Summary of Contents for DirectOut Technologies ANDIAMO
- Page 1 ANDIAMO Hardware Guide Version 1.0...
- Page 2 DirectOut GmbH cannot be held responsible for any misleading or incorrect information provided throughout this manual. DirectOut GmbH reserves the right to change specifications at any time without notice. DirectOut Technologies® is a registered trademark of the DirectOut GmbH. © DirectOut GmbH, 2022 page 2 of 48...
-
Page 3: Table Of Contents
Connecting Management ................32 Connecting MADI ..................33 Connecting Audio Network ................. 33 Connecting Analog ..................34 CHAPTER 5: Menu Navigation CHAPTER 6: Troubleshooting and Maintenance Troubleshooting ................... 39 Maintenance ....................39 ANDIAMO Hardware Guide - Version 1.0 page 3 of 48... - Page 4 CHAPTER 7: Technical Data Appendix A - DSUB-25 Pin assignment Appendix B - Firmware Update Index page 4 of 48 ANDIAMO Hardware Guide - Version 1.0...
-
Page 5: About This Manual
N OT E S are used for important points of clarification or cross references. WAR NI N GS! alert you when an action should always be observed. ANDIAMO Hardware Guide - Version 1.0 page 5 of 48... -
Page 6: Chapter 1: Overview Introduction
CHAPTER 1: Overview CHAPTER 1: Overview Introduction Welcome to the third generation of ANDIAMO, DirectOut's successful AD/DA converter for 32 audio channels. Evolving the legacy it features two MADI ports and an audio network option supporting RAVENNA or Dante or SoundGrid. -
Page 7: Feature Summary
(84 V to 264 V AC / 47 Hz to 63 Hz / safety class 1) * available soon Applications ANDIAMO can be used for conversion, monitoring, recording and routing of analog and digital signals. Typical applications include: • monitoring digital audio •... -
Page 8: Chapter 2: Legal Issues & Facts
We would like to remind you to please check carefully whether the failure is caused by erroneous configuration, operation or connection before sending parts for repair. page 8 of 48 ANDIAMO Hardware Guide - Version 1.0... -
Page 9: First Aid (In Case Of Electric Shock)
Check their pulse and reanimate if their respiration is poor. Lay the body down and turn it to one side. Call for a doctor immediately. • Having sustained an electric shock, always consult a doctor. ANDIAMO Hardware Guide - Version 1.0 page 9 of 48... -
Page 10: Updates
This guide refers to firmware version 1.0. Intended Operation ANDIAMO is designed for conversion / routing between analog, digital and audio network signals. Digital audio refers to AES10, audio network refers to Dante, SoundGrid and RAVENNA (including AES67 and SMPTE ST 2110-30 / -31). -
Page 11: Conformity & Certificates
Germany Only stamped parcels will be accepted! WEEE-Reg.-No. DE 64879540 Contact DirectOut GmbH Leipziger Str. 32, 09648 Mittweida, Germany Phone: +49 (0)3727 5665-100 Fax: +49 (0)3727 5665-101 Mail: sales@directout.eu www.directout.eu ANDIAMO Hardware Guide - Version 1.0 page 11 of 48... -
Page 12: Contents
CHAPTER 2: Legal issues & facts Contents The contents of your ANDIAMO package include: • 1 x ANDIAMO (19’’, 1 RU) • 2 x power chord • 1 x Instruction Leafl et Transceiver for the MADI SFP ports may be delivered separately and require installation fi... -
Page 13: Accessories
The BREAKOUT series is a range of adaptor boxes available in different variants to extend the coverage of the ANDIAMO and PRODIGY series. They are equipped with XLR or BNC connectors on the front panel and DSUB-25 connectors on the rear panel. - Page 14 Digital patch cable for connection with DOCAA0332 BREAKOUT.AES or AESid transferring 8 audio channels, length 0.5 m DSUB25.AES100 Digital patch cable for connection with DOCAA0333 BREAKOUT.AES or AESid transferring 8 audio channels, length 0.5 m page 14 of 48 ANDIAMO Hardware Guide - Version 1.0...
- Page 15 - 5.00 dBm - 3.00 dBm (Receiver overload) Temperature (min) 0° Celsius 0° Celsius Temperature (max) 70° Celsius 70° Celsius Type of DDM/DOM internal internal Extinction Ratio 8.20 dB 9 dB ANDIAMO Hardware Guide - Version 1.0 page 15 of 48...
