AGILTRON NanoSpeed F Series Operation Manual

Features

Solid-State
•
• High speed
• Ultra-high reliability
• Low insertion loss
Compact
•

Applications

Optical blocking
•
• Configurable operation
Instrumentation
•
Revised: 06/23/22
NanoSpeed
30dB Extinction
(SMF, PMF, High Power)
(Protected by U.S. patent 7,403,677B1 and pending patents)

Product Description

The NanoSpeed TM F series fiber optic on-off switches are fast shutter device
uniquely featuring very low optical loss, fast response, and high optical
power handling. The high extinction of 50dB is achieved using a patent
pending feedback electro-optical bias control technology, that maintains
the optimum performance against drift and environment variations. The NS
fiber-optic switch is designed to meet the most demanding switching
requirements of ultra-high reliability for undersea, space, continuous
switching operation, and longevity over 25 years. The switch is bidirectional.
It is well suited to replace acoustic modulator with advantages of low loss,
low power consumption, and low cost.
The NS Series switch is controlled by 5V TTL signals with a specially
designed electronic driver having performance optimized for various
repetition rate. A wall pluggable DC power supply is accompanied with
each devices.

Specifications

NanoSpeed Series Bias Control Switch
Central wavelength [1]
1260~1650nm
[2]
Insertion Loss
960~1100nm
Durability
[3]
On-Off Ratio
PDL (SMF Switch only)
PMD (SMF Switch only)
ER (PMF Switch only)
IL Temperature Dependency
Return Loss
Response Time (Rise, Fall)
Fiber Type
60kHz driver
Driver Repeat Rate
300kHz driver
Normal power
Optic power
Handling [4]
High power
Operating Temperature
Storage Temperature
[1] Operation bandwidth is +/- 25nm approximately at 1550nm.
[2] Measured without connectors. For other wavelength, please contact us.
[3] Measured at 100kHz, which may be degraded at higher repeat rate.
[4] Defined at 1310nm/1550nm. For the shorter wavelength, the handling power may
be reduced, please contact us for more information.
15 Presidential Way, Woburn, MA 01801
1x2 Fiber Optical Switch
TM
Min Typical
780
0.6
0.8
10 14
30 30
0.15
0.1
18 25
0.25
45 50
50
SMF-28, Panda PM, or equivalent
DC 60
DC 300
300
-5
-40
Tel: (781) 9351200 Fax: (781) 935-2040
www.agiltron.com
Max Unit
1650 nm
1.0
dB
1.3
cycles
35 dB
0.3 dB
0.3 ps
dB
0.5 dB
60 dB
80 ns
kHz
mW
5 W
70 o C
o
85 C
