Summary of Contents for Diga CRUSB Spartan
- Page 1 KONWERTER CAN / USB WARNING It is possible to influence on CANbus communication using CRUSB. It can cause material damage or even personal injury. DIGA shall not be liable for damage resulting from improper use CRUSB. file: CRUSB_Spartan_IO_EN_2015_09.odt version: v1.02...
- Page 2 • command list is available for custom software design • advanced CANStudio software for CAN is available • CANMonitor software free of charge Actual version of driver and firmware is available on the web site www.diga.biz.pl. DIGA s.c. CRUSB Spartan Manual v1.02 2015_09...
- Page 3 For a proper work CRUSB converter with operating system it is necessary to install ® USB driver. Actual driver for Windows is available on the web site www.diga.biz.pl. http://www.ftdichip.com are available drivers for Windows®, On FTDI website Linux, Android, Mac OS.
- Page 4 FTDI according to USB 2.0 (Full Speed, 12Mbps) CAN transceiver High speed CAN according to ISO 11898, PCA82C250 type CAN connector D-sub 9 pin, male USB connector A/mini* type * - dependent of version. DIGA s.c. CRUSB Spartan Manual v1.02 2015_09...
- Page 5 - 1 pcs manual - 1 pcs 8. Accessories CANStudio - CAN software tool CANMonitor - free CAN monitor software DLL library - free 32 and 64 bit dll library (free of charge) DIGA s.c. CRUSB Spartan Manual v1.02 2015_09...
- Page 6 9. Mechanical drawing Dimmensions are in mm. DIGA s.c. CRUSB Spartan Manual v1.02 2015_09...
- Page 7 All rights are reserved. DIGA s.c. assumes no responsibility for any errors which may appear in this document. DIGA s.c. reserves the right to change devices or specifications detailed herein at any time without notice. DIGA s.c. Internet: www.diga.biz.pl ul. Zamkowa 1 e-mail: info@diga.biz.pl...
