Summary of Contents for Salamander Designs DYNO 102 MED
- Page 1 DYNO 102 MED UNIVERSAL ADAPTER Installation Manual Manual De Instalación Manuel d’Installation UP TO 42” 100 LB 45 KG www.SalamanderDesigns.com...
- Page 2 Must be used in conjunction with Dyno 102 Medium. E NG E SP Uso conjuntamente con Dyno 102 Medium. FR A Utilisation en même temps que Dyno 102 Medium. FR A...
- Page 3 Align Bracket by extending and spreading arms to accommodate mounting pattern on the back of the TV. Alinee el Soporte por medio de extender y desplegar los brazos para acomodar el patrón de montaje en la parte trasera del televisor. Aligner le support en étendant et en ouvrant les bras pour permettre le modèle de montage sur l’arrière du téléviseur.
- Page 4 Note: Remove plastic slide covers from screw mounting locations. Nota: Quite las cubiertas deslizantes de plástico de las ubicaciones para montar los tornillos. Note: Retirer les protections glissantes en plastique des emplacements servant au montage des vis.
- Page 5 Attach to TV using mouting screws. Refer to TV manufacturer installation manual to determine the correct mount screw size. Fijación a la TV con tornillos de montaje. Para determinar el tamaño correctos E SP tornillos de montaje, consulte el manual de instalación del fabricante del televisor. Attache à...
- Page 6 Note: Adapter Spacers can be utilized in applications where interferences at back of TV prevent proper fi t of Adapter Bracket. Nota: Se pueden utilizar Espaciadores de Adaptador en aplicaciones en que interferencias en la parte trasera del televisor impiden el ajuste correcto del Soporte Adaptador Universal.
- Page 7 Hook and secure onto Dyno 102 Medium mount assembly. Enganche y asegure sobre Dyno 102 Medium ensamblaje de montaje. Accrochez et fi xez et sur Dyno 102 Medium support.
-
Page 8: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Carefully inspect the mount for shipping damage or missing parts. If any damage is apparent or you are missing parts contact Salamander Designs at 800-535-5659. Read ALL assembly instructions before assembly. If you have any questions, please contact your installation contractor or Salamander Designs. - Page 9 SALAMANDER DESIGNS LIMITED WARRANTY Salamander Designs Ltd. (Salamander) provides the following Limited Warranty. The Limited Warranties herein described for the specific products listed below shall be in lieu of any other warranty, expressed or implied, including but not limited to any implied warranty of merchantability or fitness for...
