Summary of Contents for DHR 230CS Series
- Page 1 Navigation Lights Signalling Lights Searchlights Whistles TECHNICAL DOCUMENT DHR 230CS - Series Cabin Controlled Searchlight Den Haan Rotterdam...
- Page 2 Den Haan Rotterdam (Intentionally blank page) Version 0.93 Sept 2020...
- Page 3 Den Haan Rotterdam Safety notes: • Turn power off before inspection, installation or removal • Keep combustible materials away from lamp • Don’t stare directly into the LEDs, Allways use eye protection when handeling LEDs • ESD, this product (the LEDs) can be damaged by electrostatic discharge. Care must be taken before opening.
- Page 4 With the 230CS-series searchlight, DHR introduces a deck mounted LED searchlight. The 75W LED engine produces a color output of 5.000K and an intensity close to the same performance levels of 1.000W halogen searchlights.
-
Page 5: Table Of Contents
Den Haan Rotterdam TABLE OF CONTENTS 1. Mounting instructions 2. Specifications 3. Dimensions 4. Photos 5. Safety, maintenance and correct use 6. Recommended Spare parts Version 0.93 Sept 2020... -
Page 6: Mounting Instructions
Den Haan Rotterdam 1. MOUNTING INSTRUCTIONS Warning! Den Haan Rotterdam does not accept responsibility for any damage if the searchlight is in- stalled incorrectly and/or used improperly. When in doubt consult a qualified electrical techni- cian. Searchlight installation Install the searchlight in a horizontal upright position with sufficient space around the drum of the searchlight to ensure it can move freely Bolt M10x35 Bolt M10x35... - Page 7 Den Haan Rotterdam Phoenix QPD connecter - please order separately Up/Down Dirt wiper Always push the push/pull rod gently from the bottom up into the searchlight to prevent damaging the dirt wiper Unscrew the two set screws M6 and move the tube up and down until both the handle and head are horizontal and point in the same direction.
- Page 8 Den Haan Rotterdam Electrical installation Install the electrical wiring according to the wiring diagrams showed on page 9. Keep the distance between the power supply and LED searchlight as short as possible. Long wires will increase the voltage drop. Connecting the cable with Phoenix connector (Please order separately) 1.
- Page 9 Den Haan Rotterdam Version 0.93 Sept 2020...
-
Page 10: Specifications
Den Haan Rotterdam 2. SPECIFICATIONS Searchlight Model 230CSL21 Dimensions Height 436 mm [17,09 inches] Width 306 mm [12,03 inches] Weight 13 kg [28,7 lb] Electrical LED-driver 115/230 VAC / 100W Cable Thermflex kabel 3x1,5mm² - L=1,55mtr. Optics Mirror Parabolic mirror reflector Ø 230 mm Range 775m [2,542.7 Feet] Adjustable Focus... - Page 11 Den Haan Rotterdam Cabin control Model SA10300 Dimensions Height 300 mm [11,81 inches]** Width Weight 2,2 kg [4,9 lb] Material Stainless steel 316 Push/Pull rod Model SA20535 SA21335 Dimensions Height 535 mm [21,06 inches]** 1335 mm [88 inches]** Width Ø14 mm [0,51 inches] Weight 0,45 kg [1 lb] 1 Kg [2,2 lb]...
-
Page 12: Dimensions
Den Haan Rotterdam 3. DIMENSIONS ZONE REV. 290 11,42 290 11,42 306 12,03 306 12,03 230CSL21 SA10300 SA20535 Remarks: · Other lengt with X the t · Maximum le Phoenix QPD connecter - Phoenix QPD connecter - * With a ceiling thickness of approx * With a ceiling thickness of approx please order separately please order separately... - Page 13 Den Haan Rotterdam REVISIONS ZONE REV. DESCRIPTION BOM Table ITEM NO. NavNumber 230CSL21 Alum. drum SA21335 SA30800 SA10300 Remarks: · Other lengths on request. with X the total length =23 · Maximum length 2235 [88 UNLESS OTHERWISE SPECIFIED: DEN HAAN ROTTERDAM BV TITLE: DIMENSIONS ARE IN MILLIMETERS [INCHES] Fascinatio Boulevard 1182...
-
Page 14: Photos
Den Haan Rotterdam 4. PHOTOS Version 0.93 Sept 2020... - Page 15 Den Haan Rotterdam Version 0.93 Sept 2020...
-
Page 16: Safety, Maintenance And Correct Use
Den Haan Rotterdam 5. SAFETY, MAINTENANCE AND CORRECT USE This product, like all LED searchlights, uses semi-conductors that can be damaged by elec- trostatic discharge (ESD). When handling, care must be taken before opening the drum so the LEDs are not damaged. The following precautions must be taken: •... -
Page 17: Recommended Spare Parts
Den Haan Rotterdam 6. RECOMMENDED SPARE PARTS Spare Part Description Order code COB led 23980010 LED-holder COB led 23980020 LED-driver 100W 23980030 Mirror reflector 230 23980040 Front glass 230 23980050 Version 0.93 Sept 2020... - Page 18 Den Haan Rotterdam Version 0.93 Sept 2020...
- Page 19 ADVANCED MARITIME SIGNALLING SOLUTIONS Den Haan Rotterdam Fascinatio Boulevard 1182 2909 VA Capelle a/d IJssel The Netherlands T +31 (0) 10 413 07 55 E sales@dhr.nl www.dhr.nl...
