Page 1 US EPA Environmental Response Team User Manual For Viper - Smart Gateway ANUAL – S IPER MART ATEWAY Page 1 ERT Support: 800-999-6990...
Page 2: Table Of Contents
Install ProRAE Guardian Software ........................40 Attaching ProRAE Host to the Smart Gateway ....................40 Configuring ProRAE Guardian ......................... 41 Configuring Viper Survey Controller ......................... 44 Configuring PRG2CAP ............................. 44 Creating a Survey Controller Run with ProRAE Guardian Instruments ............45 ...
Page 3: Overview
Viper - Smart Gateway VERVIEW The Smart Gateway can be used as a traditional gateway following the normal Viper user guide procedures or you can choose to transition tasks where you previously used a laptop or a Virtual Machine to now directly run on the gateway. There is also an opportunity to connect instruments directly, eliminating the need for LINCs.
Page 4: Smart Gateway Hardware Information
US EPA Environmental Response Team User Manual For Viper - Smart Gateway MART ATEWAY ARDWARE NFORMATION EXTERNAL PORTS HDMI Monitor Port Connect an external monitor to the internal laptop. RJ45 (Ethernet) Port Can be configured as LAN or WAN a. LAN – Connect instruments with Ethernet Outputs (i.e., SPM Flex)
Page 5: Antennae And Sim Cards
US EPA Environmental Response Team User Manual For Viper - Smart Gateway ANTENNAE AND SIM CARDS To insert the SIM card, remove the two screws on the SIM door, install the SIM in either slot, put the screws back in. (Gateway will not boot up if the SIM port screws are out)
Page 6: Gateway Name And Power Switch
US EPA Environmental Response Team User Manual For Viper - Smart Gateway GATEWAY NAME AND POWER SWITCH Gateway Name: The Gateway Name is labeled on the side of the gateway with the handle. The gateway name is EPAERTXXX where X represents a unique number.
Page 7: Internal Equipment
US EPA Environmental Response Team User Manual For Viper - Smart Gateway INTERNAL EQUIPMENT The photo here is for illustration Purposes only. There is typically NO NEED to open a Smart Gateway 1. Cradlepoint IBR900LP6 Router https://cradlepoint.com/products/cor-ibr900-series Auto-detects SIM provider and selects...
Page 8: Using The Smart Gateway
Gateway has a SIM card installed and the SIM card is using a Public IP Address. If you are unfamiliar with determining the IP Address of the SIM card installed, refer to Section 10/Step 5 of the ERT Viper User Guide or contact ERT Support for assistance.
Page 9: External Monitor, Keyboard And Mouse
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Using an internet-connected laptop or mobile device  (not on the EPAERT1 WiFi network), run Windows Remote Desktop Connection Computer Name = the EXTERNAL gateway address  followed by :7000 (i.e., EPAERT265.SAFEENV2.COM:7000)
Page 10: Troubleshooting The Internal Laptop (Motherboard)
Power the Smart Gateway off and on.  NOTE: The port may not directly line-up with the motherboard reset switch. Contact ERT Support if you are not successful with Option 1 and/or 2. Page 10 ERT Support: 800-999-6990...
Page 11: Troubleshooting Remote Desktop Connection To The Smart Gateway
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Troubleshooting Remote Desktop Connection to the Smart Gateway 1. Can’t connect via Remote Desktop Connection from within the EPAERT1 WiFi network: If you can’t use Remote Desktop Connection locally to access the Smart Gateway Laptop from a computer or mobile device connected to the EPAERT1 WiFi network, you have two options: ...
Page 12 US EPA Environmental Response Team User Manual For Viper - Smart Gateway 2. Can’t connect via Remote Desktop Connection over the internet: and you can’t use Remote Desktop Connection to access the internal laptop on the Smart Gateway, check that the “Remote Desktop Connection Port Forwarding Rule” is properly configured on the CRADLEPOINT router.
Page 13: Logging In To The Cradlepoint Router
The steps to login to the Cradlepoint Router on a Smart Gateway are the same as a traditional gateway. See Section 10/Step 4 of the ERT Viper User guide for additional details. Quick Reference Sheet for Accessing the Smart Gateway Laptop & Cradlepoint Accessing the Smart Gateway’s Internal...
Page 14: Section 1 - Using The External Ports On The Smart Gateway
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Section 1 – Using the External Ports on the Smart Gateway The Smart Gateway has four (4) external ports for connecting instruments. There is one (1) port to which a traditional gateway LINC cable can be attached (COMx), an Ethernet Port and two (2) USB ports which can be configured to communicate with RS232 Serial connections.
Page 15 3. Add the Smart Gateway to Survey Controller The process of adding a Smart Gateway is the same as adding a traditional Gateway.  Open VIPER Survey Controller. From the menu, select Lifeline>Equipment Inventory  Under the Lifeline Gateway(s) and Mesh Network(s) dialog box, click Add.
