Hi,
Thank you for getting me home
GYMNASTIC RINGS
WOODEN
SLIDER
LONG SUPPORT ROD-1
SHORT SUPPORT RODS-2
WHITE SUPPORT RODS-2
Assembly takes 30-45 minutes. Involve your child in the assembly; this will give a sense of belonging and will warm the
Unwrap the gym parts and place it as shown in the image for convenient assembly.
Secure all screws and knobs mildly during assembly. Tighten after you complete the assembly. DO NOT OVER TIGHTEN
ALLEN KEY
TOP SUPPORTER-1
BABY LADDER
WOODEN PLANK
We suggest 2 people take charge for the assembly.
child towards the gym.
KNOB SCREWS-13
ALLEN SCREWS-13
WOODEN SWING
TOP SUPPORTER-2
LEGS
Let us begin here
JUNGLE GYM
INSTRUCTION MANUAL
STEP LADDER
ROPE LADDER
Advertisement
Summary of Contents for ariro Jungle Gym
- Page 1 JUNGLE GYM INSTRUCTION MANUAL Thank you for getting me home ALLEN KEY GYMNASTIC RINGS KNOB SCREWS-13 ALLEN SCREWS-13 STEP LADDER ROPE LADDER TOP SUPPORTER-1 BABY LADDER WOODEN SLIDER WOODEN SWING LONG SUPPORT ROD-1 SHORT SUPPORT RODS-2 WHITE SUPPORT RODS-2 TOP SUPPORTER-2...
- Page 2 STEP 1 Non-threaded side of Hold the top supporter 1 (with the logo the ladders Should be placed on facing towards you), as shown in the the logo side of the top picture. Threaded supporter 1 Place the rope ladder on the left and the step ladder on the right, of the top supporter 1.
- Page 3 STEP 4 Position the legs of the gym against the Top-Supporter 2 as shown in the picture. Ensure the groves in both the legs are facing inwards. Secure the legs. STEP 5 Place one short support rod against the middle of the legs, as shown in the image and secure it.
- Page 4 STEP 7 Place one white support rod, between the legs at the bottom, in the groves provide as shown in the image. Similarly, place the other white support rod on the opposite side and secure it. STEP 8 Now move to the ladder side of the gym. Place the other short support rod in the middle.
- Page 5 STEP 10 Position the swing at the desired height and secure the knots on all four points as shown in the image. STEP 11 Tie the gymnastic rings as shown. STEP 12 Place the wooden plank as shown in the image.
- Page 6 Now gently tighten all the screws. Don’t over tight the screws WE CAN ASSIST YOU THROUGH VIDEO CALL FOR ANY DOUBTS 8939992452/ help@arirotoys.com www.arirotoys.com Happy Playing...
