- Page 1 OD-2025HD /OD-2025PHD 2-MegaPixel Outdoor 30fps 25 meter IR IPCAM / Passive PoE 2-MegaPixel Outdoor 30fps 25 meter IR IPCAM User’s Manual AirLive OD-2025HD /OD-2025PHD User’s Manual...
- Page 2 Serial No. ____________________ To prevent fire or shock hazard, do not expose the unit to rain or moisture. For AC Adaptor to avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. AirLive OD-2025HD /OD-2025PHD User’s Manual...
- Page 3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. AirLive OD-2025HD /OD-2025PHD User’s Manual...
- Page 4 We reserve the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement. AirLive OD-2025HD /OD-2025PHD User’s Manual...
-
Page 5: Table Of Contents
4.1.7 Bonjour ....................34 4.1.8 ONVIF......................35 4.1.9 IP Filter ....................36 4.1.10 IP Notification ..................37 4.2 Camera: Adjust Camera Parameters ..............40 4.2.1 Picture .....................40 4.2.2 Privacy Mask ...................42 4.2.3 PTZ Setting....................43 4.2.4 Preset Setting ..................44 4.2.5 Tour Setting .....................45 AirCam OD-2025HD /OD-2025PHD User’s Manual... - Page 6 Appendix D: Bandwidth Estimation................77 Appendix E: Specifications ..................78 Appendix F: Configure Port Forwarding Manually ...........80 Appendix G: DDNS Application ................83 Appendix H: Power Line Frequency ................89 Appendix I: 3GPP ....................91 Appendix J: Enable UPnP of Windows XP ..............92 AirLive OD-2025HD /OD-2025PHD User’s Manual...
-
Page 7: Introduction
Users are able to view live video streaming over the Internet, and it is only one of benefits for using AirLive IP Camera. It is also designed to offer high-performance surveillance and the AirLive OD-2025HD equipped with PoE port which allows power and data to be transmitted via a single Ethernet cable. - Page 8 This feature will greatly help installing the OD-2025PHD in the environment where power is an issue. With the IP-66 waterproof housing, AirLive OD-2025HD/OD-2025PHD suits for environments such as stairs, main entrance, street, and basement. The device is accessible via the LAN or Internet connection. Connect your device directly to a local area network or xDSL modem, and with Microsoft®...
-
Page 9: Package Contents
1. Introduction 1.2 Package Contents User can find the following items in the package: Item Descriptions 1. OD-2025HD or OD-2025PHD is the main element of the product. 2. Wall mount 3. Wall mount stand 2. Screws x 3 3. Power Adapter... -
Page 10: Connections
6. PoE 1P: passive PoE injector (OD-2025HD only). Note: Using a power supply with a different voltage than the one included with the Network Camera will cause damage and void the warranty for this product. - Page 11 DI/ DO: Connect to sensor in and alarm out devices Cable for I/O connectors: Name Cable Color Function 12VDC Brown/White DC 12V (50mA maximum) Blue/White Purple/White Do not connect Gray Do not connect Green/White Digital signal input AirCam OD-2025HD /OD-2025PHD User’s Manual...
- Page 12 Connect a loud speaker to the network camera. This function is for voice alerting and two-way audio. 7. BNC Connector The composite video format will be sent out through this connector. User might connect the IP Camera to a monitor or DVR via this connector. AirCam OD-2025HD /OD-2025PHD User’s Manual...
-
Page 13: Passive Poe Installation (For Od-2025Phd Only)
2. Connect the cable from the IP camera to the POE port, please note, for delivering the power properly, this should be a 4 twisted pair cable. 3. Plug the 12DC adapter to the DC phone jack. AirCam OD-2025HD /OD-2025PHD User’s Manual... -
Page 14: Mounting The Camera
The power LED turned on, it means the system is booting up successfully. Furthermore, if you have a proper network connection, and access to the camera, the LAN LED (green) will flash. AirCam OD-2025HD /OD-2025PHD User’s Manual... -
Page 15: Preparation
When you installed the Camera on a LAN environment, you have two easy ways to search your Cameras by IPWizard II or UPnP™ discovery. Here is the way to execute IPWizard II to discover Camera’s IP address and set up related parameter in a Camera. 2.1.1 Search AirCam OD-2025HD /OD-2025PHD User’s Manual... - Page 16 2. Preparation When launch the IPWizard II, a searching window will pop up. IPWizard II is starting to search Network Cameras on the LAN. The existed devices will be listed as below. AirCam OD-2025HD /OD-2025PHD User’s Manual...
-
Page 17: View
View button. Then you could see the video from camera directly. Furthermore you could double click the left button of mouse to link to the network device by browser. AirCam OD-2025HD /OD-2025PHD User’s Manual... -
Page 18: Lan
2.1.3 LAN In case you want to change the IP related parameters of wired interface, please select the device you want to configure and click the LAN button. Relative settings will be carried out as below. AirCam OD-2025HD /OD-2025PHD User’s Manual... - Page 19 2. Preparation You could modify the relative settings of the selected device. Click “<<” button will quit the LAN setting procedure and click “>>” button will move to next page as below. AirCam OD-2025HD /OD-2025PHD User’s Manual...
- Page 20 If you like to change username and/or password of the device, just click the check button. Then, the related fields will show up as below. After keying in new username and password, click “Submit” button to perform your setting accordingly. Click “<<” button will go back to previous page. AirCam OD-2025HD /OD-2025PHD User’s Manual...