Page 16 Run Survey Controller on the internal Gateway laptop  From the menu, select Run>New Run>From Scratch  Click Next on the Viper Run Configuration Wizard  Complete the Run Description information  Run Name/ID – Include the Region and name of the site/response exercise ...
Page 17 US EPA Environmental Response Team User Manual For Viper - Smart Gateway  Continue through the run configuration screens. Reading intervals can be configured and fixed coordinates can be entered; however, the Smart Gateway will provide coordinates if none are entered.
Page 18: Troubleshooting Serial (Com Port) Connections
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Troubleshooting Serial (COM Port) Connections If the MeterApp does not turn green:  Verify the COM Port and Baud Rate are correct on the Data Input Settings tab of the MeterApp ...
Page 19: Using The Usb Ports To Connect Instruments - Serial To Usb (I.e., Dusttraks)
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Using the USB Ports to Connect Instruments – Serial to USB (i.e., DustTraks) Section 5 of this guide outlines how to directly connect a RAE Host to the Smart Gateway USB port and configure a run in Survey Controller.
Page 20: Using The Ethernet (Rj45) Port (Spm Flex)
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Using the Ethernet (RJ45) Port (SPM Flex) 1. Verify that the Ethernet Port is configured as LAN  Login to the Cradlepoint and navigate to Networking – VLAN Interfaces (Refer to the table above for login information for the Cradlepoint modem) ...
Page 21: Section 2 - Smart Gateway Meterapp
As such, those default alarm values might not be representative of a typical EPA removal deployment. ERT and Safe Environment Engineering welcome feedback on any observations about these performance metrics/alarms and how they may differ during EPA responses, and what values were more appropriate for the response.
Page 22: Additional Signal And Sinr Information
Used Space: Displays the amount of hard drive space used. The Smart Gateways have a 60GB hard drive. Alarms can be configured on the percentage of disk space used. Viper Survey Controller stores ‘raw and compiled’ data locally on the hard drive. Assuming that Survey Controller was pushing data to Deployment Manager, it is recommended that when a deployment is completed, the files stored locally on the Smart Gateway be deleted from the hard drive.
Page 23 US EPA Environmental Response Team User Manual For Viper - Smart Gateway To open the Open Hardware Monitor, click the ^ in the taskbar to expand the list of icons. Right-click on the Open Hardware Monitor icon and select Hide/Show.
Page 24: Adding The Smart Gateway Meterapp To A Survey Controller Run
Survey Controller of perhaps 5 minutes for the Smart Gateway MeterApp, you will greatly reduce the number of readings recorded. Refer to the Viper User Guide – Section 3, Part E for additional information on configuring readings intervals in Survey Controller.
Page 25 Survey Controller must be installed  First Un-Install the existing version of Survey Controller  Refer to ‘Section One – Part B’ of the Viper User Guide for instructions on installing Viper Survey Controller Page 25 ERT Support: 800-999-6990...
Page 26 US EPA Environmental Response Team User Manual For Viper - Smart Gateway 3. Add the Smart Gateway MeterApp to a Survey Controller Run  Start a run and click ‘Add’ on the LINC Configuration window  Select the ‘Generic Cap Stream’ radio button ...
Page 27: Section 3 - Smart Gateway Wifi And Security
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Section 3 – Smart Gateway WiFi and Security Unlike traditional gateways, the WiFi signal on the Smart Gateway is configured on the Cradlepoint Router. There are also two (2) WiFi radio frequencies – 2.4 GHz and 5 GHz. The primary differences between the 2.4 GHz and 5 GHz wireless frequencies are range and bandwidth.
Page 28 US EPA Environmental Response Team User Manual For Viper - Smart Gateway 7. Select the EPAERT1 WiFi Name (SSID). 8. Click Edit. 9. Toggle Enables on or off by removing/replacing the checkmark. Click the ‘Save’ button. Page 28 ERT Support: 800-999-6990...
Page 29: Changing Wifi Network Name (Ssid) In The Gateway
1. Verify your computer is connected to the Smart Gateways WiFi network (EPAERT1 by default). CAUTION: Remember to change the SSID on the LINCs before changing the SSID of the Gateway. Refer to the Viper User Guide, Section Seven – Part C: Changing the WiFi Name (SSID) on a LINC.
Page 30 US EPA Environmental Response Team User Manual For Viper - Smart Gateway 7. Select the EPAERT1 WiFi Name (SSID). 8. Click Edison. 9. Enter a New SSID Name. 10. Click Save. Page 30 ERT Support: 800-999-6990...
