- Page 1 SmarPID M5 PRO Quick Start Guide https://smartpid.com smartpid@arzaman.com...
- Page 2 (PLC) and simple on/off thermostat. The flexibility, feature richness and smartness make smartPID M5 PRO a unique product on the market that can replace legacy thermostat and manage any application in a smart way !
- Page 3 SmartPID M5 PRO characteristics ● Dual Independent control channels (2 in 1 controller) ● 4 different outputs that can be assigned by SW to each ● Fully configurable PID-PWM control or ON/OFF control control channel with hysteresis ○ 2x DC out 5-36V 2.5A for heavy load driver ●...
- Page 4 SmartPID M5 PRO back panel pinout...
- Page 5 DIP switch configuration for temp probes selection Temperature probe selection need to be done either via the SW menu and configuring the back panel dip switch NTC 10K Open Open PT100 Open Close DS18B20 Close Open Thermocouple Close Open MAX31850...
- Page 6 ThermoCouple Adapter (MAX31850) AIN0 AIN1 AIN0 AIN1 Connect 1) GND ⇒ GND of CH1 or CH2 2) 3V3 ⇒ AIN0 of CH1 or CH2 Select DIP switch for K-type (SW1 close, SW2 open) 4) DATA ⇒ AIN1 of CH1 or CH2 Select in SW configuration the K-type temp proble 5)6) thermocouple...
- Page 7 Bluetooth temperature sensor pairing ● Navigate to the BT Sensor config menu (HW setup) ● Select “Pairing” menu then perform sensor scan ● The BT-05 sensors must be powered on (press central button) ● Select the BT05-xxxxx sensor and confirm ●...
- Page 8 SmartPID M5 PRO main menu Start select standard or advanced mode (profiles), select the set point and start the control process WIFI ● Check wifi connection status Monitor ● Select WiFi connection mode temperature on both channel is monitored. With...
- Page 9 SmartPID M5 PRO - HW set up Parameter Description Control Mode Select Heating/Cooling/Thermostatic mode Heating/Cooling mode Select control algorithm PID or ON/OFF Multi control Select number of control channels Out1 Heating/Cooling Assign to CH1 control process output resources (relay or DC)
- Page 10 SmartPID M5 PRO - unit parameters Parameter Description Temperature Unit Select temperature unit visualization Celsius or Fahrenheit Probe 1 & 2 calibration Adjust temperature probe reading with fixed offset +-5c NTC Beta Select NTC probe beta factor Auto Resume Enable/Disable process auto resume function after power supply...
- Page 11 SmartPID M5 PRO - process parameter Parameter Description Set Point 1 & 2 Default temperature set point for CH1 and CH2 Timer 1 & 2 Default countdown timer for CH1 and CH2 PID 1&2 Kp Ki Kd Define the proper constant value for the PID algorithm tuning for CH1 /CH2 Reset DT 1 &...
- Page 12 SmartPID M5 PRO - profile definition In the menu “profile” it’s possible to create/modify/view/delete temperature profiles to be selected in the advanced running mode. For each point of the profile user should define: SP X that is the starting set point temperature...
- Page 13 SmartPID M5 PRO - ramp/soak Ramp/soak = STATIC Soak time start when ramp time finish independently from temperature. Each soak period predefined independently from the current temperature and set point. After each soak period a new set point is defined and a RAMP time defines the time needed to reach the new set point.
- Page 14 SmartPID M5 PRO - monitor mode Monitor mode allows to measure temperature of both channels and activate manually the output (relay or DC) wifi/cloud connection status clock DC output status PWM 0-100% CH1/CH2 Relay output status temperature PWM 0-100% ●...
- Page 15 SmartPID M5 PRO - run mode In run mode smartPID execute the control loop (PID or ON/OFF) and drives the outputs accordingly control algorithm wifi/cloud connection status clock /timer output status CHx current heating/cooling/off temperature PWM output 0-100% CHx current...
- Page 16 SmartPID M5 PRO - run mode - graphic view graphic mode reports the plot of CHx temperature, Set Point , PWM out Change view Stop...
- Page 17 SmartPID M5 PRO - run mode - syntetic view in this mode a systensys of both channel status and output is reported CHx current temperature CHx current set point output status CHx heating/cooling/off Change view Stop...