-
Page 16: Chapter 3: Installation
Do not cover the fan outlets and the slots at the sides of the device! Do not block the fans by putting objects through the protective grid! Insert the transceivers for the MADI SFP ports. Connect the signal cables for MADI and audio network. page 16 of 48 ANDIAMO Hardware Guide - Version 1.0... - Page 17 Using the power cord provided connect the PSUs to a matching power supply. The delivered power cords provide a self-locking mechanism to prevent an accidental disconnect. To unlock the connection press the red release mechanism. ANDIAMO Hardware Guide - Version 1.0 page 17 of 48...
- Page 18 Select the port of the network where your device is connected to Sidebar - My Devices - Click Discovery Methods and set Ethernet Discovery to ‘ON’ Select the device from the list and click 'Add' page 18 of 48 ANDIAMO Hardware Guide - Version 1.0...
- Page 19 5002, 5003 and 5004 are fi ltered. N OT E The IP address of the device is either fi xed to 10.0.0.32 or obtained from a DHCP service (default) - see "IP Reset" on page 23 ANDIAMO Hardware Guide - Version 1.0 page 19 of 48...
-
Page 20: Chapter 4: Operation Introduction
• 44.1 kHz or 48 kHz = 1 FS • 88.2 kHz or 96 kHz = 2 FS • 176.4 kHz or 192 kHz = 4 FS page 20 of 48 ANDIAMO Hardware Guide - Version 1.0... -
Page 21: Global Control
Note that an unlit LED does not guarantee that the device is free of voltage. To ensure that the device is completely disconnected from mains voltage, the power chords must be disconnected. ANDIAMO Hardware Guide - Version 1.0 page 21 of 48... -
Page 22: Menu Control
• Input - level (gain & trim), mute, polarity • Output - level, mute, polarity • single channel routing • EARS for MADI and audio network • MADI redundancy switchable page 22 of 48 ANDIAMO Hardware Guide - Version 1.0... - Page 23 PSU 2: Enable DHCP • push SET to acknowledge your selection • to cancel, don't push a button; the front panel will return to its normal mode after 10 seconds ANDIAMO Hardware Guide - Version 1.0 page 23 of 48...
-
Page 24: Clocking
LED - indicates use of internal clock generator as clock source (ON, green) = clock source set to internal generator (OFF) = clock source set to external input page 24 of 48 ANDIAMO Hardware Guide - Version 1.0... -
Page 25: Sample Rates
In Legacy mode, which most MADI devices on the market are still exclusively using, for example a 96 kHz signal could be transmitted using 48 kFrame type (S/MUX). '96k Frame' defi nes a '2 FS' signal (e.g. 96 kHz). ANDIAMO Hardware Guide - Version 1.0 page 25 of 48... -
Page 26: Level Meters
LED - indicates signal level of channel input. (ON, green) = analog output signal equals to more than -80 dBFS. The light intensity of the LEDs depends on the audio level. page 26 of 48 ANDIAMO Hardware Guide - Version 1.0... - Page 27 CHAPTER 4: Operation This page is left blank intentionally. ANDIAMO Hardware Guide - Version 1.0 page 27 of 48...
-
Page 28: Signal Routing
Mode / Parameter Bank Routing Matrix Mode input level adjust, mute, polarity output level adjust, mute, polarity signal routing entire port / bank single channel EARS switchable MADI redundancy forced switchable page 28 of 48 ANDIAMO Hardware Guide - Version 1.0... - Page 29 SOURCE MADI Redundancy optional physical inputs to any physical EARS @ MADI I/O optional output M A D I BANK 01.. 32 3 3 .. 64 ANDIAMO Hardware Guide - Version 1.0 page 29 of 48...
- Page 30 If the MAIN signal source fails, EARS automatically switches to the BACKUP signal. The audio network is divided into NET A and NET B to cover streams with more than 64 channels. page 30 of 48 ANDIAMO Hardware Guide - Version 1.0...
- Page 31 The selected signal routing effects the usage of MADI Redundancy and EARS. MADI Redundancy EARS Bank Routing forced NET, MADI Matrix Mode MADI Redundancy disables EARS from the MADI I/Os. ANDIAMO Hardware Guide - Version 1.0 page 31 of 48...
