- Page 1 JVA Solar Wi-Fi Anywhere Quick Start Guide WA150 PTE2704 The JVA Logo is a registered trademark of JVA Technologies © JVA Technologies...
-
Page 2: Specifications
The Wi-Fi can then be used to connect an IP device or Internet of Things (IoT) device to the Cloud (Internet). The JVA Solar Wi-Fi Anywhere is installed with an ALDI SIM card at the factory, all you need to do is: 1. -
Page 3: Troubleshooting
Check that the Solar + goes to the left-hand screw terminal Broken cables Check that the battery cables are not dam- aged Solar panel broken Check solar panel for physical damage (bro- ken glass, bent frame etc.) JVA WA150 Page 3... -
Page 4: Before You Start
(~10m) SIM card not inserted Re-insert SIM card correctly If the unit is still not working correctly, contact your nearest JVA distribu- tor for technical support. Before you start Activate the SIM card Activate your SIM card and test it in a mobile phone. The Wi-Fi network allows a data-only connection, the number of devices connected to the module will determine how much data will be used. - Page 5 2. Remove the U-Bolts from the zip lock bag and mount it to the top and bottom panel of the bracket. (A) U-Bolt x 2 (B) Top or Bottom Panel (C) Washers x 4 (D) Spring Washers x 4 (E) Hex Nut x 4 JVA WA150 Page 5...
- Page 6 4. Loosen the 6 bolts on the inside of the frame. DO NOT completely re- move these bolts. Lift the bottom of the solar panel until the attached arms holding it are angled at 90 degrees. Tighten all 6 bolts again and face the panel north. Page 6 © JVA Technologies www.jva-fence.com...
- Page 7 5. If you have a JVA energiser it can be installed between the solar panel and the pole. There are 2 mounting screws that can be used to hang the energiser up. 6. If your JVA energiser is fitted, plug it into the middle lead (load output) of the Wi-Fi anywhere.
- Page 8 Alternatively, the energiser can be connected to the battery directly using the alligator leads that came with the energiser. ** The Wi-Fi anywhere middle lead (load output) will remain unused. The plug pack provided with the energiser will also be unused. Page 8 © JVA Technologies www.jva-fence.com...
- Page 9 Overview JVA WA150 Page 9...
- Page 10 Off when no solar power detected D6 (USB_5V) Solid on when USB Power is turned on Batt Level Shows battery level from bottom to top: 25% to 100% Bottom LED flashes if battery is disconnected or bad Page 10 © JVA Technologies www.jva-fence.com...
- Page 11 Region Number Australia 0731 030 582 South Africa 0861 782 349 World Wide +61 731 030 582 For more information on our complete range of electric fencing products please see the JVA website at https://www.jva-fence.com.au JVA WA150 Page 11...
- Page 12 Tel : +61 (0)499 000 455 Email : sales@jva-fence.com.au www.jva-fence.com The JVA Logo is a registered trademark of JVA Technologies © JVA Technologies...
