Summary of Contents for VELOSSA TECH G70
- Page 1 2019-2021 Genesis G70 3.3T/2.0T BIG MOUTH Ram Air Intake Installation Guide...
- Page 2 Kit Contents (Full Kit) Please review this document before attempting installation. You will need basic hand tools and 1-1.5 hours of installation time. This product reuses the OEM hardware. KIT CONTENTS AGS Simulator Bracket Assembly #6, 1/2" screws Diode Dynamics RGBW Controller Diode Dynamics 1m LED Extension Positive Cable w/ In-Line Fuse Power Cable w/ Pigtail Connector...
- Page 3 Switch Ground Cable w/ Crimped Connector 8" Zip ties 16" Zip ties 3/8" Conduit (3 feet) Cable Clips M6 Lock Nut Assembled LIT Flares If you already own the GEN 4 Genesis G70 BIG MOUTH’s, skip ahead to slide 29 for wiring instructions...
-
Page 4: Shroud Removal
Shroud Removal Remove the shroud by pushing down on the center pin of the pop-up clips and extracting them with a pry tool. -
Page 5: Bumper Removal
Bumper Removal After removing the shroud, remove the top 4 screws (10mm) that attach the bumper to the chassis... - Page 6 Bumper Removal Remove the hidden screw (8mm) lying within the cavity identified below.
- Page 7 Bumper Removal Remove all the indicated pop-up clips and screw from the wheel well and bottom edge of the bumper...
- Page 8 Bumper Removal As the bumper gets pulled off, take notice of the indicated wiring harness connector. To remove, pull back on the lever shown below. Once it swivels about entirely, pull to disconnect.
-
Page 9: Headlight Removal
Headlight Removal The bolts holding both headlights must be removed for this install but do not fully remove the headlight from its socket. Remove using a 12mm socket... - Page 10 Moving Headlight Swivel the headlights just enough to access the bolt hidden behind it...
- Page 11 Stock Snorkel Removal To remove the OEM inlets, there are 3 (10mm) screws that need to be removed. You will need a 6” extension to reach the recessed screw indicated with the blue arrow. Hold on to these, some of them will be reused.
- Page 12 AGS Shroud Removal Disconnect the indicated connector.
- Page 13 AGS Shroud Removal Disconnect the connector that is positioned in the highlighted area and remove the bolt (10mm) to detach the metal mount. Put it aside, it will be installed again.
- Page 14 AGS Shroud Removal Detach the shroud by unfastening the 4 screws (10mm) marked below. You will need a 6” extension to reach the recessed screws marked by the arrows.
- Page 15 AGS Shroud Removal From the backside of the shroud, carefully undo the clips holding the wire loom by pinching as shown in the image. There are numerous clips along the shroud. Once these have been undone, the shroud should be free to remove.
- Page 16 AGS Shroud Disassembly Remove these Phillips screws Use channel locks on a wide setting to pinch these clips, keep them pulled back so they don’t snap back in place as you move around the shroud.
- Page 17 AGS Servo Disassembly Once the AGS system has been detached from the car, you will need to remove the servo motor located on the side of the AGS shroud. Hold on to these two screws Levers Once the motor is removed, you will see two AGS levers.
- Page 18 AGS Simulator Housing Assembly Note these stock components for reference AGS Servo Casing Levers...
- Page 19 AGS Simulator Housing Assembly These are the parts needed to fully assemble the AGS simulator. The AGS simulator is necessary to prevent an engine code. AGS Simulator Housing Back plate #6 screws OEM Screws from previous slide...
- Page 20 AGS Simulator Housing Assembly Place levers back into motor casing. IMPORTANT: THE RIGHT LEVER WILL NOT MOVE FREELY. DO NOT ATTEMPT TO ROTATE. AGS Simulator Housing (flipped) Idler lever is free to move, but keep it in this position DON’T TRY TO FORCE THIS LEVER TO ROTATE...
- Page 21 Assembly Place the AGS simulator housing over the levers, come in from the Step 1: Orient top/right side and slide the housing before placement first onto the rightmost lever as shown. Then seat the housing and motor as shown in Step 3. Step 2: Tilt in and position, it’s ok to slide the lever out a little bit to get the housing to seat.
- Page 22 AGS Simulator Housing Assembly Re-use the two screws to fasten the motor to the AGS Simulator housing.
- Page 23 AGS Simulator Housing Assembly Flip the housing over and place the link onto the levers as shown, smooth side facing out. Once this process is complete, do not try and move the levers, they are now linked.
- Page 24 AGS Simulator Housing Assembly Install cover with 4 x #6 screws as shown...
- Page 25 AGS Simulator Housing Assembly The installations that follow this slide only use coarse-thread hardware, shown on the right. The threads are much larger and spaced out. Also, the coarse-thread hardware ends with a sharp point. IMPORTANT FOR NEXT SLIDE!!!
- Page 26 AGS Simulator Housing Assembly DO NOT CROSS-THREAD AND MAKE SURE NOT TO OVERTORQUE. USE SCREW FROM PREVIOUS SLIDE Install the servo casing as shown and plug the associated connector back in.
