testo 868s thermal imager
Instruction manual
Analysis software
testo IRSoft
Use the testo IRSoft software to
analyze your thermal images
extensively and in detail, and to
create professional reports. You can
download the software free of charge
and licence-free via the following link:
www.testo.com/irsoft
testo Thermography App
Use the testo Thermography App to
transfer thermal images live to your
smartphone/tablet and create quick
analyses and simple reports directly
on site.
Download the app free of charge for
Android or iOS from the app store:
testo Thermography
App

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the testo 868s and is the answer not in the manual?

Questions and answers

Summary of Contents for ICS Schneider Messtechnik testo 868s

  • Page 1 868s thermal imager Instruction manual Analysis software testo Thermography App testo IRSoft Use the testo IRSoft software to Use the testo Thermography App to analyze your thermal images transfer thermal images live to your extensively and in detail, and to smartphone/tablet and create quick create professional reports.

  • Page 3: Table Of Contents

    Contents Contents Safety and disposal ................3 About this document ................3 Security ....................3 Disposal ....................4 Technical data ..................5 General technical data ................5 Description of the instrument ............. 8 Use ......................8 Instrument / operating elements overview ..........8 Displays overview ...................
  • Page 4 Contents Image type ................... 28 Configuration ..................28 Settings ....................28 6.8.1 SuperResolution .................. 29 6.8.2 Save JPEG ..................29 6.8.3 Configure key..................30 6.8.4 Ambient conditions ................30 6.8.5 Info ....................... 30 6.8.6 Certificates ................... 31 6.8.7 Fullscreen mode .................. 31 6.8.8 Reset options ..................

  • Page 5: Safety And Disposal

    1 Safety and disposal 1 Safety and disposal About this document The instruction manual is an integral part of the instrument. • Keep this documentation to hand so that you can refer to it when necessary. • Always use the complete original instruction manual. •...

  • Page 6: Disposal

    1 Safety and disposal Only use the batteries supplied in accordance with the instructions in the • instruction manual. Do not short-circuit the batteries. • Do not take the batteries apart and do not modify them. • • Do not expose the batteries to heavy impacts, water, fire or temperatures in excess of 60 °C.

  • Page 7: Technical Data

    2 Technical data 2 Technical data General technical data Infrared image output Feature Values Infrared resolution 160 x 120 Thermal sensitivity (NETD) < 80 mK Field of view (FOV) / min. 31° x 23° / <0.5 m focusing distance Geometric resolution (IFOV) 3.4 mrad SuperResolution 320 x 240 pixels / 2.1 mrad...
  • Page 8 2 Technical data Emissivity/reflected 0.01 to 1/manual temperature adjustment Analysis functions - Center spot - Hot/cold spot detection - Delta T IFOV warner Included in the scope of delivery testo ScaleAssist Included in the scope of delivery Imager features Feature Values Digital camera Included in the scope of delivery...
  • Page 9 2 Technical data Charging time in charging Approx. 5 h via mains unit station USB interface 1.8 A* Direct current Ambient conditions Feature Values Operating temperature -15 to +50°C Storage temperature -30 to +60°C Humidity 20 - 80 %RH, not condensing Housing protection class IP54* according to IEC 60529 Vibration...

  • Page 10: Description Of The Instrument

    3 Description of the instrument 3 Description of the instrument The instrument is a handy, robust thermal imager. You can use it to undertake the non-contact measurement and display of surface temperature distribution. Areas of application • Building inspection: Energy efficiency rating of buildings (heating, ventilation, air-conditioning trade, building engineers, engineering firms, experts) Production monitoring / quality assurance: monitoring of production •...

  • Page 11: Displays Overview

    3 Description of the instrument Element Function 6 Infrared camera lens; Takes infrared images; protects the lens protective cap 7 Digital camera Takes real images Trigger Saves the displayed image 9 Battery compartment Contains the rechargeable battery 3.1 Displays overview Element Function 1 Status bar...

