  • Page 1 [EN] Use and installation manual [FR] Manuel d’installation et d’utilisation [ES] Manual de instalación y uso Cooking area Surface de cuisson Área de cocción...
  • Page 2: Table Of Contents

    [EN] Use and installation manual Dear Customer, congratulations on your purchase. Please carefully read the instructions for installation and use before using the cooktop for the first time. The instructions contain important information for installation, safety, use and maintenance. This will protect you from injury and prevent damage to the cooktop. The manufacturer will not be held liable for damage caused by failure to comply with the safety instructions and warnings.
  • Page 3: Important Safety Instructions

    Important safety instructions WARNING! READ THE OPERATING INSTRUCTIONS CAREFULLY BEFORE USING THE COOKTOP! THIS APPLIANCE IS INTENDED FOR RESIDENTIAL COOKING ONLY. Intended use • This cooking surface is intended for use in households and similar environments. • This cooking surface is not intended for outdoor use. •...
  • Page 4: Proper Use

    Important safety instructions check for visible damage. Do not operate a damaged appliance. • The electrical safety of this cooking surface can only be guaranteed if proper grounding been installed in compliance with applicable regulations. It is imperative that this basic safety requirement be met.
  • Page 5 Important safety instructions foam-type extinguisher. • WARNING: The cooktop is hot during use and remains so for some time after being switched off. The risk of burns remains until the residual heat indicators have gone out. • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously.
  • Page 6 Important safety instructions a smooth bottom. • Salt, sugar, and grains of sand or dirt (e.g. from fresh vegetables) between the cookware and the can cause scratches. Keep and cookware clean. cooking surface cooking area • Even light objects such as a salt shaker can cause cracks and chips if they fall on the glass ceramic surface.
  • Page 7: Induction Cooking

    Induction cooking Advantages of induction cooking When cooking with induction, heat is generated directly in the base of the pan. This provides many benefits for you: •Time saving when boiling and frying. Cookware is heated directly. • Less energy is consumed. •...
  • Page 8 Induction cooking due to unintentional contact with the utensil, the handle of a utensil should be positioned so that it is turned inward, and does not extend over adjacent surface units. Use Proper Pan Size - This appliance is equipped with one or more surface units of different size.
  • Page 9: Examples Of Cooking Applications

    Induction cooking Pan does not meet the minimum size Pan size meets or exceeds the required for the Cooking Zone. recommended minimum size for the Cooking Zone. Pan bottom rests on cooktop trim or does Pan rests completely on the Cooktop not rest completely on the cooktop surface.
  • Page 10: Using The Cooking Area

    Using the Cooking area Control panel sensor keys The appliance is operated using the control panel sensor keys. Functions are controlled by touching the sensor keys and confirmed by displays and acoustic signals. Touch the sensor keys from above, without covering other sensor keys.
  • Page 11 Using the Cooking area Sensor key Function Power - press to switch on the appliance Control Lock - press to activate ‘‘Control lock” function Pause/Recall - press to activate ‘‘Pause’’ or ‘‘Recall’’ function On-off - press to switch on a cooking zone Power Boost - press to activate ‘‘...
  • Page 12: Display Symbols And Leds

    Using the Cooking area Display symbols and leds Display Description Active function led - indicates that the corresponding function/zone is active Timer/egg timer led - cooking zone timer active / egg timer active Bridge led - indicates that the bridge function is active Melt led - indicates that the ‘‘melt’’...
  • Page 13: Switching The Appliance On

    Using the Cooking area Switching the appliance on Press the Power key to switch the appliance on. All the displays relative to the cooking zones switch on in the standby position”0”. The control unit remains active for 10 seconds. If no cooking zone is selected within this time, the appliance switches off automatically.
  • Page 14: Pause

    Using the Cooking area desired time using the [+] and [-] keys within 6 seconds. Wait for 5 seconds for the automatic confirmation. The time countdown will be shown on the timer display. When time elapses, the display will show a flashing ‘‘000’’ and an acoustic signal will be heard.
  • Page 15: Special Programs: Melt, Simmer, Power Boost, Automatic Warm-Up

    Using the Cooking area appear on all displays to confirm your selection and the relative led will light up. When the Child safety lock is enabled you can switch the appliance off. The Child safety lock is still enabled when the appliance is switched on again. To unlock the appliance permanently, press simoultaneously the Control lock key and the Pause/Recall key , then again the Pause/Recall key.
  • Page 16: Safety Switch

    Using the Cooking area originally set. The lenght of time that the automatic warm up function operates depends on the heat setting selected. To activate the warm up function on a cooking zone place your finger on the slidebar at the desired heat level an hold the position until the symbol ‘‘A’’, alternating with the selected heat level, appears on the cooking area display.
  • Page 17: Bridge (Flexible Cooking Zones)

    Using the Cooking area Bridge (Flexible cooking zones) This function allows you to combine two adjacent cooking zones to create one large zone as shown below. Pay attention in placing the cookware in the correct position on the cooking zones. INDUCTION HI-LIGHT max 3700 w...
  • Page 18: Troubleshooting

    Troubleshooting Problem Possible cause Remedy You cannot activate or operate appliance Contact a qualified electrician. the appliance. connected to an electrical supply or it is connected incorrectly. The fuse is released. Make sure that the fuse is the cause of the malfunction. If the fuse releases again and again, contact a qualified electrician.
  • Page 19 Troubleshooting There is no cookware on Put cookware on the zone. comes on. the zone. The cookware is incorrect. Use the correct cookware. Refer to “Induction Cooking” chapter. dimension cookware with correct bottom of the cookware is dimensions. Refer to “Induction too small for the zone.
  • Page 20: Protecting The Environment

    Protecting the environment Disposal of your old appliance • Old electrical and electronic appliances often still contain valuable materials. However, they also contain harmful substances that were essential for the proper functioning and safe use of the equipment. Handling these materials improperly or disposing of them in your household waste can be harmful to your health and the environment.
  • Page 21: Wireless Induction Charge

    Wireless induction charge CENTER 1. The Cooking area is equipped with two wireless phone charger. 2. For correct charging activation, the telephone device (Android or Apple) must be correctly placed in the center of the wireless symbol, screen-printed on the cooking surface, (otherwise the recharge does not activate and / or does not work properly).
