Summary of Contents for Sentinel SB-1200

  • Page 2 Sen�nel SB-1200 User Manual...
  • Page 3: Table Of Contents

    Contents 1.0 Machine Overview -------------------------------------- 01 2.0 Unpacking and Installa�on ---------------------------- 03 2.1 Package Contents --------------------------------------------------- 03 2.2 Installa�on and Use Loca�on ------------------------------------ 04 2.3 Installa�on Instruc�ons ------------------------------------------- 05 2.3.1 Safety Precau�ons ----------------------------------------------- 05 2.3.2 Power Supply Connec�on --------------------------------------05 2.3.3 Bill Guide Installa�on --------------------------------------------05 3.0 Control Panel and Display ----------------------------- 06 3.1 Control Panel -------------------------------------------------------- 06 3.2 Func�on Keys -------------------------------------------------------- 06...
  • Page 4 5.0 Maintenance --------------------------------------------- 16 5.1 Cleaning the Machine -------------------------------------------- 16 5.1.1 Clean the Hopper Sensor -------------------------------------- 16 5.1.2 Clean the Bill Feeding Wheel --------------------------------- 17 5.1.3 Clean the Feed Gap --------------------------------------------- 17 5.1.4 Clean the Stacker Sensors ------------------------------------- 18 5.2 Cleaning the Internal Sensors ----------------------------------- 18 5.2.1 Open the Back Cover ------------------------------------------- 19 5.2.2 Open the Internal Cover --------------------------------------- 19 5.2.3 Clean the Lower CIS Bar and UV Sensor ------------------- 20...
  • Page 5: Machine Overview

    1.0 Machine Overview Bill Guide Control Panel Display Impeller Stacker Figure 1-1 Front Diagram External Display Port Port Back Cover Printer Port Power Power Switch Cord Jack Figure 1-2 Back Diagram...
  • Page 6 Handle Hopper Feed Gap Screw Bill Feeding Wheel Figure 1-3 Top Diagram Figure 1-4 Side Diagram...
  • Page 7: Unpacking And Installa�On

    2.0 Unpacking and Installa�on 2.1 Package Contents Quan�ty Picture Item Name (Pcs) Sen�nel SB-1200 External Display Power Cable Bill Guides Calibra�on Card Cleaning Brush Cleaning Cloth Spare Fuse User Manual...
  • Page 8: Installa�On And Use Loca�On

    2.2 Installa�on and Use Loca�on As shown in figure 2-1, please keep clear of surrounding walls and reserve sufficient space for opera�on and maintenance. Installa�on Space Maintenance Space Figure 2-1 Installa�on and use loca�on...
  • Page 9: Installa�On Instruc�Ons

    2.3 Installa�on Intruc�ons 2.3.1 Safety Precau�ons 1) This machine is designed specifically for indoor use. Do not install or use outdoors. 2) Place machine on a flat and stable surface. 3) Do not use or place combus�ble materials or items around or inside the machine. 2.3.2 Power Supply Connec�on Power Supply External Dispiay...
  • Page 10: Control Panel And Display

    3.0 Control Panel and Display 3.1 Control Panel Display Area Opera�onal Keys Opera�onal Keys Figure 3-1 Display Appearance 3.2 Func�on Keys Auto/ Manual Key - Toggle between automa�c start and manual start. Naviga�on Keys SNC Key - Ac�vate or disable the serial number reading func�on. Speed Key - Change coun�ng speed.
  • Page 11: Display Interface

    Currency Key - Select desired currency. Mode Key - Select coun�ng. mode (hold to set CFD level). Batch Key - Access batch coun�ng func�on. Add Key - Ac�vate or disable the adding func�on. Start Key - Start or restart coun�ng. Back/ ESC Key - Stop the count or return to previous screen.
  • Page 12: Opera�Ng Instruc�Ons

    4.0 Opera�ng Instruc�ons 4.1 Start-up A�er connec�ng the machine to a power source, flip the power switch to the on posi�on. The machine will perform a brief self-check, which takes about 20 seconds. Ini�alizing Self-Check, Please Wait... Figure 4-1 Start-Up Screen The machine will spin the banknote processing wheels several �mes before entering the main coun�ng screen, as shown in figure 4-2.
  • Page 13: Coun�Ng Mode

    4.2 Coun�ng Mode The default coun�ng mode is MDC. You can cycle between the three coun�ng mode op�ons by pressing the MODE key on the control panel. 4.2.1 MDC Mode In MDC mode, the counter will count all denomina�ons of the selected currency, recording both the total value of the bills counted, as well as the total number of bills counted.
  • Page 14: Cnt Mode

    Figure 4-5 SDC Mode Figure 4-6 SDC Mode a�er coun�ng 4.2.3 CNT Mode In CNT mode, the counter will only count the number of bills, and it does not track the denomina�on of the bills or the currency. NOTE: while using CNT mode, counterfeit detec�on is disabled.
  • Page 15: Automa�C Currency Recogni�On

