Summary of Contents for Portwell COM Express PCOM-C60B ZR4
- Page 1 COM Express™ PCOM-C60B ZR4 User Manual COM Express™ PCOM-C60B User manual Revision 1.0 Copyright © PORTWELL PCOM-C60B...
- Page 2 COM Express™ PCOM-C60B ZR4 User Manual Revision History R 1.0 Preliminary for PCOM-C60B ZR4 Copyright © PORTWELL PCOM-C60B...
-
Page 3: Table Of Contents
5 Mechanical drawing ........................................ 13 6 Rear I/O ........................................... 17 7 On board Connectors ......................................21 8 Jumper............................................. 35 9 Miscellaneous ......................................... 42 10 Ordering Guide ........................................44 11 Pin out Tables ........................................45 12 Industry Specifications ......................................50 Copyright © PORTWELL PCOM-C60B... - Page 4 Table 20 eDP Backlight Control & Connector ....................................... 32 Table 21 CPU Fan ................................................ 33 Table 22 ATX 8 Pin Connector ............................................33 Table 23 ATX 24 Pin Connector ............................................ 34 Table 24 Jumper List..............................................35 Table 25 TPM Present on Carrier ..........................................36 Copyright © PORTWELL PCOM-C60B...
- Page 5 Table 40 Other Test (BATLOW#/LID#/CB_WAKE#/THRM#) ..................................43 Table 41 F85281 Mode Select ............................................43 Table 42 Ordering Guide ............................................. 44 Table 43 AB & CD Row Connector Signals ........................................49 Table 44 Portwell Product Matrix ....................................錯誤! 尚未定義書籤。 Copyright © PORTWELL PCOM-C60B...
- Page 6 Figure 3 Mechnical Isometric View ..........................................13 Figure 3 Mechnical dimension - Top ..........................................14 Figure 4 Mechnical dimension - Bottom ........................................15 Figure 5 Mechanical dimension - Side view ......................................... 16 Figure 6 Rear I/O ................................................. 17 Copyright © PORTWELL PCOM-C60B...
- Page 7 PORTWELL products, regardless of the legal theory on which the claim is based, and even if PORTWELL as been advised of the possibility of such damages.
- Page 8 PCOM-C60B ZR4 User Manual Technical Support PORTWELL technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and implemented. We request that you first visit our website at http://www.PORTWELL.com.tw/support/...
-
Page 9: Introduction
PCOM-C60B user manual contains all information of the product specification, mechanical dimensions, and multiple I/O expansion with ATX mother board form factor. This carrier is planned to fulfill the most of COM-Express 2.1/3.0 Type 6 module, included basic, and compact size. Copyright © PORTWELL PCOM-C60B... -
Page 10: Block Diagram
COM Express™ PCOM-C60B ZR4 User Manual 2 Block Diagram Figure 1 Block Diagram Copyright © PORTWELL PCOM-C60B... -
Page 11: Specifications
Power DC IN +12V ATX Power ; AT/ATX Mode ➢ Operating Temperature -40 ﾟ C ~ +85 ﾟ C Environment ➢ Storage Temperature -40 ﾟ C ~ +85 ﾟ C ➢ Relative Humidity 5%~95% Table 1 Specifications Copyright © PORTWELL PCOM-C60B... -
Page 12: Carrier I/O Location
