Summary of Contents for SeaViewer Surface Console
- Page 1 SURFACE CONSOLE ALL DOCUMENTATION IS AVAILABLE ON OUR WEBSITE www. SeaViewer.com Seaviewer Cameras Inc Tampa FL 33619 -1-813-242.6160...
- Page 2 :POWER ON 1. Make sure the power switch is in the neutral position (middle) 2. Plug in the Seaviewer Camera and Camera Power to the lower right portion of the panel. 3. If using “external power connection” connect external power.
- Page 3 (10amp). 1. Verify power is off 2. Connect the camera to the Surface Console 3. Connect external power if using that as the power source 4. Power on – Select external or battery using the On/Off switch 5.
- Page 4 DVR -Recorders are factory configured with or without overlay (GPS Option) based on the customers request. Seaviewer OEM recorders have the option for internal GPS function which eliminates the need for external overlay devices.
- Page 5 Typical Configuration with Recorder and Camera Typical connections / Shown with optional accessories CAMERA CONTROL BOX The HD camera connection has multiple cables on the control box. Dimmer Control – equipped if lights were ordered On/Off Switch – controls lights if lights were ordered On/Off Switch –...
- Page 6 Basic Operations of recorder - Full manual available on-line www.seaviewer.com Note: Seaviewer DVR has optional GPS Overlay available. 1. Turn console to Power ON. (Recorder will light when power is applied) 2. Note: there is a power switch on the side of the recorder which should be on.
- Page 7 F) The BATTERY CHARGER (110-240 Volt AC @ 50/60Hz) for the MAIN BATTERY is inside the foam. You may expect to power the Surface Console and a SeaViewer Camera for up to 8 hours with the MAIN BATTERY charged, depending on your choice of components. See the pages below concerning Battery Information to get a more accurate estimation.
