Summary of Contents for PowerPac PPC611
- Page 1 ELECTRIC PRESSURE COOKER PPC611...
-
Page 2: List Of Components
This newly introduced Digital Pressure cooker will help you cook the foods you like in a consistent and convenient manner, and food is also hygienically prepared. Cooking occurs extremely rapidly, and thus you might find yourself unexpectedly having some very welcomed free time. All the more to think about preparing other delicious foods like cakes &... - Page 4 Assembly and Disassembly of Anti-block Cover Screw nut Cover Anti-block cover Assembly and Disassembly of Aluminium Plate Aluminium plate...
- Page 5 Rice scoop Measuring cup Power cord Water Storage box To remove, pull the water storage box horizontally. To insert, align the water storage box horizontally along the groove and slide the box in. Inner pot External pot Middle layer Water storage box...
- Page 6 Warnings ATTENTION : Read this booklet carefully as it contains important instructions for a safe installation, use and maintenance. Important instructions to be kept for future reference. The following basic precautions should always be followed when using electrical appliances: 1. Read all instructions before using the appliance. The Appliance 2.
- Page 7 of the reach of children or disabled persons since they represent potential sources of danger. Location 10. This appliance is NOT suitable to be used or stored near heat sources (open flame, ovens, heaters, stoves, etc.) and/or in an explosive environment (in the presence of flammable substances such as gas, vapour, mist or dust, in atmospheric conditions when, after ignition, the combustion is spread in the air).
- Page 8 proper functioning. DO NOT: cover the appliance during functioning; obstruct totally nor partially the Vent valve, Float valve & Water outlet; insert objects (other than food to be cooked) or body parts inside the protection cover of the appliance; ...
- Page 9 maintenance operation. 19. In case of malfunction or anomaly during the functioning, switch the appliance off, switch the socket switch OFF and unplug the plug and check the cause of the anomaly, if possible, with the support of a qualified person. 20.
-
Page 10: Using Your Appliance
USING YOUR APPLIANCE 1. Remove the Inner pot and Aluminium plate (with seal ring) and thoroughly wash them with hot water & detergent with a non-abrasive sponge. 2. Clean the inside and outside of the appliance with a wet cloth. 3. - Page 11 7. A “clicking” sound is heard as the Pot cover is aligned into position. Using the Handle, slide the Pot cover anti-clockwise and the Pot cover will lock into place. 8. Turn the knob of the Vent valve in any direction to lower the knob slightly. 9.
- Page 12 17. Once you input your selection, e.g. pressing: (a) ‘Rice’, or (b) ‘Rice’, ‘Time Choice’ (press until the time you desire is displayed), or (c) ‘Rice’, ‘Taste’ (press through ‘short’, ‘medium’ & ‘long’), the pressure cooker will start heating. (Note: there is no ‘Enter’ button. There is no need for one!) 18.
- Page 13 Food Default duration Adjustable duration Pressure Selection (mins) (mins) 1 – 18 Rice 1 – 35 Soup High 1 – 30 Spare ribs 1 – 20 Poultry 1 – 25 Grain / Rice 1 – 15 Fish 1 – 60 Baked High 1 –...
-
Page 14: Problem Solving
PROBLEM SOLVING ERROR CODES CODE Action Open circuit Short circuit of Overheating Pressure for sensor sensor occurred switch issues Problem Possible Causes How to Solve Cannot close Seal ring not correctly the pressure positioned around the Adjust the Seal ring cooker Aluminium plate Float did not fall to its lowest... - Page 15 AUTOMATIC ELECTRICITY CUT-OFF FOR SAFETY In the case where the installed thermostat malfunctions, the power supply will stop automatically to prevent the pressure cooker from overheating. Numerous other safety devices are installed in your pressure cooker, such as: Anti-block safety device which prevents food from blocking the air outlet; Pressure-control safety device automatically cuts the electric supply when the pressure reaches pre-set parameters;...
-
Page 16: Specifications
A “clicking” sound is heard as the Pot cover is aligned into position. Using the Handle, slide the Pot cover anti-clockwise and the Pot cover will lock into place. SPECIFICATIONS MODEL CAPACITY VOLTAGE POWER PRESSURE 220 – 240 V ~50 – 60Hz 900 – 1000 W 20 – 70 kPa PPC611 6.0 Litre... -
Page 17: Warranty
3. This warranty does not cover the repair or replacement of part/s damaged by misuse, accidents, negligence, alterations, or modifications in any way, or repairs done by any repair organisation without the prior consent of PowerPac Electrical Pte Ltd. 4. Repair and service are to be performed at: 5 Changi South Lane #03-01 Singapore 486045. - Page 18 In accordance with the terms and conditions of this limited warranty as stated above, PowerPac Electrical Pte Ltd, at its expense shall provide free services for the appliance within the warranty period from its date of purchase from our Authorised...
