Operation
Manual
TOP
COVER
POWER
SWITCH
LIMITED WARRANTY
This product is warranted to be free from defects in material and/or
workmanship for a period of two (2) years from date of original
installation, not to exceed 30 months from date of shipment from
our factory. Any part or component which proves to be faulty in
material and/or workmanship within the warranty period will be
replaced or repaired (at the option of Prince Castle, Inc.) without
cost to the customer for parts or labor.
This warranty is subject to the following exceptions/conditions:
• Use of any non-genuine Prince Castle parts voids this
warranty and all work must be performed by an authorized
Prince Castle Service Agent.
• All labor shall be performed during regular work hours.
Overtime premium will not be covered.
• Travel charges are limited to 100 miles/200 km round trip, 2
hours travel time, one trip per repair.
• Damage caused by carelessness, neglect, and/or abuse (e.g.,
using wrong current, dropping, tampering with or altering
electrical components, or improper cleaning) is not covered.
• Equipment damaged in shipment, by fire, flood or an act of
God is not covered.
• Damage to non-stick coated surfaces is not covered by this
warranty.
524-500revD-EN
Product Identification
CONTROL
PANEL
DOOR
HANDLE
355 East Kehoe Blvd. • Carol Stream, IL 60188 USA
Telephone: 630-462-8800 • Toll Free: 1-800-PCASTLE
Fax: 630-462-1460 • www.princecastle.com
Electrical Specifications
120 VAC, 60 Hz, 580W, 1-Phase
220 VAC, 50 Hz, 580W, 1-Phase
The 120 VAC version will have the UL mark on the label
and the 220 VAC version will have the CE mark.
TABLE OF CONTENTS
Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Model Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exploded Views and Parts Lists . . . . . . . . . . . . . . . . . . . . . .
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pie Merchandiser
524-Series
1
1
1
2
2
2
2
3
4
5
6
Printed in USA 12/09 © 2009
Advertisement
Summary of Contents for BERKSHIRE HATHAWAY Prince Castle 524 Series
- Page 1 Operation Pie Merchandiser Manual 524-Series Product Identification Electrical Specifications COVER 120 VAC, 60 Hz, 580W, 1-Phase CONTROL PANEL 220 VAC, 50 Hz, 580W, 1-Phase The 120 VAC version will have the UL mark on the label and the 220 VAC version will have the CE mark. DOOR HANDLE POWER...
- Page 2 Pie Merchandiser 524-Series Safety Information Introduction Knowledge of proper installation, operation and maintenance The 524-MCDC/-MCDCCE Pie Merchandiser is designed to procedures is essential to ensure safe operation of any hold pies at proper serving temperatures. The cabinet has a equipment. programmable temperature controller with a low temperature •...
- Page 3 Pie Merchandiser 524-Series Operation The power switch is located at the base of the cabinet, After preheating, load boxed pies into cabinet. below the door. Turn the power switch ON. Preheat cabinet for 30 minutes. When the cabinet is turned on, the air heater will operate until the cabinet reaches the air temperature setpoint.
- Page 4 Pie Merchandiser 524-Series Non-Scheduled Maintenance WARNING Equipment surfaces may be hot. It is recommended that the unit be turned off for at least 10 minutes prior to performing any maintenance procedure. Changing Illuminated Front Graphic on Door: Tools: Phillips Screwdriver Remove the four screws on the sides of the door and remove the door trim.
- Page 5 Pie Merchandiser 524-Series Exploded View and Parts List Part No. Description Part No. Description 524-002S Heating Element 524-009S Power PCB 524-002CES Heating Element (MCDCCE) 524-009CES Power PCB (MCDCCE) 524-003S Motor w/ Fan 65-058S Relay 524-003CES Motor w/ Fan (MCDCCE) 524-010S Ballast 524-004S Cabinet Fan...
- Page 6 Pie Merchandiser 524-Series Wiring Diagram 120 V Printed in USA 12/09 © 2009 524-500revD-EN...
- Page 7 Pie Merchandiser 524-Series Wiring Diagram 230 V 524-500revD-EN Printed in USA 12/09 © 2009...
- Page 8 PREP EQUIPMENT PR 63 Prince Castle Pie Merchandiser Model 524 Model 524 Daily maintenance tasks PR 63 W1 Clean merchandiser CONTROL PANEL DOOR REMOVABLE HANDLE PIES POWER SWITCH Hazards These icons alert you to a possible risk of personal injury. Equipment alerts Look for this icon to find information about how to avoid damaging the equipment while doing a procedure.
- Page 9 Clean Pie Merchandiser Weekly PR 63 W1 To keep the merchandiser clean and food safe Time required 10 minutes to prepare 15 minutes to complete Time of day At close For 24-hour restaurants: during late-night shift Hazard icons Chemicals Electricity Hot Surfaces Tools and supplies SolidSense All Purpose...