COM Express™ PCOM-C60B ZR4 User Manual 4 Carrier I/O Location Figure 2 I/O & Connectors location Copyright © PORTWELL PCOM-C60B... -
Page 13: Mechanical Drawing
COM Express™ PCOM-C60B ZR4 User Manual 5 Mechanical drawing Figure 3 Mechnical Isometric View Copyright © PORTWELL PCOM-C60B... -
Page 14: Figure 3 Mechnical Dimension - Top
COM Express™ PCOM-C60B ZR4 User Manual Figure 4 Mechnical dimension - Top Copyright © PORTWELL PCOM-C60B... -
Page 15: Figure 4 Mechnical Dimension - Bottom
COM Express™ PCOM-C60B ZR4 User Manual Figure 5 Mechnical dimension - Bottom Copyright © PORTWELL PCOM-C60B... -
Page 16: Figure 5 Mechanical Dimension - Side View
COM Express™ PCOM-C60B ZR4 User Manual Figure 6 Mechanical dimension - Side view Copyright © PORTWELL PCOM-C60B... -
Page 17: Rear I/O
This section introduces the Rear I/O connector layout on PCOM-C60B Figure 7 Rear I/O Rear I/O Function Display Port Connector J48 A/B Display Port 1/2 Connector 4*USB2.0 RJ45 + 2*USB3.2 2*USB3.2 Audio Jack Table 2 Rear IO list Copyright © PORTWELL PCOM-C60B... -
Page 18: Table 3 Display Port
COM Express™ PCOM-C60B ZR4 User Manual J1, J48 A/B: Display Port Connector Signal Name PIN Signal Name DP_LANE0_P DP_LANE0_N DP_LANE1_P DP_LANE1_N J48 A/B DP_LANE2_P DP_LANE2_N DP_LANE3_P DP_LANE3_N DP_AUX_SEL DP_AUX_P DP_AUX_N DP_HPD VCC3 Table 3 Display Port Copyright © PORTWELL PCOM-C60B... -
Page 19: Table 4 4*Usb2.0
Signal Name Signal Name PIN Signal Name VBUSOTG VBUS1 VCT_LAN USB_DN0 USB_DN1 LAN_MDI0P USB_DP0 USB_DP1 LAN_MDI0N LAN_MDI1P USB_RXN0 USB_RXN1 LAN_MDI1N USB_RXP0 USB_RXP1 LAN_MDI2P LAN_MDI2N USB_TXN0 USB_TXN1 LAN_MDI3P USB_TXP0 USB_TXP1 LAN_MDI3N Table 5 RJ45 + 2* USB3.2 Copyright © PORTWELL PCOM-C60B... -
Page 20: Table 6 2*Usb3.2
VBU2 VBUS3 USB_DN2 USB_DN3 USB_DP2 USB_DP3 USB_RXN2 USB_RXN3 USB_RXP2 USB_RXP3 USB_TXN2 USB_TXN3 USB_TXP2 USB_TXP3 Table 6 2*USB3.2 J13: Audio Jack PIN Signal Name PIN Signal Name LINE_IN_L LINE_OUT_L LINE_IN_JD LINE_OUT_JD LINE_IN_L LINE_OUT_L Table 7 Audio Jack Copyright © PORTWELL PCOM-C60B... -
Page 21: On Board Connectors
SMBus Header LVDS Backlight Control LVDS Connector VGA D-SUB eDP Backlight control eDP connector CPU FAN ATX 8 pin Connector ATX 24 Pin Connector J45, J44 COM Express connector AB/CD Table 8 Headers & Connectors list Copyright © PORTWELL PCOM-C60B... -
Page 22: Table 9 Front Panel
COM Express™ PCOM-C60B ZR4 User Manual J10: Front Panel Signal Name Signal Name 1 VCC_CARR_SATA 2 NC 3 SATA_ACK# 4 NC 5 GND 6 Power BTN# 7 Reset BTN# 8 GND 9 NC Table 9 Front Panel Copyright © PORTWELL PCOM-C60B... -
Page 23: Table 10 Pcie X4 Slot Port 0-3/4-7
B13 GND A29 PCIE_RXP3/7 B29 GND A14 PCIE_CLK- B14 PCIE_TXP0/4 A30 PCIE_RXN3/7 B30 GND A15 GND B15 PCIE_TXN0/4 A31 GND B31 PRSNT2_2#(NC) A16 PCIE_RXP0/4 B16 GND A32 NC B32 GND Table 10 PCIE x4 Slot Port 0-3/4-7 Copyright © PORTWELL PCOM-C60B... -
Page 24: Table 11 Pcie X1 Slot Port 2/1/3/5/6/7
SMB_DAT JTAG_TDO(NC) JTAG_TMS(NC) VCC3 VCC3 VCC3 B10 3VSB PCIE_RST B11 PCIE_WAKE# B12 NC PCIE_CLK+ B13 GND PCIE_CLK- B14 PCIE_TXP B15 PCIE_TXN PCIE_RXP B16 GND PCIE_RXN B17 PRSNT2#(NC) B18 GND Table 11 PCIE x1 Slot Port 2/1/3/5/6/7 Copyright © PORTWELL PCOM-C60B... - Page 25 A16 PEG_RXP0 B16 GND A45 GND B45 PEG_TXP7 A74 GND B74 PEG_TXP14 A17 PEG_RXN0 B17 NC A46 GND B46 PEG_TXN7 A75 GND B75 PEG_TXN14 A18 GND B18 GND A47 PEG_RXP7 B47 GND A76 PEG_RXP14 B76 GND Copyright © PORTWELL PCOM-C60B...