  • Page 12: Power Supply

    3 Description of the instrument Element Function 5 Scale - Temperature unit - temperature margin of the image displayed, showing the minimum/maximum reading (with automatic scale adjustment) or the selected minimum/maximum display value (with manual scale adjustment) 6 E ... Emissivity set 7 A, M or S A - automatic scale adjustment...

  • Page 13: Operation

    4 Operation 4 Operation Commissioning Please refer to the commissioning instructions supplied for testo 865s, 868s, 871s, 872s (0973 8723). 4.2 Switching instrument on and off Switching on the camera - Remove protective cap from the lens. - Press  The camera starts.

  • Page 14: Getting To Know The Menu

    4 Operation - Press and hold down until the progress bar is complete.  The display goes off.  The camera is switched off. 4.3 Getting to know the menu to open the Menu. - Press - Move the joystick to highlight a function (orange border).

  • Page 15: Quick Select Button

    4 Operation Menu - Return to the main menu: Select and move the joystick to the left or press Esc. 4.4 Quick select button The quick select button is another navigation option that you can use to call up certain functions simply at the touch of a button. Quick select menu items Menu item Function...
  • Page 16 4 Operation - Move the joystick up/down until the orange box appears around the required menu item. - Press OK.  The quick select button is assigned to the selected menu item.  The icon for the selected function is displayed bottom right.

  • Page 17: Wlan Connection - Using The App

    5 WLAN connection - using the App 5 WLAN connection - using the App Activating/disabling the connection To connect via WLAN, you need a tablet or smartphone with the testo Thermography App already installed on it. You can get the App from the App Store for iOS devices or from the Play Store for Android devices.

  • Page 18: Select Display

    5 WLAN connection - using the App - Press Connect.  The WLAN connection to the thermal imager is established. Select display 5.2.2 Second display The WLAN connection to the thermal imager is established.  Selection → display.  The display on the thermal imager is shown on your mobile end device.

  • Page 19: Performing The Measurement

    6 Performing the measurement 6 Performing the measurement CAUTION High thermal radiation (e.g. due to sun, fire, furnaces) Detector may be damaged! - Do not point the camera at objects with temperatures > 650 °C. Ideal framework conditions Building thermography, investigating the building shell: •...

  • Page 20: Activating/Disabling Pixel Mark

    6 Performing the measurement  The submenu with the measurement settings opens: Pixel mark: • Center spot: the temperature measuring point in the centre of the image is marked with white crosshairs and the value is displayed. Coldspot, Hotspot: the lowest or highest temperature measuring point is marked with blue or red crosshairs and the value is displayed.

  • Page 21: Saving An Image

    6 Performing the measurement  Measurement settings menu opens. - Select Differential temperature and press OK. Active and press OK. - Select - Select which differential temperature is to be calculated (P A vs. P B, P A vs. Probe, P A vs. Value, P A vs. RTC). - P A vs.

  • Page 22: Image Gallery

    6 Performing the measurement  An infrared image is saved with a real image attached. If a higher resolution is required: in the menu, select Configuration → SuperResolution for four times as many readings. 6.3 Image gallery Saved images can be displayed, analysed or deleted. File names Designation Explanation...
  • Page 23 6 Performing the measurement When SuperResolution is enabled, 2 images are saved in the image gallery (an image, and an image). The high-resolution SuperResolution image is saved in the background. In the status bar, the number of SuperResolution images to be saved is displayed (for example: SR(1) ).

  • Page 24: Setting The Scale

    6 Performing the measurement For a description of the individual functions, please read the information in the relevant sections. Delete image Image gallery - Select function.  All saved images are displayed in the form of an infrared image preview. - Move joystick to select an image.
  • Page 25 6 Performing the measurement Auto-scaling continuously adjusts the scale to the readings presented, and the colour assigned to a temperature value changes. In manual scaling fixed limit values are defined, and the colour assigned to a temperature value is fixed (important for visual image comparisons).

