Page 1 SIP EBIKE USER MANUAL O N T I M E B I K E . C O M 1-888-925-6668...
Page 2: Table Of Contents
5 . O P E R A T I N G T H E P R O D U C T 2 3 5.1. TFT Monitor Operation 5.2. Activating System Lights 5.3. LCD Meter Programming & Use 5.4. Hand Throttle Control O N T IME | SIP EBIKE MA N UAL VERS ION 1 .0...
Page 3: Introduction
1. INTRODUCTION WELCOME TO THE ONTIME FAMILY Thank you for choosing an ONTIME Electric Bike. As a leader in electric bike design and distribution in United State, we are passionate about our customers riding their bikes more and driving their cars less. We are focused on ensuring that you have a safe and enjoyable riding experience for years to come.
Page 4: Safety & General Tips
If at any point ONTIME Drive Systems is asked to implement upgrades, we will notify you if the modifications exceed street legal limits •...
Page 5: Rules Of The Road
• Do not tow or push the product • Replace broken parts immediately • If any ebike component is not functioning properly, end the ride immediately O N T IME | SIP EBIKE MA N UAL VERS ION 1.0...
Page 6: Before Your First Ride
• Be sure to bed in the brakes. Failure to do so will result in lower than optimum braking performance and can lead to squealing O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 7: Battery & Charger Safety
NEVER disassemble the battery, there is significant risk of shock and damage to the battery. Doing so will also void the warranty. DO NOT puncture or crush the battery, or expose to server vibrations and impacts. O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 8: First Charge
Do not use the ONTIME battery charger for any purpose other than charging your ebike. Do not use the ONTIME battery as a power source for any other devices than your ONTIME ebike. If you do so the warranty will not be applicable, and ONTIME Drive Systems will not be liable for any damage to the system or injury to the persons.
Page 9: Charging Your Battery
70% of its capacity for about 500 full discharge/recharge cycles. As capacity diminishes, you will notice a gradual drop off in max range capability. When range falls to an unacceptable level, contact your local ONTIME dealer to purchase a new battery.
Page 10: Battery Transport
Batteries should never be thrown in the garbage • Contact ONTIME for more information about how to recycle your batteries Disposing of Lithium-Ion batteries incorrectly can allow moisture and oxygen to enter the battery. This can lead to the oxidation of lithium components and which can cause a heat reaction that may include fire or explosion.
Page 11: General Riding Tips
Failure to wear a helmet and other recomended safety gear when riding an ebike can lead to serious injury or death. O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 12 Ensure your helmet meets the latest certification standards and is appropriate for the type of riding you do and if there are any special requirements for riding an electric bike O N T IME | SIP EBIKE MA N UAL VERS ION 1 .0...
Page 13: Bike Fit
If your pelvic area touches the frame, the bike is too big for you and is therefore unsafe to ride O N T IME | SIP EBIKE MA N UAL VERS ION 1 .0...
Page 14: Safe Operating Conditions
286lb shared between the rider and cargo WEIGHT CAPACITY • ONTIME SIP eBike is designed with a maximum weight capacity of 74LB. Exceeding the maximum weight capacity can result in damage to the bike, which can lead to serious injury or death UNSAFE USE •...
Page 15: Product Description
Brake cables, shifter cables and electric Rear Wheel wires Headlight Seat Stem Front Fork Saddle Front Tire Wheel Rim Spokes Air Valve Stem Quick Release Lever O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 16: Sip Specifications
Rim: Aluminum Alloy 36h Front and Rear Weight: 74LB Gross Weight With Front and Rear Speed: Up to 28MPH on Pedal Assist Fender and Rear Rack Seat Clamp: Quick Release O N T IME | SIP EBIKE MA N UAL VERS ION 1 .0...
Page 17: A S S E M B L Y I N S T R U C T I O N
Do not damage the battery when removing it the frame from the box. 4. 4. TOOLS REQUIRED • Allen key set (included), Wrench (not-included) O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 18 While cutting zip ties be careful not to scratch or damage your bike, be extra cautious while cutting zip ties around wire connections and cable housings. Do not damage the battery when removing it the frame from the box. Remove Package Securing Pins Remove Packaging Wraps O N T IME | S IP EBIKE MA N UAL VERSIO N 1 .0...
