- Page 2 14455 INSTRUCTION MANUAL !WARNING! FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE AND OR PERSONAL INJURY. Support load by appropriate means after lifting. Use as lifting device only. Do not exceed rated capacity. Use only on hard level surface. Center load on the jack. DO NOT MODIFY JACK. Only vehicle designated by the vehicle manufacturer.
- Page 3 14455 INSTRUCTION MANUAL 1. Jack operation is controlled either manually or by external air pressure. Either insert the handle into the handle socket to manually operate or connect to an external air pressure source (clean connections prior to assembly). 2. To raise the jack, turn the release valve clockwise until tight and either manually pump with the provided handle or while connected to an air supply depress the air valve.
- Page 4 14455 INSTRUCTION MANUAL PROBLEM CAUSE SOLUTION Air pump will not operate Low air pressure Keep air pressure between 0.7- Air outlet is frozen 1.0 MPA Lack of oil Stop using and thaw frozen outlet Other Supply oil to air vavle...
- Page 5 AME INTERNATIONAL WWW.AMEINTL.NET...
-
Page 6: Parts List
14455 INSTRUCTION MANUAL PARTS LIST 14455-01 Handle Grip 14455-036 Seal Bolt 14455-02 Lower Handle 14455-037 Washer 14455-03 Press Button 14455-038 Washer 14455-04 Spring Clip 14455-039 Bolt 14455-05 Middle Handle 14455-040 Oil Plug 14455-06 Upper Handle 14455-041 Carrying Handle 14455-07 Link Pin...
