VAR thanks you for purchasing DV-10500 torque wrench, specially designed for bolts
and fasteners torqueing, from 20 Nm to 100 Nm.
Please read this manual carefully before use.
Recommendations
DV-10500 is a precision tool that has to be used and stored with care, avoiding
shocks, falls and mistreatments.
Applying a torque on bolts and fasteners has to be done in a single and gentle
movement or the desired torque may be wrongly applied. The torque wrench needs
to be held at the center of the handle.
A torque wrench must not be used as a ratchet, this affects the torque application
accuracy.
Espace Eiffel - Lot D6
19 et 21, Avenue Gustave Ei el
28630 Gellainville - FRANCE
+33 2 37 33 37 10
contact@vartools.com
20-100NM TORQUE WRENCH
WITH 3/8'' SQUARE DRIVE
DV-10500
1/4
Advertisement
Summary of Contents for VAR DV-10500
- Page 1 Please read this manual carefully before use. Recommendations DV-10500 is a precision tool that has to be used and stored with care, avoiding shocks, falls and mistreatments. Applying a torque on bolts and fasteners has to be done in a single and gentle movement or the desired torque may be wrongly applied.
- Page 2 Specifications Torque range 20 - 100 Nm Units Square drive 3/8’’ Safety instructions - Never use a torque wrench as leverage or hammer. - Using defective hand tools, sockets, bits, extensions or adapters can cause injuries. - A miscalibrated torque wrench can damage the parts and components being tightened.
- Page 3 Instructions 1. Unlock the lockring by lowering it to the handle. 2. Adjust the torque by aligning the upper edge of the handle on the desired torque value. 3. Lock the desired torque by releasing the lockring. 4. You will hear a «click» when the desired torque has been reached. Extensions and adaptors Using an extension or an adaptor (increasing the effective length of the torque wrench) modifies the torque value.
- Page 4 Conversion table Convert Multiply by Inch Pounds Foot Pounds 0.08333 Inch Pounds Newton Meters 0.113 Inch Pounds Centimeter Kilograms 1.1519 Foot Pounds Inch Pounds Foot Pounds Newton meters 1.356 Foot Pounds Centimeter kilograms 13.825 Newton Meters Inch Pounds 8.85 Newton Meters Foot Pounds 0.7376 Newton Meters...
