B&G PISTOL PRO 700 User Manual

Safety Precautions

• Do not pressurize with any gas
• Do not pressurize an empty tank.
• Open tank cap slowly to release air before removing; keep
bottle upright when releasing pressure
• Do not transport while pressurized.
• Do not treat voids with electrical
outlets or cables.
• The end of wood-injection tip is sharp
and must be handled with care.

Before Starting

• Engage the safety lock on the gun valve.
• Tighten bottle until snug, do not over-tighten
bottle.
700 Series Models
4-Way,
C+C Tip
4-Way, C+C Tip
• For typical pest control operations, indoors and outdoors.
Foaming Tip
• Add foaming agent to liquid insecticide to produce foam, tip
adjusts to produce thick or limited foam. Suitable for treat-
ing floor drains with the B&G microbial cleaner, MicroFoam
EF for small fly control.
Wood-Injection Tip
• Suitable for penetrating surface of infested wood to
intersect insect galleries; this tip
delivers foam or liquid.
• Drill a 1/16 in. hole into the wood
surface or push the pointed tip
through wood surface into gallery.
Wood-Injection
Tip
Foaming Tip
PISTOL PRO 700
USER'S MANUAL

Operating Instructions

Filling Bottle (1 pint, 1 quart)

• To ensure adequate air pressure in bottle, do not fill to the
top of the bottle, allow 1/3 of bottle for head space.
• Foaming agent must be added to bottle of the Foaming Tip
Model.
• Mix and use all insecticides in accordance with
label directions.

Pressurizing

• Connect bottle to portable battery-operated
compressor (#24013750) using the quick-con-
nection.
• Connect bottle to tire-pressurizing pump using
the tire-type valve.
• Pressurize the bottle to 60-80 psi, do not over-
pressurize.

Care and Maintenance

• Flush bottle, valve, and siphon tube
with clean water regularly.
• Inspect and clean the tip of the
siphon tube regularly.
• Clean the filter in front of the soft
seat gasket regularly.
• Protect application tips when not in
use.

Trouble Shooting

Problem: Gun is leaking from: 1) the front of the tip, or,
2) behind the tip
Solution: 1) Tighten tip retainer, clean nozzle
2) Clean or replace soft seat gasket
Problem: Leaking at bottom of the gun or the top of the bottle
Solution: • Tighten reducing nipple connection
• Tighten hose barb, check o-ring for damage
or replace
• Replace Teflon tape
Problem: Extenda-Ban valve or tip on Pistol Pro Platinum
leaking
Solution: • Tighten packing nut on valve
• Replace packing washers in valve
Problem: Foam from foaming tip is watery or not thick enough
Solution: • Add more foaming agent to bottle
• Clean the siphon tube with fresh water
24010028 Rev 7/10
