AGILTRON NanoSpeed Operation Manual

Features
• H igh speed
• H igh repetition
• High output voltage
• Wide input voltage range
• TTL/CMOS control
• Push-Pull output design
• Low power consumption
low cost
• Compact and
Applications
Optical Switch
•
• EO device driver
Revised on 12/28/22
100 kHz Repetition Rate NanoSpeed
Switch Driver
(Protected by U.S. patent 7,403,677B1 and pending patents)
Product Description
The NS switch driver provides a convenient way to use the NS series electro-optical
switches, which act as a pure capacitive load.
device mounted on the PCB.
accompanying DC power supply and input a control signal through the golden SMA
connector. The switch will be activated as the input voltage exceeds 3V with less
than 1µA draw, compatible with 3.3V CMOS/TTL . We produce boards to control
multiple NS switches with individual SMA connectors.
software is available for such a high-speed operation.
Performance Specifications
Specs
[1]
Rise Time (Tr)
[2]
Fall Time (Tf)
Repetition Rate
Pulse Width
Control Input (TTL pulse)
Power Consumption
Power Current
Power Supply
Operating Temperature
Storage Temperature
Electrical Connector
Board Size
Note:
[1]: Optic Intensity Change from 10% to 90% intuits;
[2]: Optic Intensity Change from 90% to 10% intuits;
[3]: Switch Speed (Rise): Duration from begin of electronic signal to end of optic intensity change;
[4]: Switch Speed (Fall): Duration from begin of electronic signal to end of optic intensity change.
Warning:
Control Signal >5.5V Will Damage the Board
15 Presidential Way, Woburn, MA 01801
Each driver is tuned to a specific
To operate, the customer only needs to plug in the
No computer-based control
Min Typical
85
85
DC
1.0
0
0.08
12
-5
-40
3.5(L)x1.25(W)
Tel: (781) 935-1200 Fax: (781) 935-2040
www.agiltron.com
TM
Max Unit
100 ns
100 ns
100 kHz
s
5 V
5 W
0.4 A
V
70
ºC
80
ºC
SMA
Inch
