Summary of Contents for Alpha Bidet UX-T Pearl
- Page 1 UXT Pearl...
-
Page 2: Table Of Contents
Content Safety instructions Technical specification List of materials Technical drawing Parts identification Toilet installation Preparation Automatic lid open/close Foot sensor Maintenance 1. Cleaning the unit 2. Spray nozzle maintenance and care Maintenance & troubleshooting 1. Filter maintenance 2. Manually flushing the toilet 3. - Page 3 IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: 1. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
-
Page 4: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION – Indicates that failure to follow the instruction may cause body injury or property damage. 1. Do not install or use the product in wet places as steam room etc. 2. It is recommended to use water-proof electrical outlet which should be installed in a place where is not easily to get wet. -
Page 5: Technical Specification
Technical specification Model UX-T Rated voltage 110V-120V, 50/60Hz Rated power 1170W Main Unit Water proof IPX4 Power cord length About 7ft Flush volume 1.28 gpf Flushing mode Siphonic jet Rough-in 12" Toilet Outlet outside diameter 4" Drainage method S-trap 0.18 MPa (dynamic pressure, flow rate of 5.81+ Water pressure range gal/min or 22.0+ L/min) - 0.8 MPa (static pressure) - Page 6 Model UX-T Deodorizer Deodorization method Photocatalyst-free 6-level adjustment Surface temperature Heating power Heated seat After 10 minutes of use, the seat temperature Burn protection will automatically drop slowly to a low level Seat sensor, Temperature sensor, Thermostat, Safety device Thermal fuse, Leakage protection plug Night light assembly Intelligent, Always on, Always off To avoid interference when used by multiple users...
-
Page 7: List Of Materials
List of materials Main Unit Remote Control and Wall Mount Sealing Flange Installation Cardboard Installation Manual Thank you for choosing our products. Please read the instructions carefully before installation and keep it available for future maintenance or reference. Installation Manual Remote Manual Battery Box 7/8"... -
Page 8: Technical Drawing
Technical drawing 27.6" The drawing is for reference only, and we reserve the right to modify the product appearance. -
Page 9: Parts Identification
Parts identification Left side Bumper Seat Control knob Ceramic toilet Right side Nozzle shield Dryer shield Rear Front washing Remote washing control sensor Spray nozzle Foot sensor... -
Page 10: Toilet Installation
Toilet installation Precaution before installing 2. . Installation of angle valve (optional) If the existing angle shut-off valve at the Minimum dynamic working water wall is at least 8” off the center of the pressure: 0.18+ MPa (5.81+ gal/min or 22+ drain and uses either a 3/8”... - Page 11 4. Supply hose 6. . Ceramic toilet installation Using the appropriately sized supply hose, Install the sealing flange into drain outlet. connect the toilet inlet to the angle valve. Install the toilet by carefully lowering Tighten securely and ensure the rubber it into position over the drain.
-
Page 12: Preparation
Preparation 1.Turn on the angle valve slowly Check the threaded connections at each end of the supply hose for leaks. If leaks are found, shut off water, and re-connect the hose ensuring the o-rings are in place. Add teflon tape if needed. Once leak-free, open the angle valve completely. Angle valve 2. -
Page 13: Automatic Lid Open/Close
Automatic lid open/close * The Alpha UXT Pearl is equipped with a proximity sensor that can raise and lower the lid automatically. This function is disabled by default. Press and hold the OPEN/CLOSE LID button on the remote control for 5 seconds to enable it. 1. -
Page 14: Foot Sensor
Foot sensor * The Alpha UXT Pearl is equipped with a foot sensor that can perform a few functions. Trigger the sensor by touching the sensor area with your foot. This sensor is enabled by default. On the remote control, press and hold the STOP button and then press the FLUSH button to disable it. -
Page 15: Maintenance
Maintenance Spray nozzle maintenance and care Cleaning the main unit 1. . Nozzle cleaning Unplug the power cord before doing When no one is seated, turn the any cleaning or maintenance. knob clockwise to bring the nozzle out for manual cleaning. To clean the seat, lid, back housing, and other plastic components, only use a soft damp towel to wipe clean. -
Page 16: Maintenance & Troubleshooting
Maintenance and troubleshooting Filter maintenance Manually flushing the toilet Put around 2.1Gal (8L) water into a If you begin to notice reduced spray container and dump it into the ceramic performance and are using the supplied bowl to manually flush the toilet. angle valve, try cleaning the filter: Note: Avoid water spilling from bowl. -
Page 17: Battery Replacement
Backup battery replacement Toilet will be left unused for > 3 weeks 1. Unplug DC connector and remove the When the product is left unused for a battery box. long time, especially in cold weather, it is highly recommended to drain the 2. -
Page 18: Side Control Knob Functions
Side control knob functions When Nobody is Seated • Press the knob in to flush the toilet • Turn the knob clockwise to bring the nozzle out for manual cleaning • Press the knob in and hold for 3 seconds to turn off the LED ring light. Repeat to turn it back on. -
Page 19: Troubleshooting Guide
Troubleshooting guide Problem Cause Solution Water supply hose is kinked Straighten the hose to remove the kink No water spraying Turn on the angle valve Angle valve is off from nozzle Seat sensor not triggered Sit fully on the seat with skin contact Water supply hose is kinked Straighten the hose to remove the kink Poor water...