-
Page 32: Connecting Word Clock
The word clock input also accepts a AES3 frame (AES11). Termination (75 Ω) for the word clock input is switchable locally or via remote control. Connecting Management ANDIAMO uses separate network links for managing the device and network audio transmission. RJ 45 socket (1 Gbit/s) MGMT Connect here for network control and fi... -
Page 33: Connecting Madi
Insert SFP transceiver here and connect MADI input/output. * matching SFP transceiver are available from DirectOut - page 15. Connecting Audio Network ANDIAMO can host one audio network card optionally*. Audio network is connected via 2 x RJ45-sockets (Gigabit-Ethernet). RJ45 socket (1 Gbit/s) -
Page 34: Connecting Analog
Analog audio input (balanced) - connect audio channels 25 to 32 here The pinout complies with AES59 (‘TASCAM pinout’) - see „Appendix A - DSUB-25 Pin assignment“ on page 42. page 34 of 48 ANDIAMO Hardware Guide - Version 1.0... - Page 35 The line output is not servo balanced. Do not connect the negative lead to ground. This may cause damage at the output stage. Observe the technical specifications listed in this document. ANDIAMO Hardware Guide - Version 1.0 page 35 of 48...
-
Page 36: Chapter 5: Menu Navigation
NOT E Blinking LEDs are also used to indicate an error (e.g. missing sync). Concentrate on the section where one LED is blinking and the remaining LEDs are glowing weak. page 36 of 48 ANDIAMO Hardware Guide - Version 1.0... - Page 37 M A D I BANK BANK BANK BANK 01.. 32 01.. 32 01.. 32 01.. 32 3 3 .. 64 3 3 .. 64 3 3 .. 64 3 3 .. 64 SELECT ANDIAMO Hardware Guide - Version 1.0 page 37 of 48...
- Page 38 CHAPTER 5: Menu Navigation This page is left blank intentionally. page 38 of 48 ANDIAMO Hardware Guide - Version 1.0...
-
Page 39: Chapter 6: Troubleshooting And Maintenance
To clean the device, use a soft, dry cloth. To protect the surface, avoid using cleaning agents. N OT E The device should be disconnected from the power supply during the cleaning process. ANDIAMO Hardware Guide - Version 1.0 page 39 of 48... - Page 40 • Frequency response: -0.15 dB (10 Hz) / -0.15 dB (20 kHz) • Input impedance: 20 kΩ (balanced) / 10 kΩ (unbalanced) • Input level: + 24 dBu (variants: + 15 dBu or +18 dBu) page 40 of 48 ANDIAMO Hardware Guide - Version 1.0...
- Page 41 Word Clock • 1 x BNC socket (75 Ω impedance) - input • 1 x BNC socket (75 Ω impedance) - output • Termination 75 Ω switchable • AES11 (DARS supported) ANDIAMO Hardware Guide - Version 1.0 page 41 of 48...
- Page 42 CH 1 OUT + CH 4 − CH 4 IN − CH 3 + CH 3 IN + CH 2 − CH 2 IN − CH 1 + CH 1 IN + page 42 of 48 ANDIAMO Hardware Guide - Version 1.0...
- Page 43 Firmware and the system of ANDIAMO can be updated via a browser-based user interface: Open your browser and surf <ANDIAMO IP ADDRESS>:8080 Select an ANDIAMO update fi le (.upd) from your fi le system and click 'Upload'. After the upload is fi nished, an update information page will be displayed.
- Page 44 Appendix B - Firmware Update page 44 of 48 ANDIAMO Hardware Guide - Version 1.0...
- Page 45 Frequency response ........ 40 Fuses ............40 Updates ........... 10 globcon ............ 12 Warranty ..........10 Impedance (input/output) ......41 Intended Operation ........10 IP Reset ........... 23 Latency (AD/DA) ........41 Level ANDIAMO Hardware Guide - Version 1.0 page 45 of 48...
- Page 46 Notes page 46 of 48 ANDIAMO Hardware Guide - Version 1.0...
- Page 47 Notes ANDIAMO Hardware Guide - Version 1.0 page 47 of 48...
- Page 48 DirectOut GmbH Leipziger Strasse 32 T: +49-3727-5665-100 09648 Mittweida F: +49-3727-5665-101 Germany www.directout.eu...
