- Page 1 Energy efficiency class: A ( A++ <> G) THIS PRODUCT IS NOT SUITABLE FOR PRIMARY HEATING. Instructions for use LIFESTYLE CAMILLA 3100 Catalytic heater Household appliance 0085 0086 Keep this manual for future reference. Original in Italian. SQCA.GB.08 (12.11.21)
- Page 2 This stove uses liquefied petroleum gas: the LPG cylinders are suitable for indoor use. The use of other fuels or of cylinders not indicated in this manual is forbidden. Do not store or use petrol or other flammable liquids or vapours in the vicinity of this or other appliances. Servicing must be carried out by a qualified technician.
-
Page 3: Table Of Contents
Contents 1. Introduction 2. Product description 2.1 General guidelines 2.2 Scope of application and intended use 2.3 Safety devices 2.4 Specifications 2.5 Power and consumption 2.6 Safety features 2.7 General safety warnings for installation and use 2.8 Conduct in case of gas leaks 3. -
Page 4: Introduction
TECHNICAL SPECIFICATIONS DESTINATION: TYPE OF GAS AND PRESSURE: Butane 28 mbar Category: Rated power: 3.4 kW (Hs) Max consumption: 0.24 kg/h DVGW registration number: CE-0085AQ0517 Read the instructions carefully before using the appliance. The appliance is not intended to be used by people (children included) with reduced physical, sensory or mental abilities, or without the necessary experience and knowledge, unless they have been instructed on the use of the appliance. -
Page 5: Safety Devices
basements or dormitories, in boats, recreational vehicles and in rooms located on a high floor of a building. Any other use, or the extended use of the appliance, is to be considered improper use and the user will be held responsible for any possible consequent risk. 2.3 Safety devices The product has been designed to prevent hazards thanks to the presence of the following safety devices: Thermocouple... -
Page 6: Specifications
Piezoelectric ignition This is the safest ignition method as it does not require a flame to manually ignite the appliance. Safety grid The grid present on this device prevents the risk of fire or burns: for this reason, it should never be permanently removed. - Page 7 Do not install the appliance in a room that already contains a gas cylinder (even if it is not in use) To lift or move the appliance from its intended position, use the dedicated handles. Never pull the gas hose to move the appliance. Do not move the appliance while it is operating.
-
Page 8: Conduct In Case Of Gas Leaks
2.8 Conduct in case of gas leaks If you smell gas, proceed as follows! If you smell gas, do not ignite the device and turn off at cylinder. Do not touch any switch and do not use the phone. Open doors and windows to ventilate the room. Extinguish any flame or other potential ignition sources. - Page 9 - The regulator can be fitted to any cylinders equipped with automatic valves having a diameter as indicated on the regulator. - The gas cylinder must always be used in the upright position - Whenever used outdoor, the regulator must be suitably protected against rain. - Never use a flame to look for leaks, do it using a soap solution.
-
Page 10: Instructions For Use
IMPORTANT: Never leave the Bayonet regulator onto the cylinder without being connected to the appliance. The safety in case of separation or rupture of the pipe supplying gas to the consuming appliance is not provided for being used as an open-close valve. 3.4 Checking the regulator for leaks Never use a naked flame to check for leaks. -
Page 11: Replacing The Cylinder
Instructions for using the stove 1- Place the heater in the position you prefer, following the “INSTALLATION and USE” instructions. 2- Turn on Gas at the regulator. 3- Turn the knob (N°5 - Fig.8) to the START/MAX position, push it completely and hold down for approx. -
Page 12: Cleaning And Maintenance
Maintenance 5.1 Cleaning and maintenance Ensure that the gas valve is completely closed. Do not carry out any maintenance or cleaning operations until the stove has cooled down completely. The stove must be cleaned using only and exclusively a dry cloth. Never use pointed or abrasive tools and always wait until the stove has cooled down. -
Page 13: Spare Parts
Warranty LIFESTYLE guarantees its products for a period of 2 years, provided that the following conditions are met: • the guarantee period starts on the day the stove is delivered with a purchasing document such as an invoice, a transport document or a payment receipt. •... -
Page 14: Declaration Of Conformity
Lpg cabinet heater Camilla 3100 Type: 22S (Domestic flueless heaters – UNI EN 449) The Company: TMC S.r.l. Traversa Viale del Lavoro, 1 I - 37013 CAPRINO VERONESE (VR) Hereby declares under its own responsibility that the following appliances: Camilla 3100... - Page 15 UK DECLARATION OF CONFORMITY We: TMC srl Address: Traversa Viale del Lavoro, 1- 37013 Caprino Veronese - Verona Italy Declare that Indipendent space heater (LPG) CAMILLA 3100 Satisfies the essential requirements of the Regulation 2016/426 on gas appliances as brought into UK law...
- Page 16 Permanent pilot flame power requirement Pilot flame power requirement pilot applicable) Contact details TMC srl Traversa Viale del lavoro, 1 – 37013 - Caprino Veronese - Verona - Italia (*) NOx = Nitrogen oxides...
- Page 17 Scheda prodotto / Product fiche / Tarjeta de producto / Produktkarte / Carte de produit a) Produttore / Manufacturer / Productor / Produzent / Producteur: TMC srl b) Modello / Model: Camilla 3100 c) Classe di efficienza energetica / Energy efficiency class / Clase de eficiencia energética / Energieeffizienzklasse / Classe d'efficacité...
- Page 18 Purchase from ____________________________ On _________________________________ Warranty service requested from__________________________________________________ Address_______________________________________________________________________ Problem encountered___________________________________________________________________ Note; This form must only be used for warranty claims. Manufactured from TMC srl 37013 CAPRINO VERONESE (VR) ITALY for Lifestyle Appliances Ltd, Unit 66, Enfield Ind Estate, Redditch, Worcestershire, United Kingdom...
