De Haardt 200.910 User Manual

Xtra.emergency button
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XTRA.EMERGENCY BUTTON
User Manual
Article No. 200.910
Document version:
Date:
1.4
2022-09-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 200.910 and is the answer not in the manual?

Questions and answers

Summary of Contents for De Haardt 200.910

  • Page 1 XTRA.EMERGENCY BUTTON User Manual Article No. 200.910 Document version: Date: 2022-09-06...
  • Page 2 Email: info@de-haardt.com All rights reserved. Safety All De Haardt’s products are designed as supplement to make karting safer, but cannot replace safe track procedures. If equipment fails, the normal operating procedure must still be adequate to safely operate the track.

  • Page 3: Table Of Contents

    Xtra.Emergency Button User Manual Table of Contents Getting started ............................4 What is in the box ............................ 4 Installation ..............................6 1.2.1 Mounting ............................... 7 1.2.2 Connecting ............................10 Operation ..............................11 Overview ..............................11 Indication LEDs ............................11 Configuration............................12 Accessing the web interface ........................

  • Page 4: Getting Started

    Xtra.Emergency Button User Manual 1 Getting started This manual provides one with all the information needed to install, configure and use the Xtra.Emergency Button. The Xtra.Emergency Button is a product that can be used to stop or to slow down go karts and does not disconnect electrical circuits of the go karts.
  • Page 5 Xtra.Emergency Button User Manual 3. Power over Ethernet injector Figure 3 - Power over Ethernet injector 4. Usage/warning board Figure 4 Usage/warning board v 1.4...

  • Page 6: Installation

    Xtra.Emergency Button User Manual 1.2 Installation Before installing the Xtra.Emergency Button, it is important to understand that the Xtra.Emergency Button is not able to stop or slow down go karts which are out of range. Therefore it is necessary to prevent any blind spots by using one or more Xtra.Black Boxes.

  • Page 7: Mounting

    Xtra.Emergency Button User Manual 1.2.1 Mounting The Xtra.Emergency Button can be mounted using 4 bolts or screws as shown in figure 5. The Xtra.Emergency button has 4 holes, 2 holes on each side. It is necessary to mount the Xtra.Emergency Button on flat surfaces to guarantee its functionality. By using 4 bolts or screws it is possible to hang the Xtra.Emergency Button on flat surfaces.
  • Page 8 Xtra.Emergency Button User Manual Mounting the Xtra.Emergency Button on a wall or fence with steel in it may result in loss of radio signal. Mounting the Xtra.Emergency Button to a wall or plate made of metal may result in radio dysfunctionality. Figure 6 - Wall blocking radio signals v 1.4...
  • Page 9 Xtra.Emergency Button User Manual The Xtra.Emergency Button instruction board can be mounted above the Xtra.Emergency Button with screws. It is recommended to place the Xtra.Emergency Button Board right above the Xtra.Emergency Button. This adds visibility and instructions to the Xtra.Emergency Button. Figure 7 Xtra.Emergency Button Instruction Board v 1.4...

  • Page 10: Connecting

    Xtra.Emergency Button User Manual 1.2.2 Connecting This chapter describes how to connect the Xtra.Emergency Button. Figure 8 - Xtra.Emergency Button 1. Ethernet connector: Used to provide power to the Xtra.Emergency Button through power over Ethernet and may also be used for Ethernet communication. The waterproof connector of the supplied Ethernet cable must be connected to the Ethernet connector of the Xtra.Emergency Button and the other end of the cable must be connected to the port labeled OUT on the power over Ethernet injector.

  • Page 11: Operation

    Xtra.Emergency Button User Manual 2 Operation 2.1 Overview The front of the Xtra.Emergency Button is provided with 6 LEDs around the push button. Figure 10 - Front with indication LEDs 2.2 Indication LEDs The 6 LEDs on the front of the Xtra.Emergency Button will light up the push button when the Xtra.Emergency Button has been powered on.

  • Page 12: Configuration

    Xtra.Emergency Button User Manual 3 Configuration The Xtra.Emergency Button can be configured using the products web interface. This chapter describes how to access the web interface and what the different settings are. 3.1 Accessing the web interface The web interface can be accessed using any device featuring a web browser. When the IP address of the Xtra.Emergency Button is entered into the address bar of a web browser, the products web interface will appear.

  • Page 13: Using The Web Interface

    Xtra.Emergency Button User Manual 3.2 Using the web interface The web interface is divided into 4 webpages: 1. Home: Provides an overview of the active general settings. 2. Setup: Allows the user to change the settings of the Xtra.Emergency Button. 3.

  • Page 14: Setup

    Xtra.Emergency Button User Manual 3.2.2 Setup The setup webpage allows the user to change the settings of the Xtra.Emergency Button. The webpage is divided into 3 sections: 1. LAN: Change the LAN settings. 2. EMBU SPD Mode: Change the function of the push button. Each section will be explained separately in this paragraph.

  • Page 15: Change The Lan Settings

    Xtra.Emergency Button User Manual 3.2.2.1 Change the LAN settings In the LAN section, two modes can be selected: Dynamic IP (default) and Static IP. When the Static IP mode is selected, the user must provide some network properties. After changing the LAN mode, the Xtra.Emergency Button needs to be restarted for it to take effect.

  • Page 16: Embu Spd Mode

    Xtra.Emergency Button User Manual 3.2.2.3 EMBU SPD Mode In the EMBU SPD Mode section, the function of the button can be changed from EV mode to fuel mode and vice versa. The Xtra.Emergency Button can be used to stop or slow down go karts. Besides it is also possible to configure the duration that the Xtra.Emergency Button will be active after the button has been pressed.
  • Page 17 Xtra.Emergency Button User Manual Changing the configuration from continuously sending to a specified duration may result in dangerous situations. Continuously sending is the default setting (duration 0). The default function of the Xtra.Emergency Button is to slow down all go karts to SPD 1.

  • Page 18: Run Time Statistics

    3.2.3 Run Time Statistics The Run Time Statistics webpage provides statistics for support purposes. When there is a problem with the Xtra.Emergency Button, a support employee of De Haardt can use this data to identify the issue. Figure 17 - Run Time Statistics webpage...

  • Page 19: System Tools

    Xtra.Emergency Button User Manual 3.2.4 System Tools The Systems Tools webpage allows the user to perform a firmware update. There are two options to upgrade to a new firmware version: perform a manual firmware update or check for online firmware updates.

  • Page 20: Perform A Manual Firmware Update

    5. Restart the Xtra.Emergency Button. This can be done by temporarily removing the power from the device or by using the restart button on the webpage. Do not select any file that is not supplied by De Haardt. Doing so can cause the Xtra.Emergency Button to stop working.

  • Page 21: Check For Online Firmware Updates

    Haardt. The user can then have the Xtra.Emergency Button check for online firmware updates in the following way: 1. In the Update Server section, enter the update IP address and update port supplied by De Haardt. 2. Tick the checkbox to instruct Xtra.Emergency Button to check for updates.

  • Page 22: Technical Specifications

    6,5W. According to the standard, an Ethernet cable with a maximum length of 100 meters may be used. However, De Haardt recommends using the supplied 5- meter-long cable. The side of the supplied Ethernet cable that connects to the power over Ethernet injector as well as the power over Ethernet injector itself are NOT waterproof.

  • Page 23: Support

    Xtra.Emergency Button User Manual 5 Support For support, one can contact the support department of De Haardt by email: support@de-haardt.com v 1.4...
