Summary of Contents for Consolidated Ruckus 2111
- Page 1 TV Service TV Service Quick-Start Kit...
- Page 2 THANK YOU for choosing TV service from Consolidated Communications. With local, national and music channels, plus Premium High-Definition Channels, Video on Demand, Digital Video Recorder (DVR) and HBO, Showtime, Cinemax and Starz, our TV service provides you with leading-edge television...
- Page 3 Quick-Start Kit components • Set-top box • Ruckus 2111/7111 Multimedia Wireless Adapter Note: If your initial TV service installation included a Ruckus Wireless unit, this Quick-Start Kit will allow you to add additional set-top boxes to your service. If your TV service does not already include a Ruckus Wireless unit, please call to schedule an appointment for one of our technicians to install additional set-top boxes.
- Page 4 Set-top box system configuration 1. Power button. 2. Link – confirms that the set-top box is connected to the network. 3. USB Port – this feature is non-functioning. 4. DVR – displays when a program is recording. 5. HD – indicates the set-top box is set to 720p or higher. 6.
- Page 5 TV Service How to connect the set-top box to your TV • Cabling Option 1: HDMI. Connect one end of an HDMI cable (supplied by customer) from the HDMI connection on the back of the set-top box. Connect the other end of the cable to the HDMI “IN” port on your TV. •...
- Page 6 Providing TV service with Ruckus Wireless and Entone Amulet set-top boxes Ruckus 2825/7811 Wireless Base Unit Router Ruckus 2111/7111 Wireless Receiver Set-Top Box Television...
- Page 7 2. To configure your new Ruckus 2111/7111 Wireless Receiver, connect the Ethernet cable between the LAN port of the Ruckus 2111/7111 and the WAN port of the Ruckus 2825/7811 Wireless Base Unit. Ethernet 3. When the Ruckus units have completed the configuration, you will see the light combinations shown below.
- Page 8 4. After connecting your new set-top box to your TV, connect an Ethernet cable from the LAN port on your Ruckus 2111/7111 to the Ethernet port on the set-top box. Then power both units on. Ethernet Cable 5. You will see all green lights on the Ruckus 2111/7111 when everything is operating properly, and TV programming will begin to display.
