SDM630MCT
USER MANUAL V1.3
Measures kWh kVArh, kW, kVAr, kVA, P,
F, PF, Hz, dmd, V, A, THD,etc.
Bi-directional measurement IMP & EXP
Two pulse outputs
Shenzhen KSTAR New Energy Company Limited
40mA
DIN Rail Energy Meter for Three Phase
KSTAR Electrical Systems
RS485 Modbus
Din rail mounting 35mm
40mA CT connection
Better than Class 1 / B accuracy
www.kstar.com
Advertisement
Table of Contents
Summary of Contents for KStar EASTRON SDM630MCT 40mA
- Page 1 Measures kWh kVArh, kW, kVAr, kVA, P, RS485 Modbus F, PF, Hz, dmd, V, A, THD,etc. Din rail mounting 35mm Bi-directional measurement IMP & EXP 40mA CT connection Two pulse outputs Better than Class 1 / B accuracy Shenzhen KSTAR New Energy Company Limited www.kstar.com...
- Page 2 Three-Phase Power Meter For Kstar Three phase inverter Solution: KSTAR three phase inverters can ful l the requirement of zero export function with a smart meter and three CTs. The system can implement data-driven decisions to control the inverter’s output. Three are two different methods of achieving zero export function, which are phase-level zero export and system-level zero export.
- Page 3 Meter & CT Installation: Pull to release the retaining clip. ① Mount the Meter on the DIN track and push ② the retaining clip up (a clicksound indicates it is installed well). ① ② The current should be consistent with the ①...
- Page 4 Inverter Setting: After wiring connection ,all the setting can be done on the inverter. It means there is no need to set the meter. Setting steps of set meter mode and zero export function are as follows: A: Return Button Escape from current interface or function. B: Up button: Move cursor to upside or increase value.
- Page 5 www.kstar.com...