Page 31: Disabling Wifi Security
Viper - Smart Gateway Disabling WiFi Security By default, the Viper Smart Gateways are configured with an SSID of EPAERT1 and require a security password. There may be some instances when having an ‘open’ WiFi connection is desirable (e.g., a LINC is not security enabled and cannot connect to the EPAERT1 network).
Page 32: Enabling Wifi Security
US EPA Environmental Response Team User Manual For Viper - Smart Gateway 9. Under Security Mode, select ‘Open’. 10. Click Save. Enabling WiFi Security  Follow steps 1 through 8 above to navigate to the Security Mode option  Select WPA2 Personal for Security Mode ...
Page 33: Section 4 - Cradlepoint Gps Settings
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Section 4 – Cradlepoint GPS Settings Overview The GPS on the Cradlepoint acts like an independent ‘client’ and delivers GPS to all of the Meters that are connected. If the Cradlepoint can’t see the satellites, GPS will not be provided.
Page 34 US EPA Environmental Response Team User Manual For Viper - Smart Gateway  To make sure GPS is enabled on the Cradlepoint, navigate to SYSTEM | ADMINISTRATION | GPS and make sure that Enable GPS is checked.  There should be one entry under the ‘Send to Clients’ section of that screen.
Page 35 US EPA Environmental Response Team User Manual For Viper - Smart Gateway  Add or Edit GPS page 2 of 3 settings should be set to: o Choose Language = NMEA o Check in Report NMEA GGA sentences  Add or Edit GPS page 3 of 3 settings should be set to:...
Page 36: Section 5 - Internet Sources
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Section 5 – Internet Sources The Smart Gateway supports acquiring internet access via a SIM card, WiFi Source or Ethernet Source. If the source of the internet access is behind a router and/or uses a private IP Address (vs. a Public/Static IP Address), Survey Controller running on the internal laptop will still be able to push data to Deployment Manager.
Page 37: External Wifi Source
US EPA Environmental Response Team User Manual For Viper - Smart Gateway External WiFi Source If cell service isn’t available but a WiFi connection is available, the Cradlepoint in the Gateway can be configured to use the WiFi as its source of internet and data will be pushed to Deployment Manager.
Page 38: Troubleshooting Wifi And Ethernet Internet Sources
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Login to the Cradlepoint and navigate to NETWORKING | VLAN INTERFACES  Look where port 0U is. If it is in LAN, the Ethernet Connector is set to work for an SPM Flex or other Ethernet-connected instrument.
Page 39 US EPA Environmental Response Team User Manual For Viper - Smart Gateway  Modify the Gateway Subnet Mask temporarily. o Navigate to NETWORKING – LOCAL NETWORKS – LOCAL IP NETWORKS o EDIT THE PRIMARY LAN o SELECT Ipv4 Settings o Change the subnet mask from 255.255.0.0 to 255.255.255.0 and click Save o Navigate back to Connection Manager and select Devices o The profile should now show ‘Connected’...
Page 40: Section 6 - Directly Connecting A Rae Host To The Smart Gateway
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Section 6 – Directly connecting a RAE Host to the Smart Gateway Overview Since the Smart Gateway has a built in laptop, ProRAE Guardian (PRG) can be installed on the laptop and the RAE Host can be directly connected to the USB Port(s) on the Smart Gateway using a compatible Serial (RS-232) to USB connector.
Page 41: Configuring Prorae Guardian
US EPA Environmental Response Team User Manual For Viper - Smart Gateway 5. When the connection is made on the Smart Gateway, Device Manager should display the new COM port assigned for that instrument. Make a note of the new COM port.
Page 42 US EPA Environmental Response Team User Manual For Viper - Smart Gateway 4. Under Data Sources | Remote Data In tab, make sure there is NO checkmark in ‘Cascade In Mode’. 5. Under Options | Data Options | Data Forwarding tab, place a checkmark in Cascade Out Mode and enter Remote PC IP Address 127.0.0.1 and...
Page 43 8. The instruments will now be displayed in the ProRAE Guardian software and will appear online in the System Information window. NOTE: For ProRAE Guardian to recognize instruments, those instruments must be set to the same Network ID as the RAE Host. ERT/EPA uses a Network ID of 438. Page 43 ERT Support: 800-999-6990...
Page 44: Configuring Viper Survey Controller
US EPA Environmental Response Team User Manual For Viper - Smart Gateway Configuring Viper Survey Controller 1. Open Survey Controller. 2. Re-register Survey Controller if this is the first run for a new deployment. 3. Click on Run | Preferences.
Page 45: Creating A Survey Controller Run With Prorae Guardian Instruments
Viper - Smart Gateway Creating a Survey Controller Run with ProRAE Guardian Instruments Generic CAP Streams are added when a run is being created in VIPER Survey Controller’s ‘Run Configuration Wizard’. It is very similar to the way LINC/instruments are added.
