1
Install screen protector.
3
Place battery pack into the
compartment.
5
Plug charger into RAMPAGE.
Follow on-screen instructions.
Quick Start Guide
2
Loosen quarter turn latches to
open battery compartment door.
4
Close battery compartment.
Replace door, tighten latches.
1
2
3
8
9
10
The anatomy of your RAMPAGE 6.
1
Stylus and Handstrap
2
Touch Screen
3
Power Button
4
Camera Lens
5
Battery Doors
6
SD Card Slot
7
SIM Card Slot
11
12
13
14
8
Handstrap Tethers
9
12V DC Jack
10
Mic/Speaker Jack
11
9-pin Serial Port
12
USB Host
13
USB Client
14
Antenna Bumper (Geo Model)
Questions?
1-724-452-9366
support@sdgsystems.com
TM
part# 20503-00
4
5
6
7
Advertisement
Summary of Contents for SDG Rampage 6
- Page 1 Quick Start Guide Install screen protector. Loosen quarter turn latches to open battery compartment door. The anatomy of your RAMPAGE 6. Place battery pack into the Close battery compartment. compartment. Replace door, tighten latches. Stylus and Handstrap Handstrap Tethers Touch Screen...
- Page 2 Mounting Options Quick Start Guide Installing and Removing RAMPAGE 6 from Mobile Dock Place RAMPAGE in Mobile Dock. Align with lower mounting points. Mobile Dock Desktop Base Kit: Mobile Dock Vehicle Kit: PN 22885 PN 22886 The Anatomy of Your Mobile Dock Press back to secure to Mobile Dock.
