- Page 1 T O W E L W A R M E R INSTRUCTION MANUAL...
- Page 2 TO W E L WARM E R INSTRUCTION MANUAL Before using this product. Please read the following instructions carefully and keep this pamphlet for future reference. ABOUT THE PRODUCT This heated towel rail is designed for drying towels or clothes. It has a surface stabilized temperature of 40°C -50°C (104°F -122°F) and it used in household bathrooms and kitch- ens.
- Page 3 REQUIRED TOOLS Pencil Tape Measure Hammer Cross screwdriver Electric Drill Leveling instrument ACCESSORIES LIST Power cord outlet wall bracket 3pcs Normal wall bracket Hardwired wall bracket Hardwired wall panel 4pcs 4pcs 4pcs 4pcs 4pcs 2pcs Long screw Tapping Wall M5 inner hex Screw Bushing M6 x 45mm...
- Page 4 INSTALLATION STEPS Drill the long screw (3) through the normal wall bracket (1) Screw down the long screw (3) to firmly connect the normal wall bracket (1) to the vertical bar. Note that the set screw on the wall bracket should towards the floor when the unit is installed.
- Page 5 INSTALLATION STEPS Drill A, B, C, D holes with size Ø 8*D45mm. Use hammer to knock wall anchor (5) into the wall completely. Insert the tapping screw (4) through bushing (6). Then into the wall anchor (5), make sure bushing (6) is firmly connected to the wall.
- Page 6 INSTALLATION FOR HARDWIRED Cut off the plug. Take out the wall bracket (1). Connect hardwired wall bracket and panel (2) by screw (10). Screw down the screw (9) to firmly connect the hardwired wall bracket (2) to the vertical bar. Fix the hardwired wall panel with screw (9).
- Page 7 AVAILABLE MODELS & DIMENSIONS GEORGIA GUSTAVO GIOVANNA...
