S&S NavBoard FlipLite NB-FL02 Series User Instructions

END USER INSTRUCTIONS - READ BEFORE USE
PRODUCT NAME:
NavBoard

PACKAGE INCLUDES:

NavBoard® FlipLIte™

PREPARE FLIPLITE FOR ATTACHING TO CARRIER

Push down on
1 2
bungee lock to
release
PAGE 1 of 2
NOT COMPATIBLE WITH NAVBOARD® ZIPFLIP™ OR FLAP
FlipLite™
®
Adjustable friction hinge
Flip up bungee lock Release the two
3
and release. Open mounting straps.
FlipLite. FlipLite is ready for
mounting.
ATTACHING THE FLIPLITE™ TO A PLATEFRAME MODULAR™ (PF-M™)
Feed the mounting
1 2
straps through the
uppermost slots.
4
PART NUMBER:
NB-FL02XX
Pull the mounting Fold the mounting
3
straps through the straps up and lock in
appropriate window by pushing down as
(approximately 3" shown above. Repeat
below the uppermost with second strap.
slots). Fold the FlipLite
phone panel down.
Attach Velcro to
Fold bottom panel
5
back of device up and pull the
and pull corner
closure over the
retention straps bottom panel.
over device to
The FlipLIte™ is
secure. now attached and
secured.
©2022 S&S Precision, LLC | 11072022
