(ER/ET/WR/WT)
Quick Start Guide
ER01/ ET01
WR01/ WT01
Full User Manual
Rev 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the ER01 and is the answer not in the manual?

Questions and answers

Summary of Contents for EZCast Pro ER01

  • Page 1 (ER/ET/WR/WT) Quick Start Guide ER01/ ET01 WR01/ WT01 Full User Manual Rev 1.0...
  • Page 2: What's In Box

    9. Supports Web settings through Ethernet connection and CMS (Central Management System) installed for Win/Mac OS connecting to the L2 Switch incorporated. What’s in Box RST PWR LINK MODE Product: ER01/ ET01/ WR01/ WT01 Screw X4 Holder X2 Power Cable USB-A data cable RX/TX Adapter for IR...
  • Page 3 Hardware Overview for ER01 RJ45 DC IN HDMI OUT AUX OUT IR IN USB K/M RS232 RST PWR LINK MODE 8 9 10 11 12 13 14 15 17 18 1. DC IN port: 12V/1A power supply is required. 2. HDMI OUT port: Connect to the monitor for display.
  • Page 4 18. Switch mode: Display the screen to ER01 with the same channel ID. 19. Splitter mode: Direct connect to ER01 for 1 to 1 extending display or connect through a switch for 1 to N multicast. No channel ID should be set.
  • Page 5 Hardware Overview for WR01 RJ45 DC IN HDMI OUT AUX OUT IR IN USB K/M RS232 8 9 10 11 12 13 14 15 17 18 RST PWR LINK MODE 1. DC IN port: 12V/1A power supply is required. 2. HDMI OUT port: Connect to the monitor for display. 3.
  • Page 6 Hardware Overview for WT01 RJ45 DC IN HDMI OUT HDMI IN AUX IN IR OUT USB PC RS232 9 10 11 12 13 14 15 16 18 19 RST PWR LINK MODE 1. DC IN port: 12V/1A power supply is required. 2.
  • Page 7 Hardware Installation for ER/ ET 1. Position the toggle switch to the same mode (SW/ SP) on both ER01 and ET01. 2. Connect power to 12V/1A and a monitor to display output on ER01. 3. Connect power to 12V/1A, a monitor for loopback, and a device to input on ET01.
  • Page 8 Hardware Installation for WR/ WT 1. Position the toggle switch to the same mode (SW/SP) on both WR01 and WT01. 2. Connect power to 12V/1A and a monitor to display output on WR01. 3. Connect WR01 and WT01 by the HDMI cable to pair. The STA signals keep flashing until pairing completed.
  • Page 9: Channel Adjustment

    Central Management System Download Central Management System (CMS) to real-time monitor and efficiently operate all EZCast ProAV devices under the same network. For more information, please refer to our website: www.ezcast-pro.com or watch demo videos in our YouTube Channel (EZCast Pro).

This manual is also suitable for:

Et01Wr01Wt01Er02
