U S E R ' S G U I D E
High-Dynamic-Range
Power Sensors
Models 2101 & 2103
These power sensors are sensitive to electrostatic
discharges and could be permanently damaged if
subjected even to small discharges. Ground your-
self adequately prior to handling these detectors or
making connections. A ground strap provides the
most effective grounding and minimizes the
likelihood of electrostatic damage
e-mail: tech@newport.com • www.newport.com
phone: (877) 835-9620
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Newport 2101
Summary of Contents for Newport 2101
- Page 1 U S E R ’ S G U I D E High-Dynamic-Range Power Sensors Models 2101 & 2103 These power sensors are sensitive to electrostatic discharges and could be permanently damaged if subjected even to small discharges. Ground your- self adequately prior to handling these detectors or making connections.
- Page 2 Warranty Newport Corporation guarantees its products to be free of defects for one year from the date of shipment. This is in lieu of all other guarantees, expressed or implied, and does not cover incidental or consequential loss. Information in this document is subject to change without notice.
-
Page 3: Table Of Contents
Service ..........16 Models 2101 & 2103... - Page 4 This page has been intentionally left blank 4 • Contents...
-
Page 5: Operation
The fast analog response is also useful for viewing high-range signals on an oscilloscope, making the Model 2101 and 2103 good tools for general lab use. Multiple units can be bolted together and their power Models 2101 & 2103... -
Page 6: Basic Operating Information
N times 75 mA. 4. The output is an analog voltage with a gain of 50 mV/dB of input light. For the Model 2101, a 3.5-V output typically corresponds to approximately 2 dBm of input optical power at 920 nm. - Page 7 <0.02 dB. The typical wavelength dependence of the response is shown in Figure 1 for Model 2101 and Figure 2 for Model 2103, respectively. The vertical axis is in optical dB, and the horizontal axis is in optical wavelength µm.
- Page 8 Model 2101 has no status light. Output Signal The output of the Models 2101 and 2103 is an analog voltage with a gain of 50 mV per dB of input light. For Model 2101, a 3.5-V output corresponds to approximately 2 dBm of input power at 920 nm;...
- Page 9 Measurement Speed The Models 2101 and 2103 have three filter settings (1, 5, and 25 kHz) to reduce noise when speed of response is not critical. The fastest setting results in a 0-100% small signal rise time of 30 µs and an analog bandwidth in excess of 25 kHz.
- Page 10 Noise Levels The electrical noise voltage present at the output divided by the gain (50 mV/dB) of the power sensor represents the noise referred to the input. A plot of this is shown in Figure 4 for the 25-kHz filter setting. Note the discontinuity at the crossover.
- Page 11 The Newport Model 0901 15-V Power Supply can power a total of nine units (four from each of the two 300-mA outputs, and one from the 100-mA output.)
- Page 12 This page has been intentionally left blank 12 • Operation...
-
Page 13: Characteristics • 13
2.86 3.25 (82.5) (72.6) the Model 2103 1.50 (38.1) 3.00 (76.2) Speed Switch 2.86 (72.7) 3 Pin Female Connector Unless otherwise noted, dimensions are in inches with metric dimensions in mm in parentheses. Models 2101 & 2103 Characteristics • 13... -
Page 14: Characteristics
Figure 8: Single unit configuration Characteristics Specification Model 2101 Model 2103 Calibrated Wavelength Range 1520–1620 nm Uncalibrated Wavelength Range 320~1060 nm 950–1650 nm Photodiode Material InGaAs Photodiode Diameter 5 mm 1 mm Photodiode Window Fusion bonded AR coating borosilicate glass,... - Page 15 -0.2 to +3.75 V typ. Input Connector Free space plus fiber FC/PC or FC/APC adapter option Power Consumption ±15 V, 75 mA ±15 V, 75 mA Operating Temperature Range 15–35˚ C 15–35˚ C Taken at 1550 nm. Models 2101 & 2103 Characteristics • 15...
-
Page 16: Customer Service
Customer Service Technical Support Information and advice about the operation of any Newport product is availabe from our applications engineers. For quickest response, ask for “Technical Support” and know the model number and serial number for your product. Hours: 8:00–5:00 PST, Monday through Friday (excluding holidays).