-
Page 26: Table 12 Pcie X16 Slot Port
A58 GND B58 PEG_TXP10 Table 12 PCIE x16 Slot Port J13/18/19/22: SATA Port 1/2/3/0 Signal Name 1 GND J13/18/19/22 2 SATA_TXP 3 SATA_TXN 4 GND 5 SATA_RXN 6 SATA_RXP 7 GND Table 13 SATA Port 1/2/3/0 Copyright © PORTWELL PCOM-C60B... -
Page 27: Table 14 Tpm Connector
5 BUF_PLT_RST# 6 VCC 7 LAD3 8 LAD2 9 VCC3 10 LAD1 11 LAD0 12 GND 13 CB_SMCLK0_R 14 CB_SMDAT0_R 15 3V_DUAL 16 LPC_SERIRQ 17 GND 18 NC 19 PM_SUS_STAT# 20 TPM_PP Table 14 TPM Connector Copyright © PORTWELL PCOM-C60B... -
Page 28: Table 15 Com0/1 D-Sub
COM Express™ PCOM-C60B ZR4 User Manual J46/J47 J46/47: COM0/1 D-SUB PIN Signal Name 1 NC 2 SER0/1_RX_232 3 SER0/1_TX_232 4 NC 5 GND 6 NC 7 NC 8 NC 9 NC Table 15 COM0/1 D-SUB Copyright © PORTWELL PCOM-C60B... -
Page 29: Table 16 Gpio Header
5 GPI2 4 GPO1 3 GPI1 2 GPO0 1 GPI0 Table 16 GPIO Header J31: I2C Header J32: SMbus Header Signal Name Signal Name I2C_clk SMB_clk I2C_dat SMB_dat 3V_DUAL 3V_DUAL Table 17 I2C & SMbus Header Copyright © PORTWELL PCOM-C60B... -
Page 30: Table 18 Lvds Backlight Control & Connector
18 LVDSB_DATA0# 19 LVDSB_DATA1 20 LVDSB_DATA1# LVDS_BCLK_EN 21 LVDSB_DATA2 22 LVDSB_DATA2# 23 LVDSB_DATA3 24 LVDSB_DATA3# 25 LVDSB_CLKP 12 LVDB_CLKN 27 Color bit select 28 NC 29 GND 30 GND Table 18 LVDS Backlight Control & Connector Copyright © PORTWELL PCOM-C60B... -
Page 31: Table 19 Vga D-Sub
COM Express™ PCOM-C60B ZR4 User Manual J35: VGA D-SUB PIN Signal Name PIN Signal Name VGA_RED VGA_GREEN 10 GND VGA_BLUE 11 NC 12 VGA_I2C_DAT 13 VGA_HSY 14 VGA_VSY 15 VGA_I2C_CLK Table 19 VGA D-SUB Copyright © PORTWELL PCOM-C60B... -
Page 32: Table 20 Edp Backlight Control & Connector
8 GND 14 EDP_TXN2_R 34 GND 15 EDP_TXP2_R 35 NC 16 GND 36 GND 17 EDP_TXN3_R 37 GND 18 EDP_TXP3_R 38 NC 19 GND 39 NC 20 EDP_AUX_N_C 40 EDP_AUX_P_C Table 20 eDP Backlight Control & Connector Copyright © PORTWELL PCOM-C60B... -
Page 33: Table 21 Cpu Fan
COM Express™ PCOM-C60B ZR4 User Manual J26: CPU Fan Signal Name +12VL FAN_TACHIN_C FAN_PWMOUT_C Table 21 CPU Fan J33: ATX 8 Pin Connector Signal Name +12V +12V +12V +12V Table 22 ATX 8 Pin Connector Copyright © PORTWELL PCOM-C60B... -
Page 34: Table 23 Atx 24 Pin Connector
COM Express™ PCOM-C60B ZR4 User Manual J37: ATX 24 Pin Connector PIN Signal Name PIN Signal Name VCC3 VCC3 VCC3 PS_ON# ATX_POK 5VSB +12V +12V VCC3 Table 23 ATX 24 Pin Connector Copyright © PORTWELL PCOM-C60B... -
Page 35: Jumper
LVDS color depth select 3 Pin Header JP22 eSPI / LPC clock select 3 Pin Header JP24 eSPI / LPC reset select 3 Pin Header JP25 eDP / LVDS signal select 3 Pin Header Table 24 Jumper List Copyright © PORTWELL PCOM-C60B... -
