Powercore E43B Instructions

Instructions
Product manual
Digital Display
Strong magnetic Smart chip Safety protection
Power bank function description
1. Check the remaining battery
Click the switch button, the digital display of the power in the screen is on,
and the number corresponds to the displayed power.
2. Check the charging function:
Click the switch button to turn on the mobile power digital display to display
the current battery power. When the input current is used to charge the
mobile power, the digital display will jump, and it will stop beating when fully
charged, and a green lightning symbol will be displayed to indicate that it is
in a fast charging state. When it is detected that a device is being charged,
the digital display will jump until the power is exhausted and the digital
display will turn off.
3. Switch function
Click the switch button, the wireless function starts working; double-click
the switch, stop working.
4. Stand use
There are grooves on both sides of the OPEN word on the back of the
product.When using it, drag the magnetic bracket above to make it at the
upper end.Drag to the bottom side of the triangle to use the stand.
Precautions
*Please charge the battery at least once every 3 months if it will not be used
for a long time. During the use of this device, it will be slightly hot, but it is
normal that it is not hot.
*Always keep the product dry and do not use chemical agents for cleaning
and scrubbing. Please take care of the environment, recycle this device at
the designated location, and do not dispose of it arbitrarily.
*Children or persons who are not equipped to use this device alone must
use this device under the supervision of an adult.
*Do not bump, disassemble, pierce, crush, or expose this device to moisture.
*Do not apply this power bank to devices that do not meet the output
parameter requirements, it may cause malfunction or fire.
FAQ
★When the power bank cannot be charged:
Please check whether the power adapter is suitable, the connector used,
and whether the converter is normal.
It is recommended to choose a suitable brand of power adapter for charging.
★When the power bank cannot charge other devices:
The power bank is too low, please charge it before using it.
If the internal circuit of the power bank is faulty, please contact the after-sales
service department of the local dealer for help.
Made In China
宽120mm 高110mm
User guide
1. Can be used as a magnetic wireless power bank, compatible with
Apple 12/13 series mobile phones.
2. Can be used as a universal wireless charging power bank, compatible
with all mobile phones that support the QI wireless charging protocol.
Support wireless charging mobile phones such as OPPO、HUAWEI、
Xiaomi、SAMSUNG.
3. Can be used as a portable and compact mobile power supply,
supporting more than 99% of mobile phone charging.
4. It can be used as a wireless charger, put it on the desktop, and charge
it whenever you put it.
5. Can be used as a mobile phone stand,Horizontal and vertical
placement, free vision.
Packaging List
Power bank*1
Instruction manual *1
Charging cable*1
Product Performance
15W wireless output, magnetic wireless fast charging
PD+QC22.5W fast charge
It can be charged and discharged at the same time, and the mobile
phone and power bank can be quickly charged at the same time
LED digital display power screen, accurate display of power
High-quality polymer batteries, safe and worry-free
Remarks: Description of wireless charging functions
*Place the phone on the wireless charger, click the switch button to turn on
the wireless charging function.
*When using the charger to charge the mobile power supply and using the
wireless charging function to charge the device at the same time, only the
ordinary 5W wirelessLine charging function.
*During the charging process of the mobile power supply, in a fully charged
state, since the charging protocol is switched to the 5V input state, it is
turned on at this time.In wireless charging mode, only ordinary 5W charging
can be performed. When you stop charging the power bank, it will restart
automatically, andWireless charging can enter fast charging mode.
*When using PD12V charger to charge the power bank, because this function
does not support 12V power supply, wireless chargingfeature will be turned
off.
Specifications
Name Magnetic wireless power bank
Product model E43B
Type of cell Lithium polymer battery
Type-C output
Type-C input
USB output
Wireless output
105*66.5*20.2±0.1mm
Product Size
Executive standard
Operating temperature
Magnetic suction
wireless output
Type-C out/input
Bracket
ON/OFF
USB output
Battery display
screen