Page 19: Installing Handle Bar
4.5.INSTALLING HANDLE BAR Use the Hexagon Screw (Found Inside The Hex Key Set) Loosen the four handle bar mount screws Place the handlebar onto the handlebar mount Secure the handlebar mount cover with the four screws O N T IME | S IP EBIKE MA N UAL VERSIO N 1 .0...
Page 20: Installing Front Wheel
4. 6. INSTALLING FRONT WHEEL Use the Hexagon Screw (Found Inside The Hex Key Set) Carefully latch the front wheel Secure both side front wheel bolts O N T IME | S IP EBIKE MA N UAL VERSIO N 1 .0...
Page 21: Installing Bike Pedals
4.7. INSTALLING BIKE PEDALS Use a Wrench (Not Included) Prepare bike pedals for installation Align bike pedals with bike pedal threads tightening bike pedals O N T IME | S IP EBIKE MA N UAL VERSIO N 1 .0...
Page 22: Installing Bike Seat&Assembly Complete
4. 8. INSTALLING BIKE SEAT & ASSEMBLY COMPLETE Flip the bike over and secure the kick stand Mount seat cusion Installation complete O N T IME | SIP EBIKE MA N UAL VER SION 1 .0...
Page 23: Tft Monitor Operation
To turn the head and LCD lights ON and OFF, simply press and hold the UP arrow on the LCD display for about two seconds until you see the display light up O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 24: Lcd Meter Programming & Use
The maximum working current: 30mA Off-state leakage current: <1μA Operating temperature: -20℃~ 60℃ Storage temperature: -30℃~ 70℃ Appearance and Size Display appearance and dimensional drawing (unit: mm) O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 25: Hand Throttle Control
Error code indication ● USB connection indicator ● Various Parameters Settings (e.g., wheel size setting, speed limit setting, battery voltage segmented value setting, power assist parameters setting,etc.) O N T IME | SIP EBIKE MA N UAL VERS ION 1.0...
Page 26: General Operation
Distance by default. Press the “i” button to switch between following elements: Trip (Km) →ODO (Km)→Max. Speed (Km/h)→ Avg. Speed (Km/h) →Time (Min.) . Display Indication Cycle Interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 27 To switch on the bike light, hold the + button. The backlight brightness is automatically reduced. Hold the + button again, the lighting can be switched off. Switching the Lighting Mode On/Off Interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 28 The five battery bars represent battery SOC.The five battery segments are bright when the battery is in high voltage. When percentage is 0%, the battery needs to be recharged immediately. Battery SOC Indication Interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 29 Motor Power Indication Interface USB connection indication When the display is inserted into a USB external device, the display interface will show as below. USB Connection Indication Interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 30 Have the display repaired when error code appears. Otherwise, you will not be able to ride the bike normally. Please always refer to an authorized dealer. O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 31: Settings
“-” button to increase or decrease until the desired value is displayed. The default value is 26 inch. To store a changed setting, press the “i” button to confirm. Wheel Diameter Settings Interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 32 “+” button or the “-” button to choose the desired percentage. To store a changed setting, briefly press the “i” button to confirm. Backlight Brightness Settings Interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 33 5 bar-voltage values are entered completely, press the “i” button to confirm. Battery Voltage Settings Interface Advanced settings Advanced setting here deals with PAS parameters settings Advanced setting interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 34 To change the magnet numbers for the power assist sensor, press the “+” or the “-” button to choose the desired number. To store a changed setting, press the “i” button to confirm Assistant Num setting interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 35 To change basic settings, press the “+” or the “-” button to increase or decrease the value of the current. To store a changed setting, press the “i” button to confirm. Current limit setting O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 36 To change slow start up settings, press +/- button to choose the desired value. And press the i button to confirm and store a changed setting. Slow start setting O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 37 “-” button to choose the desired duration. The default auto-off time is 5 minutes. To store a changed setting, briefly press the “i” button. Auto-off time settings O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 38 To access the power-on password setting page, select ‘Password’ in the menu and press “i” button to