OPERATOR'S MANUAL

MODEL #201107

1600 ExPANSiON BATTERy

at championpowerequipment.com

or visit championpowerequipment.com

READ AND SAVE THiS MANUAL. This manual contains important safety precautions which should be read and understood before operating the product. Failure to

do so could result in serious injury. This manual should remain with the product.

Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.

3589-M-OP REV 20221114

Champion Power Equipment, Inc., Santa Fe Springs, CA USA

Table of Contents

Need help?

Do you have a question about the 201107 and is the answer not in the manual?

Questions and answers

Summary of Contents for Champion 201107

Page 1 This manual should remain with the product. Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice. 3589-M-OP REV 20221114 Champion Power Equipment, Inc., Santa Fe Springs, CA USA...
Page 2: Table Of Contents
TABLE Of CONTENTS 201107 - 1600 ExPANSiON BATTERy TABLE Of CONTENTS Operation ........... .. Using the Expansion Battery .
Page 3: Introduction
201107 - 1600 ExPANSiON BATTERy SAfETy DEfiNiTiONS iNTRODUCTiON Congratulations on your purchase of a Champion Power Equipment The purpose of safety symbols is to attract your attention to (CPE) product. CPE designs, builds, and supports all of our possible dangers. The safety symbols, and their explanations, products to strict specifications and guidelines.
Page 4: Important Safety Instructions
Expansion Battery produces heat. Skin burns can occur on Do not operate the Expansion Battery with a damaged cord, contact. plug, or a damaged output cable. Use only Champion electrical cords for proper application. Do not touch hot surfaces. Do not allow children or unqualified persons to operate or Allow equipment to cool before touching.
Page 5: Lithium-Ion Battery Safety
– Do not use this unit if you do not understand these operating instructions. – Maintain the labels and nameplates on this Expansion Battery. These carry important information. If unreadable or missing, contact our Champion Technical Support Team for a free replacement.
Page 6 – Never use Expansion Battery or charger in the presence of – Never place fingers or hands inside the product. explosive atmospheres (gaseous fumes, dust or flammable – For service information please contact our Champion materials). Technical Support Team at 1-877-338-0999. Please have –...
Page 7 SAfETy iNSTRUCTiONS 201107 - 1600 ExPANSiON BATTERy CAUTiON CAUTiON   When storing the Expansion Battery: Safe disposal of Lithium-ion battery: – This Expansion Battery is to be stored indoors and must – Lithium-ion batteries contain elements that pose health not be stored or left outdoors when not in use.
Page 8: Safety And Dataplate Labels
1638 BLOC ALIMENTATION (Wh) Dataplate This artwork belongs to Champion Power Equipment. The contents are conﬁdential and privileged and shall not be disclosed to or used by or for 201107 MODEL / MODÈLE outside parties without the explicit consent of Champion Power Equipment.
Page 9: Safety Symbols
SAfETy iNSTRUCTiONS 201107 - 1600 ExPANSiON BATTERy Safety Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product.
Page 10 SAfETy iNSTRUCTiONS 201107 - 1600 ExPANSiON BATTERy SYMBOL MEANING Open Flame Alert. Keep away from fuel, smoking, open flames, sparks, pilot lights, heat, and other ignition sources. Wet Conditions Alert. Do not operate Expansion Battery in wet conditions. This product uses lithium-ion (Li-ion) batteries. Local, state, or federal laws prohibit disposal of Li-ion batteries in ordinary trash.
Page 11: Operation Symbols
SAfETy iNSTRUCTiONS 201107 - 1600 ExPANSiON BATTERy Operation Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product.
Page 12: Controls And Features
CONTROLS AND fEATURES 201107 - 1600 ExPANSiON BATTERy CONTROLS AND fEATURES Read this operator’s manual before operating your Expansion Battery. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Expansion Battery...
Page 13: Intelligauge - Expansion Battery
CONTROLS AND fEATURES 201107 - 1600 ExPANSiON BATTERy intelligauge - Expansion Battery This meter displays the remaining battery level of the Expansion Battery from 0-100%. The display button must be pressed to illuminate the display, however, the Expansion Battery is fully operational as soon as it is plugged into and paired with the Power Station.