Page 36: Table 25 Tpm Present On Carrier
1-2 shorts Carrier TPM present 2-3 shorts Carrier no present Table 25 TPM Present on Carrier JP6: 5VSB Select for Module Signal Name 1-2 shorts Normal 2-3 shorts NOT USE 5VSB Table 26 5VSB Select for Module Copyright © PORTWELL PCOM-C60B... -
Page 37: Table 27 1*Pcie X4 / 4*Pcie X1 Select
Table 27 1*PCIe x4 / 4*PCIe x1 Select JP8: 1*PCIe x4 / 4*PCIe x1 Select Signal Name 1-2 shorts 4*PCIE X1 (J11.J21.J7.J27) 2-3 shorts 1* PCIE X4 (J11) Table 28 1*PCIe x4 / 4*PCIe x1 Select Copyright © PORTWELL PCOM-C60B... -
Page 38: Table 29 Lvds Panel Power Select
Table 29 LVDS Panel Power Select JP10: LVDS Backlight Enable Signal Name 1-3 shorts *5V,Active High JP10 2-4 shorts 1-3 shorts 12V,Active High 4-6 shorts 3-5 shorts 5V,Active Low 2-4shorts 3-5 shorts 12V,Active Low 4-6 shorts Table 30 LVDS Backlight Enable Copyright © PORTWELL PCOM-C60B... -
Page 39: Table 31 Bios Eerom Boot From Module Or Carrier Select
Table 31 BIOS EEROM Boot from Module or Carrier Select JP12: SMA RF (COMe 3.0 SDP use) Signal Name JP12 1-2 shorts No use. connect to GND 2-3 shorts *No use. floating Table 32 SMA RF (COMe 3.0 SDP use) Copyright © PORTWELL PCOM-C60B... -
Page 40: Table 33 Usb Host Present
1-2 shorts 2-3 shorts Table 34 AT/ATX Mode Select JP19 JP19: LVDS Color Depth Select Signal Name 1-2 shorts *Normal PU 2-3 shorts Note. JP19 this option by each LVDS panel Table 35 LVDS Color Depth Select Copyright © PORTWELL PCOM-C60B... -
Page 41: Table 36 Espi / Lpc Clock Select
1-2 shorts eSPI reset 2-3 shorts *LPC reset Table 37 eSPI / LPC Reset Select JP25: eDP / LVDS Signal Select JP25 Signal Name 1-2 shorts LVDS 2-3 shorts *eDP Table 38 eDP / LVDS Signal Select Copyright © PORTWELL PCOM-C60B... -
Page 42: Miscellaneous
This section presents other functions and locations. Power / Reset button, CMOS battery etc. can be found in this section. Switch Function Remark Power Button Sleep Button Reset Button Other test (BATLOW#/LID#/CB_WAKE#/THRM#) Rapid shutdown F85281 mode select SW10 F85281 pre#/port select Button Table 39 Miscellaneous List Copyright © PORTWELL PCOM-C60B... -
Page 43: Table 40 Other Test (Batlow#/Lid#/Cb_Wake#/Thrm#)
Table 40 Other Test (BATLOW#/LID#/CB_WAKE#/THRM#) SW9: F85281 Mode Select Signal Name Auto detect /1-4 on, 2-3 on Single channel /1-4 on, 2-3 off Dual channel /1-4 off, 2-3 on Quad channel /1-4 off, 2-3 off Table 41 F85281 Mode Select Copyright © PORTWELL PCOM-C60B... -
Page 44: Ordering Guide
