Summary of Contents for COX l2T
- Page 1 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2020 2019 2018 2017 2016 2015 2014 2013 2012 2011 WARNING 2010 Read this manual. Serious injury or death can result if safety instructions are not followed.
- Page 2 Engine is shipped without oil. - Before starting engine, fill with SAE 10W-30 motor oil. - See engine manual for engine oil capacity. Hydraulic Oil Tankis shipped withoutoil. - When adding oil, verify oil level is 1 level from top of hydraulic reservoir (not including fill neck).
-
Page 3: Table Of Contents
Table of Contents ！ Important Safety Rules………………………………………………4-5 Machine Component Definitions………………….…………………6 ！ Component Parts………………………………….…………………7 ！ Operation Instructions……………………………………………….8-9 ！ Proper Operation of the Log Splitter………………………..8 Vehicle Towing & Working………………………………….9 ！ Maintenance and Storage……………………………………………10 Troubleshooting…………………….…………………………………….11 Specifications………………….………………………………………….12 Assembly Instruction……………………………………………………. 13-15 Parts Explosion…………………………………………………………..16-18... -
Page 4: Important Safety Rules
Important Safety Rules ！ ！ WARNING 1.) Read this manual completely. Serious injury or death can result if safety instructions are not followed. Everyone who operates the log splitter must read and completely understand all safety rules, operating instructions, and maintenance instructions. - You must be 16 or older to operate this machine. - Page 5 Important Safety Rules ！ ！ WARNING 6.) Risk of fire and explosion. - Hot exhaust fumes from engine can cause fire. Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. - Position muffler at least 7 feet from combustible objects. - Before adding fuel, stop the engine and keep heat, sparks, and flame away.
-
Page 6: Machine Component Definitions
Machine Component Definitions 1.) Hydraulic Cylinder. The hydraulic cylinder has a 3” bore and a 19” stroke. It is rated to 3500 psi. 2.) Control Valve Handle. Use the control valve handle to move the cutting wedge slide forward and backward. 3.) Ram. -
Page 7: Component Parts
Component Parts... -
Page 8: Operation Instructions
Operation Instructions ！ Proper Operation of the Log Splitter 1.) Load a log onto the beam and against the ramplate. 2.) Serious accidents can happen when other people are allowed inside the work zone. Keep everyone else out of the work zone while operating control valve. 3.) Push control valve handle FORWARD to split log. -
Page 9: Vehicle Towing & Working
Operation Instructions ！ While towing, connect the tow hitch to your vehicle and raise the front support leg. Note, the Lock Pin should be in the upper hole. The LEG should be raised while The LEG should support the floor while operating towing When operating, please connect the Front Support Leg to the lower hole with... -
Page 10: Maintenance And Storage
Maintenance and Storage ！ ！ Before performing maintenance, the log splitter must be placed in maintenance mode. 1.) Turn off engine. 2.) Move the control valve handle forward and backward to relieve hydraulic pressure. ！ After performing maintenance, make sure all guards, shields and safety features are put back in place. -
Page 11: Troubleshooting
Troubleshooting Problem Cylinder rod will not move SOLUTION: A,D,E,H,J Slow cylinder shaft speed when extending or SOLUTION: A,B,C,H,I,K,L retracting Wood will not split or splits extremely slowly SOLUTION: A,B,C,F,I,K Engine bogs down during splitting SOLUTION: G,L Engine stalls under low load condition SOLUTION: D,E,L,M Cause Solution... -
Page 12: Specifications
Specifications Ram force: 12ton Engine: 6.5HP 2.3 GPM Gear Pump Maximum Pressure: 3500PSI Hydraulic Cylinder Size (bore x stroke): 3”x19” Cycle time: 8.6s Hydraulic Tank Capacity: 8L Max. Log Opening: 20” long and 8” Diameter Hardened Steel Wedge: 6.3” The manufacturer reserves the right to make improvements in design and/or changes in specifications at any time without incurring any obligation to install them on units previously sold. -
Page 13: Assembly Instruction
ASSEMBLY STEP STEP 1: WHEEL ASSEMBLY Assemble the wheel (#66) to the wheel stand by using Cotter Pin Ø4x36 (#69), Hex Nut M16x1.5 (#68) and Flat Washer Ø16 (#27) STEP 2: WHEEL STAND ASSEMBLY Assemble the wheel stand to the main frame by using Hex Bolt M10x50 (#64), Flat Washer Ø10 (#6) and Hex Lock Nut M10 (#65). - Page 14 STEP3: ATTACH FRONT SUPPORT LEG Attach the front support leg (#22) to the main frame by using Hex Bolt M10x70 (#23), Flat Washer Ø10 (#6) and Hex Lock Nut M10 (#65), then fix the Lock Pin (#24). STEP 4: ENGINE ASSEMBLY Assemble the engine to the wheel stand by using Hex Bolt M8x70(#60), Flat Washer Ø8 (#19), Lock Washer Ø8 (#43) and Hex Lock Nut M8 (#20), between Engine &...
- Page 15 STEP 5: LOG CRADLE ASSEMBLY Attach the log cradle (#26) and stiffening plate (#25) by using Flat Washer Ø10 (#6), Lock Washer Ø10 (#7) and Hex Nut M10 (#8). STEP 6: PULL HANDLE ASSEMBLY Attach the pull handle to the main frame by using Flat Washer Ø16 (#27) and Cotter Pin 4x36 (#69).
-
Page 16: Parts Explosion
LOG SPLITTER PARTS LIST... - Page 17 LOG SPLITTER PARTS LIST Ref.No Drawing No. Description LS12J-01000 Beam LS12-02000 Ram Plate 9101-12080-DX8.8 Hex Bolt M12x80 9206-12000-DX Hex Lock Nut M12 9101-10040-DX8.8 Hex Bolt M10x40 9301-10000-DX Flat Washer Ø10 9306-10000-DX Lock Washer Ø10 9201-10000-DX Hex Nut M10 LS12-00001 Wedge Spacer LS12-00002 Wedge Plate LSA22-00025...
- Page 18 Ref.No Drawing No. Description 9306-08000-DX Lock Washer Ø8 9101-05010-DX8.8 Hex Bolt M5x10 LS12J-00010 Straight Joint (Pump-Hydraulic Hose) LSP25-10008-FH Steel Wire Snap Ring for Shaft LS12J-00001-DX Pull Handle LS12J-00002 Handle Sleeve LS12J-00008 Gear Pump LS12-11000 Cylinder LSP25-00011 Clamp LSH22-00011 Oil Pipe 9101-06020-DX8.8 Hex Bolt M6x20 9306-06000-DX...
