Programmer Kit 356484-1 for
Flexible Flat Cable (FCC) Terminating Machines
224910-[ ] and 318619-[ ]
SAFETY PRECAUTIONS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TOOLING ASSISTANCE CENTER 1-800-722-1111
. . . . . . . . . . . . . . . . . . . . . . . . . .
READ THIS FIRST !
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at
Customer Manual
409-5880
28 JUL 08 Rev B
2
3
4
4
5
5
7
7
7
7
7
8
9
9
12
12
13
of 13
1
www.tycoelectronics.com
LOC B
Advertisement
Table of Contents
Summary of Contents for Tyco Electronics 356484-1
-
Page 1: Table Of Contents
For latest revision and Regional Customer Service, All International Rights Reserved visit our website at TE logo and Tyco Electronics are trademarks. www.tycoelectronics.com LOC B *Trademark. Other products, logos, and company names used are the property of their respective owners. - Page 2 409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] DANGER SAFETY PRECAUTIONS AVOID INJURY Safeguards are designed into this application equipment to protect operators and maintenance personnel from most hazards during equipment operation. However, certain safety precautions must be taken by the operator and repair personnel to avoid personal injury, as well as damage to the equipment.
-
Page 3: Introduction
409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] Control Module Specifications Dimensions (Approximate) Length: ..438.15 mm [17.25 in.] Width: ..285.75 mm [11.25 in.] Height: . -
Page 4: Description
409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] NOTE Dimensions in this manual are in metric units [with U.S. customary units in brackets]. Reasons for reissue are in Section 8, REVISION SUMMARY. 2. DESCRIPTION 2.1. Physical Description The control module features a metal cabinet which houses the electrical and electronic components for the programming system. -
Page 5: Internal Controls
409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] C. Function Keys The four function keys are used to save part numbers, to edit (and save) part numbers, and to move between screens. D. RETURN Key The RETURN key is used to enter the diagnostic mode. - Page 6 409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] Reset and Count Switch Adjustments Screw Mounting Screw Switch Cam Switch Bracket Horizontal with Center of Main Shaft (Ref) Clutch Solenoid (Ref) Cam Mount Switch Actuating Pin (Ref)
-
Page 7: Programmer Kit Adjustments
409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] 4. PROGRAMMER KIT ADJUSTMENTS 4.1. Reset and Count Switch Adjustments (Figure 3) The reset switch assembly must “close” when the clutch solenoid is de–energized and “open” when energized. -
Page 8: View Part
409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] Sequence of Operations Main Menu Activate Select Edit Part Number Part Number Part Number to Run (Production) Enter View Delete View Part Number Part Number Part Number... -
Page 9: Production
409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] When the last part has been displayed, the control module informs the operator that the end of the part file has been reached, and that the operator may start again at the beginning by pressing the F1 (REPEAT) key. - Page 10 409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] ENTER P/N F4 = MENU P/N = (Part Number to Create) Figure 11 2. Enter the part number (up to four digits) and enter the total number of conductors in the cable. See Figure 12.
- Page 11 409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] NOTE If a position number is entered that is higher than the total number of positions in the cable, an INVALID NUMBER" message will appear and the F1 function key will clear the error.
-
Page 12: Error Conditions
409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] C. Delete To delete a part, first press F2 (DEL) in the EDIT PART FILE menu (see Figure 10) and then enter the part number assigned to that part. The control module will prompt you to confirm the deletion. Pressing the F1 (YES) key will delete the part from the part file, and pressing the F2 (NO) key will leave the part file unchanged. -
Page 13: Revision Summary
409-5880 Programmer Kit 356484-1 for FFC Terminating Machines 224910-[ ] and 318619-[ ] The diagnostics menu displays options numbered from 0 to 9. The numbers on the display correspond directly with the numeric keys on the control panel, and each number displayed represents a diagnostic test that may be selected.