    4.3.1 Automa�c Currency Recogni�on When the currency is set to AUTO, the counter will automa�cally recognize the currency of the first bill it counts. The flag and 3-digit code for this currency will appear in the top le� corner of the display, and the machine will count all denomina�ons of the currency.
  • Page 16: Op�Onal Coun�Ng Func�Ons

    4.4 Op�onal Coun�ng Func�ons 4.4.1 Automa�c Start When automa�c start is enabled, the machine will start coun�ng as soon as bills are placed into the hopper. If automa�c start is disabled, the machine will not start coun�ng un�l you press the START key. Automa�c Start is on by default, and can be enabled or disabled by pressing the AUTO/ key.
  • Page 17: Adding Func

    The batch quan�ty can be changed by pressing the arrow keys. Pressing the will increase the batch by 10, pressing the key will decrease the batch by 10, pressing the key will increase the batch by 1, and pressing the key will decrease the batch by 1.
  • Page 18: Count Detail Report

    Figure 4-15 Speed Indicator 4.6 Count Detail Report A�er performing a count in MDC or SDC mode, you can view the count details by pressing the REPO key. The report includes the total number of bills counted, the total value counted, as well as a breakdown of each denomina�on counted. Press the BACK/ key to return to the main count screen.
  • Page 19: Count Detail Prin�Ng

    4.7 Count Detail Prin�ng If the machine is connected to a printer, the count details can be printed. A�er performing a count, press the PRINT key to enter the print menu. Figure 4-18 Print Menu Press the key to print the count details. If serial number capture was enabled during the count, the serial numbers of the bills counted will be printed as well.
  • Page 20: Maintenance

    5.0 Maintenance Regular cleaning and calibra�on are required to maintain op�mal opera�on of your bill counter. 5.1 Cleaning the Machine Circulated bills collect dust, dirt and grime that can impair the opera�on of your bill counter’s sensors and feeding system. Any dirt or dust stuck to the sensors can cause error messages and erroneous coun�ng results.
  • Page 21: Clean The Bill Feeding Wheel

    5.1.2 Clean the Bill Feeding Wheel As shown in Figure 5-2, clean the bill feeding wheel with a nylon brush or cleaning cloth. Bill Feeding Bill Feeding Wheel Wheel Figure 5-2 Bill Feeding Wheel 5.1.3 Clean the Feed Gap As shown in Figure 5-3, clean the feed gap with a nylon brush. Figure 5-3 Feed Gap...
  • Page 22: Clean The Stacker Sensors

    5.1.4 Clean the Stacker Sensors As shown in Figure 5-4, clean the stacker sensors with a nylon brush or cleaning cloth. Stacker Sensor Stacker Sensor Figure 5-4 Stacker Sensors 5.2 Cleaning the Internal Sensors Open the back cover to access and clean the internal sensors. NOTE: Please move the power switch to the off...
  • Page 23: Open The

    5.2.1 Open the Back Cover As shown in Figure 5-5, open the back cover. Figure 5-5 Open Back Cover 5.2.2 Open the Internal Cover As shown in Figure 5-6, open the internal cover. Press the handle down firmly to release the internal cover. The Handle of Internal Back Cover...
  • Page 24: Clean The Lower Cis Bar And Uv Sensor

    5.2.3 Clean the Lower CIS Bar and UV Sensor As shown in Figure 5-7, clean the lower CIS bar with a cleaning cloth and clean the UV sensor with a nylon brush. Lower UV Lower CIS Figure 5-7 Lower Sensors 5.2.4 Clean the Upper CIS Bar As shown in Figure 5-8, clean the upper CIS bar with a cleaning cloth.
  • Page 25: Feed Gap Calibra�On

    Bill jams can be caused by the following: 1) Foreign Objects - the bill channel is blocked by a foreign object (rubber band, paper clip, tape, etc). Open the back cover, remove any foreign objects or debris, and clean the internal sensors. 2) Feed Gap - the feed gap is set either too �ght or too loose.
  • Page 26 Turn the feed gap screw clockwise to make the feed gap wider, and counterclockwise to make the feed gap narrower. Figure 5-12 Wider Figure 5-13 Narrower Fine tune the feed gap as follows: 1) Disable automa�c start by pressing the AUTO key. 2) Insert a single bill into the gap between the rollers, as shown in Figure 5-14.
  • Page 27 Figure 5-15 Check The Gap 3) If the bill does not fit into the gap, or is hard to fit into the gap, this means the feed gap is set too small. Rotate the feed gap screw clockwise to open the gap wider. 4) If the bill fits loosely into the gap, or you can fit more than one bill at once, this means the feed gap is set too wide.
  • Page 28: Technical Specifica�Ons

    6.0 Technical Specifica�ons Image (Dual CIS), Magne�c, Infrared, Ultraviolet Counterfeit Detec�on Double note detec�on, half note detec�on, Error Detec�on chain note detec�on Supported Currencies USD, CAD, MXN, EUR, GBP, CHF, COP and CRC Hopper Capacity 500 bills Stacker Capacity 200 bills 800, 1000 pcs/min (MDC &...
