Indoor·for home use

Air purifier

KJ220F-ACMS

User manual

Contents

Preparation before use

Safety instructions ....................................................... 2

Usage precautions....................................................... 4

Placement method....................................................... 4

Parts ............................................................................ 5

Preparations before use .............................................. 8

Filter screen ................................................................. 9

Operation instructions

Operation instructions.................................................. 9

Indoor air quality monitor ............................................. 11

Cleaning and maintenance .......................................... 12

Others

Troubleshooting ........................................................... 14

Specifications .............................................................. 15

Consumables............................................................... 15

KJ220F-ACMS

Table of Contents

Need help?

Do you have a question about the KJ220F-ACMS and is the answer not in the manual?

Questions and answers

Summary of Contents for Iris Ohyama KJ220F-ACMS

Page 1: Table Of Contents
CODE：808395_ ㊥ＰＨ取説空清ＡＣＭＳＤＣＭＳサイズ：210 × 297(A4)　16 ページ KJ220F-ACMS 材質：上質紙四六判 70kg（81.4g ／㎡）刷色：1C(BLACK) Indoor·for home use Air purifier KJ220F-ACMS User manual Contents Preparation before use Safety instructions ............2 Usage precautions............4 Placement method............4 Parts ................5 Preparations before use ..........8 Filter screen ..............
Page 2: Safety Instructions
KJ220F-ACMS Safety instructions Please read the “Safety instructions” carefully and strictly follow these when using the product, so as to avoid injury to people and unnecessary property damage. The Safety instructions are divided into two parts: “Warning” and “Attention” , both of which provide important information on safe use and need to be strictly adhered to.
Page 3 KJ220F-ACMS ● Do not spray liquids onto this Do not use this product in places ● product, such as insecticides, within the spray range of water hair care products, or vapour, such as a humidifier Prohibited Prohibited lubricating oil, etc.
Page 4: Usage Precautions
KJ220F-ACMS Usage precautions ● Do not operate this product with the filter ● Do not use damaged or broken filter screen removed. screens. Doing so may cause failure to achieve the Doing so may cause failure or reduction in purification effect.
Page 5: Parts
KJ220F-ACMS Parts ■ Front Operation panel Body HEPA activated carbon composite filter screen Pre-filter screen Air inlet (Left and right sides and Front panel below of the front panel) ■ Back Air deflector Air outlet Handle (Left/Right) Dust sensor cover...
Page 6 KJ220F-ACMS Parts Continued ■ Operation panel Indoor air quality monitor Display the PM2.5 concentration of indoor air monitored by the sensor, and graphically display the concentration changes within 14 minutes and 14 hours or 14 days ago. SEV ——— severe Backlight button L ————...
Page 7 Turbo button Reset button Press the button, the indicator light After replacing the filter screen and goes on. KJ220F-ACMS runs for about cleaning the sensor, press this button to 10 minutes. turn off the Replace and Clean sensor indicator lights.
Page 8: Preparations Before Use
KJ220F-ACMS Preparations before use ■ Installation of filter screen Install the composite filter screen Be sure to install the filter screen before plugging the • Keep the HEPA activated carbon composite filter power plug into the socket. screen surface towards the direction of front panel during installation.
Page 9: Filter Screen
KJ220F-ACMS Filter screen Operation instructions ■ Functions of filter screen Press the On/Off button Pre-filter screen • Run the product in Auto mode at low speed. ※You need to wait for a period of time from connection to the power to monitoring by the sensor.
Page 10 KJ220F-ACMS Operation instructions Continued ■ Turbo mode ■ Air direction adjustment It’s a high speed running mode in a short period in Use the air deflector of the air outlet to adjust the air case of serious indoor air pollution.
Page 11: Indoor Air Quality Monitor
KJ220F-ACMS Indoor air quality monitor Display the PM2.5 concentration of the indoor air. Display the changes in concentration Display PM2.5 concentration. (“0” within 14 minutes, within 14 hours, or is displayed during the period 14 days ago. from the connection to the power...
Page 12: Cleaning And Maintenance
KJ220F-ACMS Indoor air quality monitor Cleaning and maintenance Continued ■ Time display ● Be sure to turn off the power and unplug the power plug from the electric socket before • After pressing the Time button, the displayed time cleaning and maintaining the product.
Page 13 KJ220F-ACMS ■ Clean sensor indicator light on ■ Replace filter light The indicator light goes on when the sensor needs to The indicator light goes on when the filter screen be cleaned. needs to be replaced. • Remove the sensor cover on the side of the body, •...
Page 14: Troubleshooting
KJ220F-ACMS Troubleshooting Please read the following content carefully before sending to repair to confirm whether it is abnormal due to the following reasons. Common faults Possible reasons Solutions ● The power plug is not plugged ● Insert the power plug into the socket.
Page 15: Specifications
KJ220F-ACMS Specifications Model No KJ220F-ACMS Rated voltage 220-240V〜 Rated frequency 50/60Hz Rated power Product size W400×D164×H536mm Product weight (Approximately) 5.9kg Power cord length (Approximately) 2.0m ※ No other notification will be delivered in condition of changes on specifications of the product.
Page 16: Consumables
KJ220F-ACMS Air purifier 　 KJ220F-ACMS This warranty card is a certificate for providing free repair according to the following warranty terms in case of failure within the following period from the date of purchase . Date of purchase ※ Warranty period From the date of purchase: MM 　...