COM Express™ PCOM-C60B ZR4 User Manual 10 Ordering Guide Model name Status PCOM-C60B AB1-3G22Z Available Table 42 Ordering Guide Copyright © PORTWELL PCOM-C60B... -
Page 45: Pin Out Tables
USB_SSRXN_P0 USB_SSTXN_P0 LAN_LED_100# LAD0 USB_SSRXP_P0 USB_SSTXP_P0 LAN_LED_1000# LAD1 LAN_MDI2N LAD2 USB_SSRXN_P1 USB_SSTXN_P1 LAN_MDI2P LAD3 USB_SSRXP_P1 USB_SSTXP_P1 LAN_LINK# LPC_DRQ0# LAN_MDI1N LPC_DRQ1# USB_SSRXN_P2 USB_SSTXN_P2 LAN_MDI1P 33M_REF_CLK USB_SSRXP_P2 USB_SSTXP_P2 LAN_MDI0N PM_PWRBTN# USB_SSRXN_P3 USB_SSTXN_P3 LAN_MDI0P SMB_CLK USB_SSRXP_P3 USB_SSTXP_P3 VCT_LAN SMB_DAT Copyright © PORTWELL PCOM-C60B... - Page 46 N8649827 ACZ_SYNC N8649815 DDI1_LANE1+ ACZ_RST# ACZ_SDIN DDI1_LANE1- ACZ_BITCLK SPKR AUX_DDC_P_2 DDI1_LANE2+ ACZ_SDOUT I2C_CLK AUX_DDC_N_2 DDI1_LANE2- BIOS_DIS0# I2C_DATA DP_AUX_2 DP_AUX_1 THRMTRIP# THRM# USB_DN6 USB_DN7 AUX_DDC_P_3 DDI1_LANE3+ USB_DP6 USB_DP7 AUX_DDC_N_3 DDI1_LANE3- USB_OC#_6_7 USB_OC#_4_5 DP_AUX_3 USB_DN4 USB_DN5 DDI3_LANE0+ DDI2_LANE0+ Copyright © PORTWELL PCOM-C60B...
- Page 47 PEG_TXN0 GPI0 GPO1 TYPE0# N8700062 PCIE_TXP4 PCIE_RXP4 PEG_RXP1 PEG_TXP1 PCIE_TXN4 PCIE_RXN4 PEG_RXN1 PEG_TXN1 GPO2 TYPE1# TYPE2# PCIE_TXP3 PCIE_RXP3 PEG_RXP2 PEG_TXP2 PCIE_TXN3 PCIE_RXN3 PEG_RXN2 PEG_TXN2 PCIE_TXP2 PCIE_RXP2 PEG_RXP3 PEG_TXP3 PCIE_TXN2 PCIE_RXN2 PEG_RXN3 PEG_TXN3 GPI1 GPO3 PCIE_TXP1 PCIE_RXP1 Copyright © PORTWELL PCOM-C60B...
- Page 48 LVDSB_DATA#3 PEG_RXP8 PEG_TXP8 LVDSA_DATA#3 LVDS_BKLT_EN PEG_RXN8 PEG_TXN8 EDP_TXP_3_LVDSA_CLKP LVDSB_CLKP PEG_RXP9 PEG_TXP9 EDP_TXN_3_LVDSA_CLKN LVDSB_CLKN PEG_RXN9 PEG_TXN9 EDP_AUX_DP_LVDS_DDC_CLK LVDSB_BKLT_CRTL EDP_AUX_DN_LVDS_DDC_DATA 5VSB_MOD GPI3 5VSB_MOD PEG_RXP10 PEG_TXP10 5VSB_MOD PEG_RXN10 PEG_TXN10 EDP_HPD 5VSB_MOD CLK0_100M_COM_DP BIOS_DIS1# PEG_RXP11 PEG_TXP11 CLK0_100M_COM_DN VGA_R PEG_RXN11 PEG_TXN11 Copyright © PORTWELL PCOM-C60B...
-
Page 49: Table 43 Ab & Cd Row Connector Signals
A107 +12V_MOD B107 +12V_MOD +12V_MOD +12V_MOD C108 D108 A108 +12V_MOD B108 +12V_MOD +12V_MOD +12V_MOD C109 D109 A109 +12V_MOD B109 +12V_MOD +12V_MOD +12V_MOD C110 D110 A110 GND B110 GND Table 43 AB & CD Row Connector Signals Copyright © PORTWELL PCOM-C60B... -
Page 50: Industry Specifications
COM Express™ PCOM-C60B ZR4 User Manual 12 Industry Specifications The list below provides links to industry specifications that apply to PORTWELL COM Express Carrier. Low Pin Count Interface Specification, Revision 1.0 (LPC) http://www.intel.com/design/chipsets/industry/lpc.htm Universal Serial Bus (USB) Specification, Revision 2.0 http://www.usb.org/home...
