Summary of Contents for ZUUM SP6PH
- Page 1 Surge Protector Series User Manual Model: SP6PH High Performance 1G PoE Surge Protector...
- Page 2 Introduction SP6PH is an in-line surge protector designed to protect PoE (Power over Ethernet) devices from high voltage surges, with network bandwidth up to 1000Mbps. Features Supports bandwidth up to 1000 Mbps. ⚫ Supports IEEE 802.3af, 802.3at, 802.3bt PoE standard.
- Page 3 RJ45 Pinout: (TIA/EIA-568-B) (PIN TIA/EIA-568B) Wire Color Orange-white Orange Green-white Blue Blue-white Green Brown-white Brown Application Computer Control Rooms ⚫ Educational Institutions ⚫ Server Farms ⚫ Commercial Offices ⚫ Manufacturing Facilities ⚫ Transmitter and Receiver Stations ⚫...
- Page 4 Specification ITEM NO. SP6PH Support Compliance IEEE 802.3af, 802.3at, 802.3bt, IEC 61000-4-2, IEC 61000-4-5 Network Bandwidth 10/100/1000 Mbps Response Time Less than 0.7nS ESD Protection 30KV (Air), 30kV Contact) Lightning Protection 10KA (8/20 us), 20KV (8/20 us) Ports & Interfaces...
