UM-8142
User Manual for
Type 8221, 8212, 8142 & 8091 HPT
Type 8182 HPT Modems
HPT Variants
Issue B Rev 1
Date of Issue: 08 July 2016
Sonardyne International Limited
Blackbushe Business Park
Yateley, Hampshire
GU46 6GD United Kingdom
920-0120
T. +44 (0) 1252 872288
F. +44 (0) 1252 876100
E. support@sonardyne.com
W. www.sonardyne.com