  • Page 26: Setting Emissivity And Reflected Temperature

    6 Performing the measurement The ScaleAssist function calculates a display-neutral scale depending on the inside and outside temperature. This scale graduation can be used to detect structural defects in buildings. Scale - Select the function. - Press OK. joystick ScaleAssist - In the mode menu, move the up/down until selected.
  • Page 27 6 Performing the measurement Because of their low or non-uniform emissivity, bright metals and metal oxides only have limited suitability for infrared measurement. Highly inaccurate measurements should be expected. A remedy for this is coatings that increase emissivity, e.g. paint or emission adhesive (accessory: 0554 0051), which must be applied to the object to be measured.

  • Page 28: Selecting The Emissivity

    6 Performing the measurement readings) or much higher temperatures (such as ovens or machines) are in proximity to the object being measured should the radiation temperature of these sources be determined and used. The reflected temperature has little effect on objects with high emissivity. Further information can be found in the Pocket Guide.
  • Page 29 6 Performing the measurement  RTC and emissivity are automatically adjusted. - Press OK. If it is not physically possible to determine the emissivity due to the same object temperature and reflected temperature, the input field opens again. The emission value must be input manually.

  • Page 30: Selecting The Colour Palette

    6 Performing the measurement 6.6 Selecting the colour palette This function is only available if the Image type is set to infrared image. - Select the Palette function. - Move the joystick up/down to select the required colour palette and then press OK.

  • Page 31: Superresolution

    6 Performing the measurement Temperature unit The temperature unit can be set. - Select Configuration → Settings → Temperature unit. joystick - Move the up/down to select the required unit and then press OK. Power-save options The illumination intensity of the display can be set. A lower intensity increases the battery life.

  • Page 32: Configure Key

    6 Performing the measurement - Press OK. - Move the joystick up/down until On/Off is selected. - Add a date/time stamp to a JPEG file if required. Turn function on or off for this. - Select and press OK. ✔ Configure key 6.8.4 Menu...

  • Page 33: Certificates

    6 Performing the measurement Connectivity • Certificates 6.8.7 Select Menu → Configuration → Certificates. - Displays the radio certificates for the instrument.  Fullscreen mode 6.8.8 The scale and the quick select button function indicator can be hidden. Menu Configuration Fullscreen mode.
  • Page 34 6 Performing the measurement Menu Configuration Reset options. → → - Select the Factory settings function.  Apply factory settings? is displayed. - Select and press to reset to factory settings. ✔ - Press or select and press to cancel the process. Formatting The image memory can be formatted.

  • Page 35: Maintenance

    7 Maintenance 7 Maintenance 7.1 Charging the rechargeable battery - Open the cover of the interface terminal. - Connect the recharger cable to the Micro-USB interface. - Connect the mains unit to a mains socket.  The charging process starts. If the battery has been completely drained, the charging time is approx.
  • Page 36 7 Maintenance - Switch the instrument off. - Open battery compartment. - Release the battery and remove.

  • Page 37: Cleaning The Instrument

    7 Maintenance - Insert new battery and slide upwards until it clicks into place. - Close the battery compartment. 7.3 Cleaning the instrument Cleaning the instrument housing - The interface terminal is closed.  - The battery compartment is closed. - Rub down the surface of the instrument with a damp cloth.

  • Page 38: Firmware Update

    7 Maintenance Firmware update The current firmware version is available at www.testo.com. There are two options available: Performing an update using IRSoft or • Performing an update with the thermal imager • Downloading firmware - Download firmware: Firmware-testo-865-872.exe - Unzip file: double-click on the exe. file ...

  • Page 39: Performing An Update With The Camera

    7 Maintenance In certain circumstances, the camera reports: Firmware update finished. Please restart the device. A restart is not performed. Action: - After 10 seconds, switch off the camera; switch back on again after 3 seconds. The current firmware version is displayed. ...

  • Page 40: Tips And Assistance

    8 Tips and assistance 8 Tips and assistance Questions and answers Question Possible cause / solution Error! Memory full! Insufficient memory available: Transfer images displayed. to the PC or delete. Error! Permissible Switch off the camera, allow the instrument to instrument temperature cool down and observe the permissible exceeded!

  • Page 41: Authorisations And Certification

    9 Authorisations and certification 9 Authorisations and certification Please refer to the commissioning instructions supplied for testo 865s, 868s, 871s, 872s (0973 8723).
