOX IREX SYSTEM In Box ( IR BOX-IN) Specifications Damping Loading capacity : 40kg ● Adjustment range : top/bottom +/- 2mm, left right +/-1.5mm ● Back plate height : 70mm ● Color : Metalic Silver ● Drawer( IR BOX-NS)
- Page 3 * Front plate for In box : Inner shell - 85 Drawer's diagram Location of side plate mounting ( In box) Drawer's diagram Location of side plate mounting (Drawer) Drawer's diagram Location of side plate mounting ( Gallery) IREX BOX...
- Page 4 Front panel assemble and disassemble method max loading capacity Front panel adjustment up/down +/- 2mm , L/R +/- 2mm IREX BOX installation and decomposition method 1. Lift out the rails on both sides. 2. Place the wood box on top of the slide 3.
- Page 5 MEMO IREX BOX...
-
Page 6: Smart System
SMART SYSTEM In Box (SM BOX-IN) Specifications Damping Loading capacity : 40kg ● Adjustment range : top/bottom +/- 2mm, left right +/-1.5mm ● Back plate height : 66mm ● Color : Metalic silver ● Drawer (SM BOX-NS) Specifications Damping Loading capacity : 40kg ●... - Page 7 Foundation size 1. Bottom plate 2. Back plate (In, Drawer) Tailor's measure / 500mm drawer / Outer reference Item name Inner shell -87 600mm 1000mm Rail + 8 3. Back plate ( Gallery) Base plate (15 T standard) 494(W) x 508(D) 894(W) x 508(D) Drawer 483(W) x 66(D)
- Page 8 max loading capacity 30kg Use various space in the drawer IN Box installation method ① fixed bracket ③ fixing bolt ② Aluminum panel Front panel adjustment range ● How to install the front panel in a drawer front panel disassemble or assemble modifying vertically modifying horizontally Gallery Drawer (SM Box-GA)
- Page 9 MEMO SMART BOX...
-
Page 10: Installation
Damping Under Rail (Full Extension) IR-UD RAIL ※ Easy assemble and disassemble Fix the bolt in catcher bottom hole part Cabinet Max loading Model Rail Capacity length IR-UD 250 30kg L+20mm IR-UD 300 30kg L+20mm IR-UD 350 40kg L+20mm IR-UD 400 40kg L+20mm IR-UD 450... - Page 11 Damping Under Rail (Full Extension) IREX-UD RAIL ● New Soft Closing Damper Installation +1.0 A-41 13~16 -0.5 L1 = Rail length + 20mm side panel +0.1 A-41 13~16 -0.5 36.1 DAMPING UNDER RAIL...
- Page 12 Damping Under Rail (Full Extension) 댐핑언더레일(Full Extension) IREX-UD RAIL(250mm only) Installation +1.0 (A-41) 13~16 -0.5 250MM 36.1 2-∅6DP 12 side panel A VIEW +1.0 (A-41) 13~16 -0.5 Rail Rail length caution: only 250mm Minimun distance DAMPING UNDER RAIL...
- Page 13 Ball Bearing Slide (Full Extension) IREX-BR SLIDE Installation Size : 250mm~500mm(250mm~550mm) 9.5X4.5 Side panel Drawer cabinet assemble drawer assemble 4.5X9.5 9.5X4.5 Traval REMARKS +0.5 12.7 +0.5 12.7 -0.0 247.5 -0.0 12.7 12.7 297.5 347.5 397.5 447.5 497.5 547.5 BALL BEARING SLIDE...
- Page 14 Damping Ball Slide (Full Extension) IREX-DB SLIDE Installation Side panel 1 2 .7 + 0 . 5 1 2 .7 + 0 . 5 Drawer Drawer cabinet assemble Drawer Cabinet Cabinet drawer assemble Travel Travel 12.7 12.7 3- 4.5 3-4.5X9.5 9.5 4.5...
- Page 15 Damping Ball Rail (NEW IREX-DB) NEW IREX-DB SLIDE Installation Size : 300mm~600mm(damping 300mm~600mm) - NEW TYPE ※ Caution - carefully fixing the bolt as of dwg. 4.5X10.3 4.5X9.3 Side panel 측판 16 25.2 cabinet assemble 캐비넷 부 Drawer Travel 4.5X9.3 4.5X9.3...
- Page 16 삼성정밀공업(주) www.irex.co.kr Head office, Factory : 167, Bongsu-daero, Seo-gu, Incheon, Korea Tel : 82-70-7101-9352 / Fax : 82-32-577-3366 e - mail: jhonkim@irex.co.kr irex@irex.co.kr Rev.113590831...
