料号：

版本

11. 40011064 V1. 0

2019- 10- 30

周红娟已确认

CS200

QUICK START MANUAL

Table of Contents

Need help?

Do you have a question about the CS200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Linkzone Technology CS200

Page 1 料号：版本 11. 40011064 V1. 0 2019- 10- 30 周红娟已确认 CS200 QUICK START MANUAL...
Page 2: Package Contents
1. Package Contents CS200 Watch USB Charging Cable Quick Start Manual 2. How to Operate Charging Your Watch Properly attach the magnetic charging base to the back of the watch, then plug the charging cable into a USB port on the computer, charging dock or power bank for...
Page 3: Navigating Your Watch
Input current: <0.3A Input voltage: 5V DC Charging time: about 2 hours Note: 1. It is recommended to use the universal 5V/1A charger with certiﬁcation mark on the market. 2. Do not use fast charging charger. Navigating Your Watch Short Press Long Press 1.
Page 4: App Download
Gestures Instruction Conﬁrm to use this feature/Enter the sub-interface Tap the screen Swipe left/right Switch screen Swipe up/down Switch screen Long press the screen Change watch face from the home screen Turn on Your Watch Long press the power key to turn on your watch. If that fails, then please fully charge the watch ﬁrst.
Page 5: Wearing The Device
Connection After downloading, open the app and register an account, ﬁll in your personal information (height, weight, date of birth) truthfully, and then complete the connection according to the operation instructions on app. Note: 1. In order to connect the watch to your phone successfully, you need to turn on the Bluetooth of your phone and connect to your device through the app.
Page 6: Replace The Strap
Replace the Strap Please choose the strap with a width of 20mm if you want to replace it. 1. Remove the strap from the watch by sliding the snap lock on the strap. 2. Align the new strap with the watch and buckle the strap in. 3.
Page 7: Main Features
3. Main Features Heart Rate Monitoring Built-in PPG heart rate sensor coupled with HR algorithm, the watch can accurately monitor your heart rate after wearing. 1. The watch can monitor your 24-hour real-time heart rate, you can choose to turn on or off this function.
Page 8 Stress Measurement The watch can monitor your stress levels and your physical condition. According to the monitored results, you can reasonably adjust the training intensity & duration to prevent sports injuries. 1. Wear the watch on your wrist correctly and swipe left or right from the home screen to ﬁnd “Stress”, tap it to measure.
Page 9 3. Switch display data: long press the right key to switch the display data under swimming mode. Note: 1. CS200 is only used for swimming. If wearing for diving, it may cause damage to the device. Such damage is not within the scope of warranty.
Page 10: Sleep Monitoring
2. CS200 cannot monitor your heart rate during swimming. 3. Under the swimming mode, the touch function is automatically closed. 4. In the pool mode, please set the distance of the swimming pool correctly so as to calculate the distance and other data accurately. If the swimming distance is less than one lap, then the distance can not be calculated.
Page 11 The water resistance performance of the device is not permanently valid, it may diminish as time passes. The device can be used during washing hands, rain or swimming in the shallow water, but not support hot water shower, diving, surﬁng, etc.
Page 12: Specification Parameter
Speciﬁcation Parameter 49×37×13.7MM 150mm-250mm Physical size Adjustable strap 1.3 inch TFT color Display size Working temperature 0-40℃ square display Weight About 45g Resolution ratio 240×240 pixels Battery capacity 170mAh Li-Polymer battery 10-15 days (receive an average of 50 messages & 5 calls per day; raise your wrist to wake screen up 50 times;...
Page 13: Device Maintenance
Note: （1） Make sure that the battery level is more than 50% before upgrading. （2） During the upgrade process, you can not quit halfway if the progress bar moves, keep the screen of your phone bright, and only when the upgrade is completed can you exit the interface, otherwise, the upgrade will fail.
Page 14: Cleaning The Device
5. Avoid extreme shock and harsh treatment since it can reduce the product life. 6. Do not exposure to extremely high or low temperatures for a long time, which can cause permanent damage. 7. After each training, please rinse the watch with clean water. Cleaning the Device 1.
Page 15 （4） The device, accessories, heart rate monitor and related data are intended to be used only for exercise monitoring not medical purposes. （5） The heart rate readings are for reference only, and no liability is accepted for the consequences of any wrong interpretation. （6）...
Page 16 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