confirm. PassWord Set means power-on password settings. Power-on password is a 4-digit code. The default password is ‘1212’. Password Setting Interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 39 Finally, it comes to the third page and reenter the new password again for confirmation. The screen displays ‘ PassWord Reset Successfully’ When switching on the E-bike system next time, please enter the new password to power on the display. O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 40 To reset to defaults, press the “+” or the “-” button to choose YES or NO. The default is NO. To store a changed setting, press the “i” button to confirm. Factory settings O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 41 No represents not clearing a single ride distance. To store a changed setting, briefly press the “i” button to confirm. Trip Distance Clearance Settings Interface O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 42 Exit means return back to home screen from setting pages. ■ If thre is no operations in one minute; the display will exit the settings state automatically. O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 43: Warranty
Display end- RX Yellow（TX） Display end-TX ■Some displays have wire connection with water-proof connectors, users can not see the color of lead wires in the harness. O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 44: Warnings
Please always refer to an actual version. Attached list 1：Error code definition Error Code Definition Current Abnormality Throttle Abnormality Motor Phase Abnormality Motor Hall Signal Abnormality Brake Abnormality Communication Abnormality O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 45: Error Code Definition
5.9 ERROR CODE DEFINITION will be indicated and one of the The HMI can show the faults of Pedelec. When a fault is detected, the icon following error codes will be indicated too. Note: Please read carefully the description of the error code. When the error code appears, please first restart the system.
Page 46 Error Declaration Troubleshooting 1. Check all connectors from the battery are correctly connected to the Error with the temperature sensor motor. inside of the battery 2. If the problem still occurs, please change the Battery. 1. Allow the pedelec to cool down and restart the system. The protection temperature inside the controller has reached its maximum 2.
Page 47 Troubleshooting Declaration Error 1. Check that all connections are connected correctly. 2. Please connect the pedelec to the BESST system to see if speed signal can be read by the BESST tool. Speed signal of the torque sensor has an error 3.
Page 48 Error Declaration Troubleshooting Using the BESST tool update the controller to see if this resolves the problem. If not, please change the controller or contact your supplier. WDT circuit is faulty Total voltage from the battery is too high Please change the battery. Total voltage from the battery is too low Please Charge the battery.
Page 49: Operation Range
Clean the drivetrain as often as you can and at least thoroughly clean it once a month • Avoid sudden starts and stops • Minimize use of the throttle • Check and adjust tire pressure O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 50: Pre-Ride Checklist
Check that the hub motor is functioning smoothly and in good condition Check that battery has enough charging left on it Lock the battery and remove the key Check seat height Check lights and reflectors O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 51: Transportation&Storage
Although our warranty is designed to ensure you receive a perfect product at the time of purchase your product will still require maintenance by the user O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
Page 52 I M P O R TA N T N O T E : ONTIME does not offer tune-up and bike mechanical services beyond limited installation or repairs of electrical system. Changing settings on the controller from the default manufacturer suggestion settings may cause damage the ebike components.
Page 53: Warranty
7. 3. EXCLUSIONS ONTIME is released and discharged of any liability for any damages, injuries or claims occurring as a result of neglect, the owner is responsible for the maintenance and safety of all structural and mechanical components of their ebike such as brakes, headset, forks, etc.
Page 54 • In case the issue is not diagnosed by standard ways; for our hub motor kits, ONTIME ebikes, and other house brand products, since the electrical system is modular and has easy access. We would be able to easily send you replacement parts such as a controller to swap and test and return the defective one.
Page 55: Contact
L I V E C H A T H O U R S Monday to Friday: 9am-5pm PST P H O N E 1-888-925-6668 W E B S I T E www.ontimebike.com O N T IME | SIP EBIKE MA N UAL VERSIO N 1 .0...
