1300 049 246
PRODUCT INFORMATION &
INSTALLATION GUIDE
Removable Surface Mount
Twist Type Bollard
SKU
REMBOLSMU
REMBOLSMKA
REMBOLSMKAB (Keyed Alike) - Black
Hot Dip Galvanised Steel Powder Coated
Material
with Class 1 Reflective Tape
Height:
Diameter: 90mm (Pole) 200mm (Base)
Dimensions:
Wall Thickness: 3mm
Base: 4 Mounting Holes
Item Weight
13kg
4 x FREE M10 Coach Screws 100mm,
Fixings
washers and nylon plugs Included per
bollard (standard fixings kit)
Technical Drawing
Surface Mount
Twist Type Bollard
A: 900mm Dia.
B: 1200mm Overall Height
Base Plate:
C: 200mm Dia.
D: 18mm Thickness
E: 8mm Fixing Hole Dia.
www.safetyxpress.com.au
Specifications
(Unique Lock) - Yellow
(Keyed Alike) - Yellow
1200mm
Extra Base Plates
(SKU: TBOLREC) are
available for purchase,
this is handy when
bollards need to be
removed and mounted
at different locations.
Page 1 of 4
Advertisement
Related Manuals for Safety Xpress REMBOLSMU
Summary of Contents for Safety Xpress REMBOLSMU
- Page 1 PRODUCT INFORMATION & INSTALLATION GUIDE Removable Surface Mount Twist Type Bollard Specifications REMBOLSMU (Unique Lock) - Yellow REMBOLSMKA (Keyed Alike) - Yellow REMBOLSMKAB (Keyed Alike) - Black Hot Dip Galvanised Steel Powder Coated Material with Class 1 Reflective Tape Height:...
- Page 2 PRODUCT INFORMATION & INSTALLATION GUIDE Tools Required: • Hammer drill with correct sized drill bit • Fixing kit • The correct sized socket • A hammer • A hand broom or industrial vacuum Installation: 1. Read instruction steps from beginning to Base Plate end.
- Page 3 PRODUCT INFORMATION & INSTALLATION GUIDE Removable Surface Mount - Twist Type Bollard How To Attach Bollard To Base Plate 1. Put the key into lock barrel, while lifting the bollard by its handle so it sits directly ontop of the base plate 2.
- Page 4 PRODUCT INFORMATION & INSTALLATION GUIDE Removable Surface Mount - Twist Type Bollard How To Remove Bollard From Base Plate (To Allow Vehicle Access) 1. Put the key into lock barrel, gently twist it anti-clockwise. Make sure you hold the key down in place with one hand (so it is not locked), while holding the bollard handle with another hand.