- Page 27 Securing Wire Loom Use 16” zip ties to tidy up the area and keep the wire loom secure AGS simulator shown here...
- Page 28 BIG MOUTH Install After the OEM components have been removed, you will need to remove the rubber seal on each stock snorkel and re- apply it to the BIG MOUTH intakes in the same orientation as OEM. Note that R is RIGHT side (or passenger side) and L is LEFT side (or driver side).
- Page 29 Install the LIT BIG MOUTH Flares SKIP THIS SLIDE IF YOU PURCHASED A FULL KIT Remove the flares by unscrewing the 4 set screws on each flare. Screw the new LIT KIT flares on your BIG MOUTH bodies. Ensure there is ample strain relief at the Clean the surfaces well, and apply the strain LED power wires! relief cable clips, apply modest pressure.
- Page 30 BIG MOUTH Install Carefully slide the BIG MOUTH intakes over the stock ports and ensure the bolt holes line up. Fasten using the OEM coarse-thread hardware. DO NOT CROSS-THREAD AND MAKE SURE NOT TO OVERTORQUE.
- Page 31 BIG MOUTH Install Prepare the following locations by wiping down with a clean cloth or paper towel, let dry. Apply the LED cable relief clip as shown.
- Page 32 BIG MOUTH Lit Kit Prep Plug the supplied Diode Dynamics LED extension cable into the driver side LED as shown and clip into LED cable relief clip. Take notice of the notch within the M8 female connector. The connectors must be properly oriented and should not require very much force to connect.
- Page 33 BIG MOUTH Lit Kit Prep Clip the extension cable into the second strain relief clip and join both cables together at the join point. Cut a 6” piece of conduit supplied in the kit and wrap the two Diode Dynamics cables in the conduit at this location and snake through as shown below. 6”...
- Page 34 BIG MOUTH Lit Kit Prep Using a 16” zip tie, fasten the Diode Dynamics controller in the following orientation to the stock transition duct as shown. Both main output cables should be facing up. 16” zip tie Other side of 6” conduit, through radiator support.
- Page 35 BIG MOUTH Lit Kit Prep Plug both LED power cables into the Diode Dynamics RGBW Bluetooth controller along with the pigtail connectors (grey). Bunch the cables together neatly. Do not strain the cables with tight radius bends or tugging in any place. Both LED power wires exit here 8”...
- Page 36 BIG MOUTH Lit Kit Prep There should be enough slack here as to not strain the cables. Zip tie in a tidy fashion, at center of pigtail connector. Ensure there is no tight bending of wire or kinks.
-
Page 37: Wiring Harness
Wiring Harness Positive wire (+) Power terminal (+) In-line fuse Toggle switch Crimped connectors Switch ground wire Power connector Ground terminal (-) Ground wire (-) Crimped connector... - Page 38 Wiring Harness Schematic Gold terminal can be grounded using the Switch (leave on) wire shown below to allow switch LED to light up when in use. Crimped connector to switch terminal (+) Crimped connector to 12V Power switch terminal (A) Terminal (+) Fuse Power connector...
- Page 39 BIG MOUTH Lit Kit Routing Route the remaining wires and conduit as shown, tuck underneath for a clean look. Grey power connector gets plugged in and wires routed through this hole and wrapped in the remaining conduit. Ensure at least an inch of conduit sits in the hole.
- Page 40 Ground the BIG MOUTH Lit Kit Use a 10mm box wrench to remove the indicated OEM shoulder bolt and use it to ground the power circuit. Tuck in any leftover wire back into the conduit. Tuck in excess wire Remove OEM shoulder bolt...
- Page 41 BIG MOUTH Lit Kit Routing Route the remaining wires and conduit as shown, tuck underneath for a clean look.
- Page 42 BIG MOUTH Lit Kit Routing Power wires routed from here. Grounded here.
- Page 43 BIG MOUTH Lit Kit Routing Connect the red wires to the switch as shown in slide 38. Set aside about 2 ft of red wire and bundle the excess of the red power wires together using an 8” zip tie. Leave 2 ft of wire free Bundle excess power wire together and zip tie...
- Page 44 BIG MOUTH Lit Kit Routing Maneuver the power ring terminal and in-line fuse through the rear of the indicated area into the fuse box. Pop this clip if necessary, push the middle button down on the head of the clip to release...
- Page 45 BIG MOUTH Lit Kit Power Route the power wire along the rear of the fuse box as shown by the arrows and connect to the power terminal using the supplied M6 nut. Ensure the wire is not going to be pinched by the fuse box cover or subject to any kinks.
- Page 46 Re-install Headlights...
- Page 47 Re-install Sensor Reinstall the bracket shown and reconnect the associated connector...
-
Page 48: Phone App
Phone App Finalize the installation by downloading the Diode Dynamics app and connect via Bluetooth. Play around with the app, it’s fun! - Page 49 Finalize Re-install the bumper and plastic cover plate, enjoy!
