MR RESISTOR
WI-FI CARD FOR CONTROLLING A DEVICE THROUGH THE WISE DIRECT APP
Product code
MOD01WIFIMR
WI-FI CARD CONNECTION
Connector
MOD01WIFIMR
TELECO DEVICE*
* Follow product device manual for configuration
TECHNICAL SPECIFICATIONS
MOD01WIFIMR
Wise House, 21 Lydden Road, Wandsworth, London, SW18 4LT
Telephone: 020 8874 2234 Fax: 020 8871 2262
www.wisecontrols.com
Power supply
Max. output power
Operating temperature range
Protection rating
Frequency band
This document is the property of Teleco Automation Srl, which reserves all reproduction and copyrights
info@wisecontrols.com
Warning: before insert the MOD01WIFIMR into the connector turn the
power supply off.
5-12Vdc
500mA
-20°C +50°C
IP20
2.4GHz
DOC.: T991.01
DATE: 03/08/22
Advertisement
Table of Contents
Summary of Contents for MR. RESISTOR MOD01WIFIMR
- Page 1 WI-FI CARD FOR CONTROLLING A DEVICE THROUGH THE WISE DIRECT APP Product code MOD01WIFIMR WI-FI CARD CONNECTION Connector MOD01WIFIMR Warning: before insert the MOD01WIFIMR into the connector turn the power supply off. TELECO DEVICE* * Follow product device manual for configuration TECHNICAL SPECIFICATIONS 5-12Vdc...
- Page 2 INSTALLATION Download the Wise Direct APP from the App Store or Google Play or using the IOS or Android QR Code. Check compatibility with your device first. QR Code IOS QR Code Android CONFIGURATION Scan the QR code with Digit this password 000000 your phone camera.
- Page 3 WISE - DIRECT PRODUCT LABEL Apply this label to the device case. The product label it can be find in the packaging. RESET OF THE PASSWORD TO FACTORY DEFAULT 5 s) keep it pressed the LED flashes fast Within the power ON... Press 1 time the P button on the WI-FI board and keep it pressed for 5 s.
- Page 4 WARNING IMPORTANT! READ CAREFULLY THESE INSTRUCTIONS BEFORE INSTALLING AND COMMISSIONING THE PRODUCT. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. PRODUCT INSTALLATION: The product at issue must be installed, commissioned and maintained only by licensed and authorised people, respecting the laws concerning the electrical installations. The manufacturer is not responsible for any damage due to wrong installation or improper use.
