SW 11 ACTIVE - SW 11 PASSIVE
Congratulation on your purchase of your new SW-Series Subwoofers.
IMPORTANT: Before installation of your spare-wheel-subwoofer, we recommend to read the owner's manual
carefully and to follow the instructions regarding connection and fitting exactly.
ATTENTION: Pay attention to advices and instructions of the car manufacturer.
IMPORTANT: Your proof of purchase is evidence of warranty claim for repair or replacement. Keep your proof
of purchase, manual and original packaging.
ATTENTION: Use of sound components can impair your ability to hear neccessary traffic sounds and may
constitute a hazard while driving your automobile.
Audio System Germany accepts no liability for hearing loss, bodily injury or property
damage as a result of use or misuse of our products. We recommend installing the equipment by an
authorized service center or dealer. A professional fitting and connection is the requirement for further
warranty and perfect sound.
SW
- 27,5cm Active-Spare-Wheel-Woofer with extremely heavy housing
- PRS (Phantom-Resistor-Simulation) impedance simulation
- Extremely wide input sensitivity from 0,1 to 10 V
- Multi-Way-Protection-Circuitry: overheating, overcurrent, short circuitry & DC protection
- High-Power-Input (normally OEM radio) with automatically „Turn-On"
- Cable-High-Level-Input or Cinch-Input
- Included RTC SW wired remote for Gain, Bass Boost, Low-Pass-Filter and Phase
SW
4
SW
equipment SW 11 ACTIVE
technical dat a SW 11 active
Technical dat a SW 11 passive
10 - 16 V
150 W
> 92 dB
50 - 150 Hz
20 Hz
0° / 180°
35 Hz ~ 150 Hz (+/-1 dB)
< 0,3%
0 bis +12 dB
25A
0,1 V ~ 10 V (+/- 5%)
360(D) x 135(H) mm
2x 175 W
35 Hz ~ 150 Hz (+/-1 dB)
2x 2 Ohm
360(D) x 135(H) mm