Page 14: Intelligauge - Power Station
CONTROLS AND fEATURES 201107 - 1600 ExPANSiON BATTERy intelligauge - Power Station This meter displays a variety of info such as input/output power, charge/discharge times, as well as faults, errors, and protection codes to help diagnose malfunctions in the Power Station and Expansion Batteries.
Page 15 CONTROLS AND fEATURES 201107 - 1600 ExPANSiON BATTERy Indicators MODE DESCRIPTION Expansion Battery Discharging (Hours) – Example: Battery 2 Icon illuminated, 8.0 Hours to 2 Expansion Batteries empty, 0 watts in, Expansion Batteries are at 200% and 1 Power Station...
Page 16 CONTROLS AND fEATURES 201107 - 1600 ExPANSiON BATTERy MODE DESCRIPTION Example: Steady red when the Expansion Another Expansion Battery and/or Power Station have experienced a Battery or Power communication fault. The Expansion Battery with Station detected fault will display fault code E2. See troubleshooting during charging section.
Page 17: Industry Canada: Ices-003/Nmb-003
ASSEMBLy 201107 - 1600 ExPANSiON BATTERy ASSEMBLy industry Canada: iCES-003/NMB-003 This device complies with Industry Canada license - exempt RSS Your Expansion Battery must be charged before first use. standard(s). If you have any questions regarding the use of your Expansion Operation is subject to the following two conditions: Battery, call our Technical Support Team at 1-877-338-0999.
Page 18: Pairing With Power Station
ASSEMBLy 201107 - 1600 ExPANSiON BATTERy Pairing with Power Station Charging from Wall CAUTiON CAUTiON   The Expansion Battery and Power Station can not be used to Do not charge Expansion Battery or Power Station while charge each other in place of AC or DC input charge.
Page 19: Using Included Easy Connect Dc Solar Charge Harness
ASSEMBLy 201107 - 1600 ExPANSiON BATTERy Using included Easy Connect DC Solar 3. If not using all 3 connections, you can remove any spare connectors and store in a safe and dry location. Charge Harness (For solar panels with MC4 connector) NOTiCE ...
Page 20: Using App Port
OPERATiON 201107 - 1600 ExPANSiON BATTERy Any solar panel rated between 10-28V with MC4 or APP – Once paired, the Expansion Batteries can be unplugged connectors can be used. The Expansion battery’s charging module from the Power Station or each other and remain paired until has a built in MPPT so there is no need to buy an external charge manually unpaired.
Page 21: Do Not Overload Expansion Battery
Expandable Capacity slots and damage the Expansion Battery electronics. Your Champion Power Station is capable of connecting up to ten 1638 Wh Expansion Batteries. To order more Champion Expansion 1. Use a damp cloth to clean exterior surfaces of the Expansion Batteries to increase your Power Station’s capacity and run time...
Page 22: Specifications
SPECifiCATiONS 201107 - 1600 ExPANSiON BATTERy SPECifiCATiONS AC Charger Specifications Output Watts ............ Expansion Battery Specifications Input Voltage ..
Page 23: Troubleshooting
TROUBLESHOOTiNG 201107 - 1600 ExPANSiON BATTERy TROUBLESHOOTiNG Problem Cause Solution The display button must be pressed for the display to turn on. It does not turn on automatically. The Display does not automatically turn on Expansion Battery will charge and discharge regardless of whether the display is on.
Page 24 TROUBLESHOOTiNG 201107 - 1600 ExPANSiON BATTERy Problem Cause Solution Each Expansion Battery must be paired Expansion Battery will not pair multiple individually to the Power Station. Do not chain Batteries not paired individually batteries. Expansion Batteries and attempt to pair more than one at a time.
Page 25: Power Station Fault Indicator Codes
POWER STATiON fAULT iNDiCATOR CODES 201107 - 1600 ExPANSiON BATTERy POWER STATiON fAULT iNDiCATOR CODES If a problem arises with the Expansion Battery, a fault indicator code will flash on the Expansion Battery Intelligauge. To resolve the issue, follow the directions as indicated in the table below. For further information about Fault Codes, contact:...
Page 26 – Failures due to acts of God and other force majeure events days from date of purchase. beyond the manufacturer’s control. – Problems caused by parts that are not original Champion Repair/Replacement Warranty Power Equipment parts. CPE warrants to the original purchaser that the components will –...
